EKOL CLARITY DOUBLE SIDED – INSTALLATION AND OPERATING INSTRUCTIONS.
INTRODUCTION
SAFETY
Safety is the most important consideration when using and installing your stove. If not installed and used correctly,
a house fire could result. Installation must comply with relevant national and local Building Regulations and fire
safety standards.
IN THE EVENT OF CHIMNEY FIRE, EVACUATE THE PROPERTY AND CALL THE EMERGENCY
SERVICES.
Your stove will be heavy and care needs to be taken when lifting - 2 people will normally be required to lift.
UNPACKING
Your stove will have several of its components stored inside the stove itself for transportation.
Do NOT drag the stove on its legs – it must be carefully lifted into place.
The flue spigot must be bolted to the flue outlet on the top of the stove.
Inside the stove you will find a glove which must be used when opening the door or when adjusting air vents when
the fire is hot.
INSTALLATION
Installation of your stove must comply with relevant local and national Building Regulations and fire safety
standards.

Advertisement

loading

Related Manuals for Ekol Ekol Clarity Double Sided

Summary of Contents for Ekol Ekol Clarity Double Sided

  • Page 1 EKOL CLARITY DOUBLE SIDED – INSTALLATION AND OPERATING INSTRUCTIONS. INTRODUCTION SAFETY Safety is the most important consideration when using and installing your stove. If not installed and used correctly, a house fire could result. Installation must comply with relevant national and local Building Regulations and fire safety standards.
  • Page 2 TECHNICAL Model; “Ekol Clarity Double Sided” Nominal heat output – 12.3 kW Maximum Heat Output – 14kW Gross Weight of Stove (inclusive of packaging) - 160 kg. Net Weight of Stove – 137kg (low version), 152 kg (tall version). Max Height - 598 mm (low version), 815 mm (Tall version)

  • Page 3: Air Inlet Controls

    "authorised" fuels) have been exempted by an Order made and signed by the Secretary of State or Minister in the devolved administrations. The “Ekol Clarity Double Sided” has been recommended as suitable for use in smoke control areas when burning seasoned wood.

  • Page 4: Lighting The Fire

    TOOLS The glove is provided for adjusting the air inlets and for opening the door when the stove is hot, as these knobs will heat up when in use. NOTE – all parts of the stove will become hot during use and care needs to be taken to avoid injury through burning.
  • Page 5 UK Clean Air Act 1993 - Smoke Control Areas The Ekol Clarity Double Sided wood-burning stoves are suitable for use in smoke control areas when used in accordance with these instructions.

  • Page 6: Cleaning & Maintenance

    CLEANING/MAINTENANCE Regular cleaning of the stove is essential for safety and efficiency. The ash should be emptied at least after every use, and during use if burning for longer periods. When cold, the inside of the stove should be given a regular sweep out. The flue and flue pipe will require cleaning with a suitable chimney brush, to minimise build up of soot and tar.
