Receiver
Ink Refill
Receiver
A.
Clip- Holds paper of A4 Size (default).
B.
Reset hole- Reset the device.
C.
Power button- Press to turn on/off the device.
D.
Micro USB port- Connects to Micro USB cable for charging.
E.
LED indicator- Indicate the various working status of the device.
Note: For the sake of power saving, usually only one LED indicator will light to
indicate related status at one time:
Power on: two LEDs blink once;
Charging : red LED blinks briefly;
Fully charged : red LED lights for a while
Low battery: red LED blinks slowly
Standby : green LED blinks slowly
Writing : green LED blinks briefly
Accessories
● USB Cable(Mini + Micro)
● Refill Extractor
Overview of Receiver
● Digital Pen Electropen 2
● User Manual
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Portronics XN680
Summary of Contents for Portronics XN680
- Page 1 Accessories Receiver ● USB Cable(Mini + Micro) ● Digital Pen Electropen 2 Ink Refill ● Refill Extractor ● User Manual Overview of Receiver Receiver Clip- Holds paper of A4 Size (default). Reset hole- Reset the device. Power button- Press to turn on/off the device. Micro USB port- Connects to Micro USB cable for charging.
-
Page 2: Digital Pen
Digital Pen F Mini USB port Connects to PC via Mini USB cable for charging. Note Disconnect the USB cable when the device has charged for about 2 hours. G Charging indicator: Lights red when charging is going on and goes out when charging completes ;... - Page 3 Software Application 1 System requirements iPhone 4s /iPad3 or above with iOS7.0 or above Android 4.3 or above, with Bluetooth 4.0 LE 2) Run the application “Cloudwrite” a. User can download the application “Cloudwrite ” to your mobile devices from AppStore, Google Play, Android Market or by scanning the QR code (for Android devices) and install it.
- Page 4 d. Tap on the device name which is also showing on the device barcode from device list to pair. “ Device is connected, Start writing” will appear at bottom area to notify the note-taking mode. e. Clip the receiver on the top- center of A4 size paper. Hold the pen and write as usual.
- Page 5 g. Tap on “Note” icon on the top right corner to check your recent notes. Description of the interfaces Notes Management Upload Management Modify the name of device or get back to device list. Note Check all notes that have been saved or uploaded. Share : Upload your notes to social networks.
- Page 6 Remarks: To share your notes, please make sure your mobile device is connected to the Internet. Pen: Change the width of your pen. Wall: Change the wallpaper (background) of your notes. Erase : Erase paticular part of your writing or drawing, or clear the whole page. Color: Change the color of your ink.
