ATP Electronics APD Series User Manual

Bench scales with weight indicator which can be mounted attached to the platform or can be mobile
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
ATP Messtechnik GmbH
J. B. von Weiss Strasse 1
D- 77955 Ettenheim
Email: info@atp-messtechnik.de
Internet: www.atp-messtechnik.de
Tel: 0 7822-8624 0 - FAX: 0 7822-8624 40
APD: Bench scale with weight indicator which can be mounted
attached to the platform or can be mobile.
APD_01_11.05_EN_U

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APD Series and is the answer not in the manual?

Questions and answers

Related Manuals for ATP Electronics APD Series

Summary of Contents for ATP Electronics APD Series

  • Page 1 User Manual ATP Messtechnik GmbH J. B. von Weiss Strasse 1 D- 77955 Ettenheim Email: info@atp-messtechnik.de Internet: www.atp-messtechnik.de Tel: 0 7822-8624 0 - FAX: 0 7822-8624 40 APD: Bench scale with weight indicator which can be mounted attached to the platform or can be mobile. APD_01_11.05_EN_U...

  • Page 2: Table Of Contents

    APD series bench scale APD_01_11.05_EN_U INDEX 1. INTRODUCTION.................................3 2. MAIN TECHNICAL SPECIFICATIONS..........................4 3. SYMBOLS...................................4 4. INSTALLATION ..................................5 5. POWER SUPPLY AND START UP ............................7 5.1 POWER SUPPLY.................................7 5.2 TURNING ON / OFF THE INSTRUMENT ........................7 6. FRONT PANEL KEYS AND INDICATORS ........................8 7.

  • Page 3: Introduction

    APD series bench scale APD_01_11.05_EN_U 1. INTRODUCTION The purpose of this manual is to help the user get to know the scale’s various functioning modes, the keys’ functions and the display indications. It is possible that one may incur into the phrase “TECH.MAN.REF.”: this means that an advanced function is being described (therefore, for the technical personnel) and which is further explained in the corresponding technical manual.

  • Page 4: Main Technical Specifications

    APD series bench scale APD_01_11.05_EN_U 2. MAIN TECHNICAL SPECIFICATIONS POWER SUPPLY 6Vdc trough 110-240 Vac 50-60Hz adapter or rechargeable battery (6V – 4,5 Ah). NOTE: recharge the battery using only the adapter provided. MAXIMUM POWER 5 VA OPERATING TEMPERATURE From -10 to +40 °C (14 to 104 °F) (with even temperature).

  • Page 5: Installation

    APD series bench scale APD_01_11.05_EN_U 4. INSTALLATION 1) Input for the external power supply. 2) Input for the cable of the cell and battery power supply.
  • Page 6 APD series bench scale APD_01_11.05_EN_U The digital weight indicator has an ABS case whose external dimensions are represented in figures. The indicator can be mounted attached to the platform or it can be installed in any desired position. In the following figures, the dimensions of the scale and the plate are shown:...

  • Page 7: Power Supply And Start Up

    APD series bench scale APD_01_11.05_EN_U 5. POWER SUPPLY AND START UP 5.1 POWER SUPPLY The instrument can be powered with a 6 Vdc tension supplied from an AC/DC external adapter which should be connected to the 110-240 Vac mains voltage. Safety norms must be respected for the connection to the mains voltage including the use of a line which has to be free from noise generated by other electronic equipment.

  • Page 8: Front Panel Keys And Indicators

    APD series bench scale APD_01_11.05_EN_U 6. FRONT PANEL KEYS AND INDICATORS The front panel of the indicator is designed for quick but simple weighing applications. It consists of a display with 6 digits, 25 mm in height and a 5 keys water-proof film keyboard.

  • Page 9: Symbols On The Display

    APD series bench scale APD_01_11.05_EN_U 7. SYMBOLS ON THE DISPLAY The display has symbols which show the scale’s functioning status; you will find the description for each symbol below. DISPLAY NUMBER SYMBOL FUNCTION 0    The weight detected on the weighing system is near zero, within the interval of –1/4 ÷...
  • Page 10 APD series bench scale APD_01_11.05_EN_U (13) Not used. (14) Indicates the unit of measure in use (“kg” for kilogram, “g” gram). (15) Not used. (16) Indicates the unit of measure in use (tons). (17) Indicates the unit of measure in use (pounds).

  • Page 11: Basic Functions

    APD series bench scale APD_01_11.05_EN_U 8. BASIC FUNCTIONS 8.1 ZERO SCALE By pressing the ZERO key, it is possible to zero a gross weight value which is within +/- 2% of the capacity; after the zeroing, the display shows 0 weight and the relative pilot lights are turned on.

  • Page 12: Limitation Of The Tare Functions For Direct Sale

    APD series bench scale APD_01_11.05_EN_U - Press the MODE/C key many times until the display shows the message “SAVE?”. - Press MR to confirm the changes made or another key for not saving. The instrument stores the last selection made, also after it is turned off.

  • Page 13: Multi Range Functioning (For Legal For Trade Approved Instruments)

    APD series bench scale APD_01_11.05_EN_U 8.6 MULTI RANGE FUNCTIONING (for legal for trade approved instruments) The multi range functioning allows to subdivide the scale capacity in two or three ranges, each which is up to 3000 divisions, improving in this way the first range division in the dual range and the first two ranges in the triple range.

  • Page 14: Totalisation

    APD series bench scale APD_01_11.05_EN_U 9. TOTALISATION Inside the F.ModE >> totAL step of the setup environment it is possible to set the parameters for the function of totalisation: tot.Mod: TYPE OF TOTALIZATION It is possible to select the type of totalisation: manual (MAnuAL) or automatic (Auto).

  • Page 15: Reactivation Of The Totalisation

    APD series bench scale APD_01_11.05_EN_U 9.2 REACTIVATION OF THE TOTALISATION To avoid undesired totalisations, the M+ key is active just once; its reactivation depends on the setting of the “rEACt” parameter (TECH.MAN.REF.) in the setup environment. It can be reactivated after the passing of the weight by the zero of the scale, by instability of the weight or always.

  • Page 16: Instrument Messages While In Use

    APD series bench scale APD_01_11.05_EN_U 10. INSTRUMENT MESSAGES WHILE IN USE MESSAGE DESCRIPTION ZEro The scale is zeroing the weight. unStAb One is trying to totalize with an unstable weight. un.oVEr One is trying to totalize with the weight in underload or in overload, in other words, with a weight of 9 divisions greater than the capacity or of 100 divisions below the gross zero.

  • Page 17: Declaration Of Conformity

    APD series bench scale APD_01_11.05_EN_U DECLARATION OF CONFORMITY This device conforms to the essential standards and norms relative to the applicable European regulations. The Declaration of Conformity is available in the web site www.diniargeo.com WARRANTY The TWO YEARS warranty period begins on the day the instrument is delivered.
