DreamCast 42” Dreambowl Setup Instructions

42" Dreambowl or Zen Firebowl setup instructions:
Burner
The firebowl utilizes a CSA approved outdoor burner unit and a custom steel pan that holds the
burner.
For information pertaining
to the safe operation of the burner, maintenance and warranty please refer to the
"Kingsman Outdoor Fire Pit Manual" (included). Specific sections in the manual will also be
referred to in these instructions.

Gas Line

When you ordered the firebowl, you specified either a bottom or side gas line hole. For a bottom
feed, the gas or propane supply must be concealed below the bowl so that the bowl can sit flatly
on a surface. For side gas line, the bowl may be
placed on any flat, secure surface.

For Natural Gas:

NOTE: Installation must be completed by a licensed gas-fitter and comply with local
codes.
Lift stainless steel ring taking care not to contact edge of bowl; then remove burner.
Feed a flexible gas supply line in through the hole in the bottom of the bowl and connect to 3/8" fl
are as per Kingsman Firepit Manual pg 6.
Feed Excess hose into the bottom of the bowl. Reposition burner assembly in bowl aligning the
valve with the valve hole.

For Propane:

Connect propane regulator hose to propane tank as per pages 5-6 of the "Outdoor Fire Pit
Manual"

Connecting Key

Attach connecting key valve to hole in bowl with epoxy and/or small screws. If the burner
assembly needs to be rotated to align with the key, gently turn the burner.

Finishing off

Distribute lava rock over entire surface of burner and steel support ensuring that it is completely
covered (approx 2" depth). If you ordered the "fire glass" this topping goes over the lava rock.
For Operating Instructions, refer to pages 14-15 of the "Kingsman Outdoor Fire Pit Manual"
