KDC-305RG/3018R/3090R/A/G/YA/YG
KDC-305RG/309R/A/G/YA/YG
FM Section
Frequency Range ............................... 87.5MHz~108.0MHz
(Frequency Step)
Usable Sensitivity(S/N:26dB) ............. 0.7µV/75Ω
Quieting Sensitivity(S/N:46dB) ........... 1.6µV/75Ω
Frequency Response(±3.0dB) ........... 30Hz~15kHz
S/N ..................................................... 65dB(MONO)
Selectivity(DIN) .................................. ≥ 80dB(±400kHz)
Stereo Separation .............................. 35dB(1kHz)
MW Section
Frequency Range ............................... 531kHz~1611kHz
(Frequency Step)
Usable Sensitivity(S/N:20dB) ............. 25µV
LW Section
Frequency Range ............................... 153kHz~281kHz
Usable Sensitivity(S/N:20dB) ............. 45µV
CD Section
Laser Diode ........................................ GaAIAs(λ=780nm)
Digital Filter(D/A) ................................ 8 Times Over Sampling
D/A Converter .................................... 1Bit
Spindle Speed .................................... 500~200(CLV)
Wow & Flutter ..................................... Below Measurable Limit
Frequency Response ......................... 10~20kHz(±1dB)
KDC-3018R
FM Section
Frequency Range ............................... 87.5MHz~108.0MHz
(Frequency Step)
Channel Space Selection ................... FIX
Usable Sensitivity(S/N:30dB) ............. 9.3dBf(0.8µV/75Ω)
Quieting Sensitivity(S/N:50dB) ........... 15.2dBf(1.6µV/75Ω)
Frequency Response(±3.0dB) ........... 30Hz~15kHz
S/N ..................................................... 70dB(MONO)
Selectivity(DIN) .................................. ≥ 80dB(±400kHz)
Stereo Separation .............................. 40dB(1kHz)
MW Section
Frequency Range ............................... 531kHz~1611kHz
(Frequency Step)
Usable Sensitivity(S/N:20dB) ............. 28dBµ(25µV)
LW Section
Frequency Range ............................... 153kHz~281kHz
Usable Sensitivity(S/N:20dB) ............. 45µV
CD Section
Laser Diode ........................................ GaAIAs(λ=780nm)
Digital Filter(D/A) ................................ 8 Times Over Sampling
D/A Converter .................................... 1Bit
Spindle Speed .................................... 500~200(CLV)
Wow & Flutter ..................................... Below Measurable Limit
KENWOOD follows a policy of continuous advancements in development. For this reason specifications may be changed without notice.
26

SPECIFICATIONS

(50kHz)
AMPLIFIER Section
TONE Section
(9kHz)
General
(50kHz)
AMPLIFIER Section
TONE Section
(9kHz)
General
THD .................................................... 0.01%(1kHz)
S/N Ratio ............................................ 96dB(1kHz)
Dynamic Range .................................. 93dB
Channel Separation ........................... 85dB
Preout Level/Load .............................. 1800mV/10kΩ(CD/CD-CH)
Preout Impedance .............................. ≤ 600Ω
Maximum Power ................................ 45W×4
Power DIN45324, +B=14.4V .............. 28W×4
Bass ................................................... 100Hz±10dB
Middle ................................................. 1kHz±10dB
Treble ................................................. 10kHz±10dB
Operating Voltage .............................. 14.4V
(11V~16V allowable)
Current Consumption ......................... 10A
Installation Size (W) ........................... 182(mm) 7-3/16(in)
(H) ........................... 53(mm) 2-1/16(in)
(D) ........................... 157(mm) 6-3/16(in)
Weight ................................................ 1.5kg(3.31lbs)
Frequency Response ......................... 10~20kHz(±1dB)
THD .................................................... 0.01%(1kHz)
S/N Ratio ............................................ 96dB(1kHz)
Dynamic Range .................................. 93dB
Channel Separation ........................... 85dB
Preout Level/Load .............................. 1800mV/10kΩ(CD/CD-CH)
Preout Impedance .............................. ≤ 600Ω
Maximum Power ................................ 45W×4
Full Bandwidth Power ........................ 22W×4
Bass ................................................... 100Hz±10dB
Middle ................................................. 1kHz±10dB
Treble ................................................. 10kHz±10dB
Operating Voltage .............................. 14.4V
(11V~16V allowable)
Current Consumption ......................... 10A
Installation Size (W) ........................... 182(mm) 7-3/16(in)
(H) ........................... 53(mm) 2-1/16(in)
(D) ........................... 157(mm) 6-3/16(in)
Weight ................................................ 1.5kg(3.31lbs)
