Summary of Contents for Fisher-Price V4553
- Page 1 V4553 IMPORTANT! KEEP FOR FUTURE REFERENCE. www.fisher-price.co.uk...
-
Page 2: Consumer Information
Consumer Information IMPORTANT! Please keep this instruction sheet for future reference, as it contains important information. WARNING • Please read these instructions before assembly and use of this product. • Adult assembly is required. Tool needed for assembly: Phillips Screwdriver (not included). To prevent serious injury or death: •... - Page 3 Some parts may be packed in the pad. for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price ® for replacement parts and instructions if needed. Never substitute parts.
- Page 4 Assembly Seat Back Tube Retainer Socket Up • Insert an M5 x 20 mm screw through each foot and tighten. Footrest • Make sure the socket in the retainer is upright. • Fit the seat back tube onto the ends of the base wire. •...
- Page 5 Assembly Retainers Pad Seat Back Pocket Soothing Unit • Fit the retainers through the side openings in the pad. • Fit the edges of the soothing unit through the large opening in the • Position the pad above the frame. front of the pad.
-
Page 6: Battery Installation
Battery Installation Hint: We recommend using an alkaline batteries for longer battery life. 1,5V “D” (LR20) 1,5V x 2 “AA” (LR6) Soothing Unit • Loosen the screw in the battery compartment door. Remove the battery compartment door. • Insert one “D” (LR20) alkaline battery into the battery compartment. •... -
Page 7: Setup And Use
Setup and Use WARNING To prevent serious injury or death: Restraint System • Fall Hazard - Never use on any elevated surface, since child’s movement may cause product to slide or tip over. Use only on a floor. • Suffocation Hazard - Never use on a soft surface (bed, sofa, cushion) since product can tip over and cause suffocation in soft surfaces.
