ATP Electronics FHB-600 Instruction Manual

FUNCTION SETTINGS
1. To change & set BAUD Rating, Parity & Print Mode
Press [ON/OFF] to turn on the scale on. This display will show --------. As soon as
you see --------, press [PRINT] and the display will show b xxx BAU value (BAUD
Rate). Press to select 1200, 2400, 4800 or 9600.
[UNIT]
Press [ZERO] to enter Parity mode, the display will show
to select odd, even or none (odd stands for 7 data bits with odd parity, even stands
for 7 data bits with even parity, none stands for 7 data bits without parity).
Press [ZERO] to enter Print mode. The display will show n xxx Mod. Press [UNIT]
to select ON, OFF, KEY or STB (OFF stands for serial data output disabled, KEY
stands for demand mode by pressing
scale is stable and ON stands for continuous print. Press [ZERO] again to return to
weighing mode.
2. To activate and deactivate weighing units
Press [ON/OFF] to turn on the scale on. The display will show digits and then
--------. As soon as you see -------- press [UNIT] to enter unit selection mode. The
display will show ON X (X stands for the units i.e. g or oz). Press [ZERO] to select
an unit and press [UNIT] to select ON (to activate the selected unit) or OFF (to
de-activate the selected unit). Press [ZERO] until you return to weighing mode.
2. To change & set the Zero, Tare, Overload & Back Light settings
Press [ON/OFF] to turn on the scale on. The display will show digits and then
--------. As soon as you see -------- press [PCS]. Following the table below, use the
[ZERO] button to enter each setting and [UNIT] button to change the value in each
setting.
Setting (shown as it is What setting you are
seen on the display)
ZRD X.X Zero Track Value
ZRT X.X Zero Track Time
RZD X.X
FIL X
PZR XX Set percentage for zero
range when the scale is
TZR XX Set percentage of zero
TTR XXX Set percentage of tare
OUR XX Overload Protection
b2 XX Activate or deactivate
beep when buttons are
ZT XX Unite tare & zero function
A XXX Auto-power off settings
L XXX Back Light settings
P XXX PAR
stands for automatic print when
[PRINT], STB
What you can choose
changing from
0.0, 0.2, 0.4, 0.6, 0.8, 1.0,
1.5 & 2.0
0.5, 1.0, 1.5, 2.0, 2.5, 3.0,
3.5 & 4.0
Zero Value 0.8, 1.8, 2.8 & 3.8
Filter Range 0, 1, 2, 3, 4, 5, 6 & 7
1, 2, 3, 4, 5, 8, 10 & 20
first turned on
3, 4, 5 & 10
range
50 or 100
range
2, 5, 10 9d
Mode
ON or OFF
pressed
ON or OFF
3, 5, 10mins or OFF
AUTO, OFF or ON
COMPACT SCALE
. Press [UNIT]
INSTRUCTION MANUAL
/
BALANCE
