Marco Beverage Systems AT10 Operator's Manual

Operator's Manual for Model

Read this operator's manual fully before installation and use.

Voltage

230V ac 50-60Hz

240V ac 50-60Hz

Permissible mains inlet water pressure:

Minimum 20kPa / 0.02MPa / 0.2bar / 2.9psi

Maximum 1000kPa / 1MPa / 10bar / 145psi

The inlet water must be potable and free of contaminants.

Inlet water should be 5-30°C, pH 6.5-8.5, maximum chlorine content of 100 mg per

litre, total hardness of 60-180ppm. Do not connect the machine to pure reverse

osmosis water or other aggressive types of water.

Ensure that the equipment is installed according to local plumbing & water

regulations.

Covers shall only be removed by authorised personnel only. The appliance

must be fully disconnected from mains (the switch on the front panel is a

standby switch and does not switch mains voltage)

Warning. Live electrical voltages are present behind the cover(s)

marked with this symbol.

Part/Model Number: 1000760, 1000760#

(where # is a suffix of one or more letters)

Save this manual for future reference

Current

Power

12.2A

2.8kW

12.7A

3kW

IP Code

IP21

Table of Contents

Need help?

Do you have a question about the AT10 and is the answer not in the manual?

Page 1 Operator’s Manual for Model Part/Model Number: 1000760, 1000760# (where # is a suffix of one or more letters) Read this operator’s manual fully before installation and use. Save this manual for future reference Voltage Current Power IP Code 230V ac 50-60Hz 12.2A 2.8kW IP21...
Page 2 Warnings: Installation should only be carried out by a competent service engineer. This appliance must be placed/installed on a horizontal flat stable surface. This appliance is not suitable for outdoor use. The ambient temperatures this unit should operate within are 5ºC - 35ºC. This appliance should not be installed in a tightly enclosed area (such as a cupboard).
Page 3 Installation details: A suitable 230-240V power socket outlet is required in accordance with the local regulations. Be sure other high power appliances are not on the same circuit which could cause tripping. Installation procedure: Fit a stop valve and suitable fitting on a cold water line (e.g. 3/4" x 1/2" 311 or washing machine type stop valve).
Page 4 MMYY. The last numbers are an identification number unique to that machine in that month. e.g. 07125555 -this machine was made in July 2012 with an identification number of 5555. Manufactured by: Marco Beverage Systems Ltd. Contact: www.marco.ie 1900067 REV.1...
