Date
July. 2014
Oct. 2014
® 2014 Aplex Technology, Inc.
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
ACS-266XC User Manual
ACS-266XC
Box PC User Manual
Revision
Version
V1.1
V1.2
All Rights Reserved.
Remark
Operating and Storage Temperature revised
aplex@aplex.com.tw
Published in Taiwan
URL:
www.aplex.com.tw
1
Advertisement
Table of Contents
Related Manuals for Aplex ACS-266XC
Summary of Contents for Aplex ACS-266XC
- Page 1 July. 2014 V1.1 Oct. 2014 V1.2 Operating and Storage Temperature revised ® 2014 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw...
-
Page 2: Warning
Disclaimer This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials. -
Page 3: Table Of Contents
4.2 Intel Graphics Media Accelerator Driver...…………………..…………..65 4.3 Intel 82583V Network Adapter……………………………………….….68 4.4 Realtek HD Audio Driver Installation…….…………..…………………71 Figures Figure 1.1:Dimensions of ACS-2663C…………………………………..…..7 Figure 1.2:Dimensions of ACS-2664C…………………………………..…..8 Figure 1.3:Dimensions of ACS-2665C…………………………………..…..9 Figure 1.4:Front view of ACS-2663C…………………………………..…..10 Figure 1.5:Rear view of ACS-2663C…………………………………..…..10 ACS-266XC User Manual... - Page 4 Figure 1.6: Front view of ACS-2664C…………………………………………11 Figure 1.7: Rear view of ACS-2664C…………………………………………11 Figure 1.8: Front view of ACS-2665C…………………………………………12 Figure 1.9: Rear view of ACS-2665C………………………….…………….12 ACS-266XC User Manual...
-
Page 5: Getting Started
268 x 195 x 74.6 268 x 195 x 101.8 268 x 195 x122.7 268 x 240 x 80 268 x 240 x 104.8 268 x 240 x 125.7 Dimension(mm) (mount kit) (mount kit) (mount kit) Net weight(Kgs) Environment ACS-266XC User Manual... -
Page 6: Dimensions
-20°C to 60°C temperature(°C) -40°C to 70°C for WT1 and WT2 option 10 to 90%@ 40℃, non-condensing Storage humidity Certification CE / FCC Class A Operating System Win 7, WES7, XP, WIN CE 6.0 Support 1.2 Dimensions ACS-266XC User Manual... -
Page 7: Figure 1.1:Dimensions Of Acs-2663C
Figure 1.1: Dimensions of ACS-2663C ACS-266XC User Manual... -
Page 8: Figure 1.2:Dimensions Of Acs-2664C
Figure 1.2: Dimensions of ACS-2664C ACS-266XC User Manual... -
Page 9: Figure 1.3:Dimensions Of Acs-2665C
Figure 1.3: Dimensions of ACS-2665C ACS-266XC User Manual... -
Page 10: Brief Description
Atom Processor D2550 1.86GHz , L2 Cache 1MB and supporting 4 x USB, 1 x SATA HDD space, DC 9~32V DC etc. ACS-266XC works very well along with any of our Display Monitor series and it absolutely can provide an easy way to perform control and field maintenance. -
Page 11: Figure 1.6 Front View Of Acs-2664C
Figure 1.6 Front view of ACS-2664C Figure 1.7 Rear view of ACS-2664C ACS-266XC User Manual... -
Page 12: Figure 1.8:Front View Of Acs-2665C
Figure 1.8:Front view of ACS-2665C Figure 1.9:Rear view of ACS-2665C ACS-266XC User Manual... -
Page 13: Chapter 2 Hardware
Up to 1366 x 768 for LVDS1 (N2600/N2800) Up to 1920 x 1200 for LVDS2 (D2550) Up to 1600 x 1200 for LVDS2 (N2600/N2800) Dual Display CRT+LVDS1 CRT+LVDS2 Winbond W83627UHG Super I/O AMIBIOS BIOS Storage 2 x SATA Connector ACS-266XC User Manual... - Page 14 Power on/off switch by TB-522 or TB-523 LED Indicators Reset switch by MIO2 Power LED status by MIO2 HDD LED status by MIO2 External I/O port 2 x COM Ports (COM1/COM2) 4 x USB 2.0 Ports (stack) 2 x RJ45 GbE LAN Ports ACS-266XC User Manual...
- Page 15 12V /1.25A (Intel Atom D2550 processor with 2GB DDR3 DRAM) Power 12V /1.18A (Intel Atom N2800 processor with 2GB DDR3 DRAM) Consumption 12V /0.95A (Intel Atom N2600 processor with 2GB DDR3 DRAM) EMI/EMS Meet CE/FCC class A ACS-266XC User Manual...
-
Page 16: Board Dimensions
2.2 Board Dimensions ACS-266XC User Manual... -
Page 17: Jumpers And Connectors Location
2.3 Jumpers and Connectors Location Board Top ACS-266XC User Manual... - Page 18 Board Bottom ACS-266XC User Manual...
-
Page 19: Jumpers And Connectors
DC IN Power (Default) Close 2-3 ATX 12V_IN (ATX Power) 4. PS_ON: (2.0mm Pitch 1X3 Pin Header),ATX Power and Auto Power on jumper setting. Mode (DC_IN) Close 1-2 Auto Power on (Default) Close 2-3 or Open 1-2 ATX Power ACS-266XC User Manual... - Page 20 7. ATX1 (option): (2.0mm Pitch 1X3 Pin wafer connector),connect PSON and 5VSB and Ground signal,support ATX Power model. Reserved. Pin# Signal Name Pin1 ATX PSON PIN2 ATX Ground PIN3 ATX 5VSB 8. U2: (FCBGA559), onboard CPU . ACS-266XC User Manual...
- Page 21 Up to 4GB ASB-M7101-N2800 SODIMM1/SODIMM2 Up to 4GB ASB-M7101-N2600 SODIMM1 Up to 2GB 11. VGA: (CRT DB15 Connector),Video Graphic Array Port, provide high-quality video output. they can not work at the same time for VGA and VGA_PH. ACS-266XC User Manual...
- Page 22 (2.0mm Pitch 1x6 Pin wafer connector), Backlight control connector for LVDS1. Pin# Signal Name +DC12V +DC12V Ground Ground BKLT_EN BKLT_CTRL Note: Pin6 is backlight control signal, support DC or PWM mode, mode select at BIOS CMOS menu. ACS-266XC User Manual...
- Page 23 (2.54mm Pitch 2x4Pin Socket), AT24C02 socket, The EEPROM is set for the resolution of LVDS2. The resolution default is:1280*1024. According to the needs of customers set. 16. INVT2: (2.0mm Pitch 1x6 Pin wafer connector), Backlight control connector for LVDS2. Pin# Signal Name ACS-266XC User Manual...
- Page 24 LB_D2_N LA_D2_N LB_D2_P LA_D2_P Ground Ground LB_CLKN LA_CLKN LB_CLKP LA_CLKP Ground Ground LVDS2_DDC_DATA LVDS2_DDC_CLK Ground Ground LB_D3_N LA_D3_N LB_D3_P LA_D3_P 19. BTN: POWER on/off Button, They are used to connect power switch button. The two pins are ACS-266XC User Manual...
- Page 25 COM1 port is controlled by pins No.1~6 of JP2,select output Signal RI or 5V or 12v, For details, please refer to description of JP2. COM1/RS232 (Default): Pin# Signal Name DCD# (Data Carrier Detect) ACS-266XC User Manual...
- Page 26 23. JP3: (2.0mm Pitch 2x3 Pin Header),COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. JP3 Pin# Function Close 1-2 COM2 RI (Ring Indicator) (default) Close 3-4 COM2 Pin9=+5V (option) ACS-266XC User Manual...
- Page 27 (2.0mm Pitch 2x3 Pin Header) COM6 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM6 port. JP4 Pin# Function Close 1-2 COM6 RI (Ring Indicator) (default) Close 3-4 COM6 Pin9=+5V (option) Close 5-6 COM6 Pin9=+12V (option) 27. COM6 ACS-266XC User Manual...
- Page 28 (Diameter 3.5mm Double stack Jack), HD Audio port, An onboard Realtek ALC662 codec is used to provide high quality audio I/O ports. Line Out can be connected to a headphone or amplifier, MIC is the port for microphone input audio. ACS-266XC User Manual...
- Page 29 +3.3V PCI Card Close 2-3 +5V PCI Card 34. PC104+ (option) (4x30 Pin), PC104 plus connector, it conforms to standard PC104+ specification. Can expand support four PCI devices. Model PC104+ Connector ASB-M7101T-D2550 (option) ASB-M7101B-D2550 Bottom (option) ASB-M7101T-N2800 ACS-266XC User Manual...
- Page 30 USB ports, one power led, one power button, via a dedicated cable connected to TB-522 MIO1or TB-523 MIO1. Function Signal Name Pin# Pin# Signal Name Function 422RX+ 485+ / 422TX+ COM3 COM3 RS422 or 485 422RX- 485- / 422TX- RS422 Ground WLAN_LED+ WLAN LED WLAN_LED- ACS-266XC User Manual...
- Page 31 RESET Ground PSON- BUZZER+ BUZZER- BUZZER- BUZZER+ GPIO_IN_1 SIO_GPIO60 SIO_GPIO20 GPIO_OUT_1 GPIO_IN_2 SIO_GPIO61 SIO_GPIO21 GPIO_OUT_2 GPIO_IN_3 SIO_GPIO62 SIO_GPIO22 GPIO_OUT_3 GPIO_IN_4 SIO_GPIO63 SIO_GPIO23 GPIO_OUT_4 Ground 5V_S5_USB PS2_K/B PS2_Mouse PS2_KBDATA PS2_MSDATA PS2_KBCLK PS2_MSCLK 5V_S5_USB 5V_S5_USB Ground Ground 5V_S5_USB 5V_S5_USB ACS-266XC User Manual...
- Page 32 41. SATA_P1/SATA_P2: (2.5mm Pitch 1x2 Pin wafer connector), Two onboard 5V output connectors are reserved to provide power for SATA devices. Pin# Signal Name +DC5V Ground Note: Output current of the connector must not be above 1A. ACS-266XC User Manual...
- Page 33 46. H5/H6: MPCIE1 SCREW HOLES, H5 for mini PCIE card (30mmx30mm) assemble. H6 for mini PCIE card (30mmx50.95mm) assemble. 47. TB-522: ASB-M7101 I/O Card, via a dedicated cable connected to ASB-M7101 MIO1. LED2: CF Card LED status. ACS-266XC User Manual...
- Page 34 BIOS Setup Utility \ Advanced /Super IO Configuration \ Serial Port3 Type: [RS-485] [RS-422] COM4: (Type DB9),Rear serial port, standard DB9 Male serial port is provided to make a direct connection to serial devices. Pin# Signal Name ACS-266XC User Manual...
- Page 35 Compact Flash card. The operating voltage of CF card can be set as 3.3V or 5V. The default setting of the product is 5V. MIO1: (DF13-40P) TB-522 MIO1 via a dedicated cable connected to ASB-M7101 MIO1. Signal Name Pin# Signal Name 422_RX+ 485+_422TX+ 422_RX- 485-_422TX- Ground ACS-266XC User Manual...
- Page 36 48. TB-520P1: TB-520P1 connect to ASB-M7101T PC104+ connector, PC104+ is located at the top, It provides one PCI slot. 49. TB-520P2: TB-520P2 connect to ASB-M7101T PC104+ connector, PC104+ is located at the top, It provides two PCI slots. ACS-266XC User Manual...
- Page 37 51. TB-520E1: TB-520E1 connect to ASB-M7101T PCIE1X connector, PCIE1X are located at the top, It provides one PCIE slot. 52. TB-521P1: TB-521P1 connect to ASB-M7101B PC104+ connector, PC104+ is located at the Bottom, It provides one PCI slot. ACS-266XC User Manual...
- Page 38 TB-521P2 connect to ASB-M7101B PC104+ connector, PC104+ is located at the Bottom, It provides two PCI slots. 54. TB-521P1E1: TB-521P1E1 connect to ASB-M7101B PC104+ and PCIE1X connector,PC104+ and PCIE1X are located at the Bottom, It provides one PCI slot and one PCIE slot. ACS-266XC User Manual...
- Page 39 Bottom, It provides one PCI slot and two PCIE slots. PCIe1 Signal for PCIE1X or MPCIE Socket. 56. TB-523: ASB-M7101 I/O Card, via a dedicated cable connected to ASB-M7101 MIO1 and MIO2. TB-523 Top： TB-523 Bottom： ACS-266XC User Manual...
- Page 40 Pin# Pin# Signal Name 422_RX+ 422_RX- 422_TX- 485- 422_TX+ 485+ Ground Ground Note: Use COM3 RS422 or RS485 Function, please enter BIOS CMOS Setup. Path: BIOS Setup Utility \ Advanced /Super IO Configuration \ Serial Port3 Type: ACS-266XC User Manual...
- Page 41 DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) RI (Ring Indicator) COM4 RS422 Type (option) COM4 RS485 Type (option) Signal Name Pin# Pin# Signal Name 422_RX+ 422_RX- 422_TX- 485- 422_TX+ 485+ Ground Ground ACS-266XC User Manual...
- Page 42 Compact Flash card. The operating voltage of CF card can be set as 3.3V or 5V. The default setting of the product is 5V. GPIO: (3.5mm Pitch 2x5 Pin Connector),General-purpose input/output port, it provides a group of self-programming interfaces to customers for flexible use. Function Pin# Function ACS-266XC User Manual...
- Page 43 485-_422TX- Ground GPIO_IN1 GPIO_IN2 GPIO_IN3 GPIO_IN4 5V_S5 DCD4- RXD4 TXD4 DTR4- Ground DSR4- RTS4- CTS4- RI4- 5V_S5 5V_S5 5V_USB01 USB3_N USB0_N USB3_P USB0_P Ground Ground GPIO_OUT1 GPIO_OUT2 5V_USB01 SO_POWER_SENSE USB1_N PWR_LED- USB1_P PS_ON- Ground Ground GPIO_OUT3 GPIO_OUT4 ACS-266XC User Manual...
-
Page 44: Chapter 3 Bios Setup
BIOS, CPU, memory, and storage devices. Press F11 to load default values and continue 0085 3.2 BIOS SETUP UTILITY Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. ACS-266XC User Manual... -
Page 45: Main Settings
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit BIOS Information Intel Reference Code BIOS Vendor American Megatrends Version Core Version 4.6.5.3 Compliancy UEFI 2.3; PI 1.2 Project Version 7101V006 ►Intel RC Version ACS-266XC User Manual... -
Page 46: Advanced Settings
Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit PCI,PCI-X and PCI ►PCI Subsystem Settings Express Settings ►ACPI Settings ►CPU Configuration ►Thermal Configuration ►IDE Configuration ►USB Configuration ►W83627UHG Super IO Configuration ACS-266XC User Manual... - Page 47 [160 PCI Bus Clocks] [192 PCI Bus Clocks] [224 PCI Bus Clocks] [248 PCI Bus Clocks] VGA Palette Snoop: [Disabled] [Enabled] PERR# Generation: [Disabled] [Enabled] SERR# Generation: [Disabled] [Enabled] 3.4.2 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] ACS-266XC User Manual...
- Page 48 Ratio Status Actual Ratio System Bus Speed 533 MHz Processor Stepping 30661 Microcode Revision L1 Cache RAM 2x56 k L2 Cache RAM 2x512 k Processor Core Dual Hyper-Threading Supported Hyper-Threading: [Enabled] [Disabled] Execute Disable Bit: [Enabled] [Disabled] ACS-266XC User Manual...
- Page 49 Not Present SATA Port1 Not Present SATA Controller(S): [Enabled] [Disabled] Configure SATA as: [IDE] [AHCI] Misc Configuration for hard disk 3.4.6 USB Configuration USB Configuration USB Devices: 1 keyboard Legacy USB Support: [Enabled] [Disabled] EHCI Hand-off: [Disabled] [Enabled] ACS-266XC User Manual...
- Page 50 VCORE : +1.184 V +12V : +12.512 V +3.3V : +3.288 V +1.5V : +1.528 V AVCC : +5.170 V VCC5V : +5.182 V VSB5 : +5.170 V VBAT : +3.368 V 3.4.9 Serial Port Console Redirection ACS-266XC User Manual...
- Page 51 [Enabled] [Disabled] CPU C state Report [Enabled] [Disabled] Enhanced C state [Enabled] [Disabled] CPU Hard C4E [Enabled] [Disabled] CPU C6 state [Enabled] [Disabled] C4 Exit Timing [Fast] [Default] [Slow] C-state POPDOWN [Enabled] [Disabled] C-state POPUP [Enabled] [Disabled] ACS-266XC User Manual...
-
Page 52: Chipset Settings
►Memory Frequency and Timing ►Intel IGD Configuration ******* Memory Information ******* Memory Frequency 1067 MHz(DDR3) Total Memory 2048 MB DIMM#0 Not Present DIMM#1 2048 MB Memory Frequency and Timing MRC Fast Boot [Enabled] [Disabled] Max TOLUD [Dynamic] [1GB] ACS-266XC User Manual... - Page 53 LCD Panel Type [VBIOS Default] [640x480,18bit] [800x480,18bit] [800x600,18bit] [1024x600,18bit] [1024x768,18bit] [1280x768,18bit] [1280x800,18bit] [1280x1024,18bit] [1366x768,18bit ] [1024x768,24bit ] [1280x768,24bit ] [1280x800,24bit ] [1280x1024,24bit ] [1366x768,24bit ] Active LFP [LVDS] [No LVDS] [EDP] IGD Clock Source [Internal Clock] [External Clock] ACS-266XC User Manual...
- Page 54 [Level 14] [Level 15] LVDS1 Setting: IGFX – Boot Type: [LVDS1] or [CRT+LVDS] Active LFP: [LVDS] LVDS2 Setting: IGFX – Boot Type: [LVDS2] or [CRT+LVDS] Active LFP: [EDP] 3.5.2 South Bridge TPT Devices PCI Express Root Port 0 ACS-266XC User Manual...
-
Page 55: Boot Settings
Setup Prompt Timeout Wait for setup Bootup Numlock State [On] Activation key. 65535(0xFFFF)means Quiet Boot [Disabled] Indef inite waiting. Fast Boot [Disabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] Option ROM Messages [Force BIOS] Interrupt 19 Capture [Immediate] ACS-266XC User Manual... - Page 56 Fast Boot [Disabled] [Enabled] CSM16 Module Version 07.69 Gatea20 Active [Upon Request] [Always] Option ROM Messages [Force BIOS] [Keep Current] Interrupt 19 Capture [Enabled] [Disabled] Boot Option #1 Boot Option #2 …… Sets the system boot order ACS-266XC User Manual...
-
Page 57: Security Settings
Launch Video OpROM po [Do not Launch] [UEFI only] [Legacy only] Other PCI device ROM [UEFI OpROM] [Legacy OpROM] Security Settings Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit ACS-266XC User Manual... - Page 58 Also, the feature is capable of requesting users to enter the password prior to system boot to control unauthorized access to your computer. Users may enable the feature in Security Option of Advanced BIOS Features. If Security Option is set to System, you will be requested to enter ACS-266XC User Manual...
-
Page 59: Save & Exit Settings
Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset ACS-266XC User Manual... - Page 60 Load Optimized Defaults Load optimized Defaults? [Yes] [No] Save user Defaults Save Values as User Defaults Save configuration? [Yes] [No] Restore user Defaults Restore User Defaults Restore User Defaults? [Yes] [No] Launch EFI Shell from filesystem device WARNING Not Found [ok] ACS-266XC User Manual...
-
Page 61: Chapter 4 Installation Of Drivers
VGA driver, LAN drivers, Audio driver. Installation instructions are given below. Important Note: After installing your Windows operating system (Windows XP), you must install first the Intel Chipset Software Installation Utility before proceeding with the installation of drivers. ACS-266XC User Manual... -
Page 62: Intel Chipset Driver
4.1 Intel Chipset Driver To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel(R) Chipset Atom D525 + Intel ICH8M from the list Step 2. Click Next to setup program. ACS-266XC User Manual... - Page 63 Step 3. Read the license agreement. Click Yes to accept the terms of the license agreement. Step 4. Click Next to continue. ACS-266XC User Manual...
- Page 64 Step 5. Click Next. Step 6. Select Yes, I want to restart this computer now. Click Finish then remove any installation media from the drivers. ACS-266XC User Manual...
-
Page 65: Intel Graphics Media Accelerator Driver
4.2 Intel Graphics Media Accelerator Driver To install the VGA drivers, follow the steps below to proceed with the installation. Step 1. Select Intel (R) GMA 3150 VGA Chipset. Step 2. Click Next to continue. ACS-266XC User Manual... - Page 66 Step 3. Click I agree. Step 4. Click Continue Anyway. ACS-266XC User Manual...
- Page 67 Step 5. Click Continue Anyway. Step 6. Click Yes to restart the computer. ACS-266XC User Manual...
-
Page 68: Intel 82583V Network Adapter
4.3 Intel(R) 8253V Network Adapter To install the Intel (R) 8253V Network Adapter connect device driver, please follow the steps below. Step 1. Select Intel (R) 8253V Network Adapter from the list Step 2. Click Next to continue. ACS-266XC User Manual... - Page 69 Step 3. Read the license agreement. Select I accept the terms in the license agreement then click Next to continue. Step 4. Select Drivers, Intel(R) PROSet for Windows* Device Manager, Advanced Network Services. Click Next to continue. ACS-266XC User Manual...
- Page 70 Step 5. Click Install to begin installation. Step 6. Click Finish to complete the installation. ACS-266XC User Manual...
-
Page 71: Realtek Hd Audio Driver Installation
4.4 Realtek HD Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. Step 1. Select Realtek ALC662 HD Audio Driver from the list Step 2. Click Next to continue the installation. ACS-266XC User Manual... - Page 72 Step 3. Click Yes. ACS-266XC User Manual...
