Aplex AVS-302 User Manual

Aplex palm-size system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AVS-302
Aplex Palm-size System
Intel Celeron J1900 Platform
User Manual
Release Date
Revision
Aug. 2022
V1.1
®2022 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235,Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail:
aplex@aplex.com.tw
URL:
www.aplex.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVS-302 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplex AVS-302

Summary of Contents for Aplex AVS-302

  • Page 1 Intel Celeron J1900 Platform User Manual Release Date Revision Aug. 2022 V1.1 ®2022 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235,Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: aplex@aplex.com.tw URL:...

  • Page 2: Revision History

    Revision History Reversion Date Description 2021/03/04 Official Version 2022/08/19 Delete Ch4 Driver Installation part information AVS-302 Palm-size System User Manual...

  • Page 3: Warning

    Electric Shock Hazard – Do not operate the machine with its back cover removed. There are dangerous high voltages inside. AVS-302 Palm-size System User Manual...

  • Page 4: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) AVS-302 Palm-size System User Manual...

  • Page 5: Safety Precautions

    ◆ Disconnect power when you change any hardware devices. For instance, when you connect a jumper or install any cards, a surge of power may damage the electronic components or the whole system. AVS-302 Palm-size System User Manual...

  • Page 6: Table Of Contents

    Packing List…………………………………….…………………………………………………....3 Safety Precautions…………………………………….…………….…..……………………....4 Chapter 1 Getting Started 1.1 Features……..…………………..………………………...…………………………..7 1.2 Specifications…..………………...………………………………………………….7 1.3 Dimensions……..…………………..……………………………………………...9 1.4 Brief Description of AVS-302 …………….…..…………………….……9 Chapter 2 Hardware 2.1 Motherboard Introduction……………………..……………………..11 2.2 Specifications…………………………..…………..………………………………11 2.3 Motherboard Dimensions….……..…………..……………………………12 2.4 Jumpers and Connectors Location……….……………………………...13 2.5 Jumpers Setting and Connectors…………..………………………..……14...
  • Page 7 Figure 2.3: Jumpers and Connectors Location-Board Bottom……………….13 Figure 4.1: Wall Mount of AVS-302……….….…..……..……………………………49 AVS-302 Palm-size System User Manual...

  • Page 8: Getting Started

    3 x USB 2.0(Type A) stack ports 1 x USB2.0 (Type A) stack port (internal) LAN(GT211V controller) 4 x GbE ports by RJ45 with Intel I210AT controller GPIO 1 x 8-bit GPIO(4 x DI+4 x DO) Storage Space AVS-302 Palm-size System User Manual...
  • Page 9 Net Weight(unit: Kg) 0.95 Environmental -20~70 °C Operating Temperature -40~85 °C Storage Temperature 10 to 90% @ 40 °C , non-condensing Storage Humidity Certification CE / FCC Class A Operating System Microsoft® Win10 IoT, Linux (TBD) Support AVS-302 Palm-size System User Manual...

  • Page 10: Dimensions

    USB 3.0 Type A and USB 2.0 Type A, LAN, VGA, HDMI, COM ports, and 1 x audio line-out for AVS-302. AVS-302 supports SATAII and mSATA connectors for storage use, and 9~36V DC wide-ranging power input. AVS-302 has 1x mPCIE slot for expansion and it is plating titanium gray aluminum heatsink and black steel chassis designed.

  • Page 11: Figure 1.2: Front View Of Avs-302

    Figure 1.2: Front view of AVS-302 Figure 1.3: Rear view of AVS-302 AVS-302 Palm-size System User Manual...

  • Page 12: Chapter 2 Hardware

    1 x RS232/RS422/RS485 DB9 connector 9Pin (COM1) Serial 1 x RS232 DB9 connector 9Pin (COM2) Audio Line out by Jack Expansion Bus 1 x mini-PCI-express connector(w/USB/SIM signal//woPCIE) Display Controller Integrated Intel HD Graphics 688/854 MHz (J1900) VGA Interface 1 x DB15 AVS-302 Palm-size System User Manual...

  • Page 13: Motherboard Dimensions

    Infineon’s Trusted Platform Module(TPM2.0, option) Operating: -20℃ to 70℃ Temperature Storage: -40℃ to 85℃ Humidity 10% - 90%, non-condensing, operating Meet CE/FCC Part15 class A EMI/EMS RoHS 2.3 Motherboard Dimension (Unit: mm) Figure 2.1: Motherboard SBC-7827 Dimensions AVS-302 Palm-size System User Manual...

  • Page 14: Jumpers And Connectors Location

    2.4 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom AVS-302 Palm-size System User Manual...

  • Page 15: Jumpers Setting And Connectors

    Power on the system again. d) When entering the POST screen, press the <DEL> key to enter CMOS Setup Utility to load optimal defaults. e) After the above operations, save changes and exit BIOS Setup. AVS-302 Palm-size System User Manual...
  • Page 16 Illegal shutdown has the risk of damaging the operating system or the machine. Repeated switching may affect the service life of the machine. The power switch button interface can be connected with the button switch through the cable. AVS-302 Palm-size System User Manual...
  • Page 17 COM cable connection. RS-232(Default) Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) AVS-302 Palm-size System User Manual...
  • Page 18 Signal Name 422_TX- 422_TX+ 422_RX+ 422_RX- Ground BIOS Setup： Advanced/NCT6106D Super IO Configuration/Serial Port 1 Configuration 【RS-422】 RS-485 : Pin# Signal Name 485- 485+ Ground BIOS Setup： Advanced/NCT6106D Super IO Configuration/Serial Port 1 Configuration 【RS-485】 AVS-302 Palm-size System User Manual...
  • Page 19 (Single stack USB type A), USB2.0 connector, it provides two USB ports via a dedicated USB cable, speed up to 480Mb/s. Each USB Type A Receptacle (2 ports) current limited value is 2.0A. If the external USB device current exceeds 2.0A, please separate connectors into different Receptacle. AVS-302 Palm-size System User Manual...
  • Page 20 2 Watt per channel output power. Pin# Signal Name +DC5V_S0 Ground Note: Output current of the connector must not be above 1A. 18. SATA2: (SATA 7P), SATA Connectors, one SATA connector is provided, SATA2 transfer speed up to 3.0Gb/s. AVS-302 Palm-size System User Manual...
  • Page 21 SIM Signal ● SMbus ● USB2.0 (USB4) ● 21. SIM1: (2.0mm Pitch 1x6 Pin Wafer Header), Support SIM Card devices Pin# Signal Name SIM_VCC Ground SIM_RST SIM_CLK SIM_IO 22. HDD/PWR: PWR: Power Indicator HDD: HDD Indicator AVS-302 Palm-size System User Manual...
  • Page 22 (2.0mm Pitch 1x4 Wafer Pin Header), Front Audio, Line Out can be connected to a headphone or amplifier. Line In is used for the connection of external audio source via a Line in cable. MIC is the port for microphone input audio. AVS-302 Palm-size System User Manual...
  • Page 23 Signal Name Pin# Pin# Signal Name GND_AUD LINE-OUT-L LINE-OUT-R FRONT_JD LINE_JD LINE-IN-L LINE-IN-R MIC-IN-L MIC-IN-R GND_AUD MIC1_JD AVS-302 Palm-size System User Manual...

  • Page 24: Bios Setup

    Press <DEL> or <ESC> to enter setup. After optimizing, exits CMOS Setup. 3.2 BIOS Setup Utility Press [Delete] key to enter BIOS Setup utility during POST, and then a main menu containing system summary information will appear. AVS-302 Palm-size System User Manual...

  • Page 25: Main Settings

    Administrator Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 AVS-302 Palm-size System User Manual...
  • Page 26 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. AVS-302 Palm-size System User Manual...

  • Page 27: Advanced Settings

    ►USB Configuration ►Platform Trust Technology ►Security Configuration ►Intel(R) i210 Gigabit Network Connection-- ►Intel(R) i210 Gigabit Network Connection-- ►Intel(R) i210 Gigabit Network Connection-- ►Intel(R) i210 Gigabit Network Connection-- Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. AVS-302 Palm-size System User Manual...
  • Page 28 IO=3F8h ； IRQ=4； Device Settings Change Settings [Auto] [IO=3F8h；IRQ=4] [IO=3F8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2F8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=3E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] [IO=2E8h ;IRQ=3,4,5,6,7,9,10,11,12 ;] COM1 Mode Selection [RS-232] [RS-485] [RS-422] Serial Port 2 Configuration Serial port [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 29 3.4.4 Intel® Smart Connect Technology ISCT Support [Enabled] [Disabled] 3.4.5 APM Configuration RTC Power On [Disabled] [Enabled] 3.4.6 CPU Configuration Socket 0 CPU Information CPU Thermal Configuration [Enabled] [Disabled] 3.4.7 PPM Configuration CPU c state Report [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 30 Super Debug [Disabled] Current Logical Processor [Disabled] Start P-State [P0] Step size [25%] Power Control Setting [CORE offlining] Performance Control Setting [CORE offlining] DPPM [Enabled] 3.4.9 IDE Configuration Serial-ATA(SATA) [Enabled] [Disabled] SATA Test Mode [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 31 [Disabled] Serial-ATA Port 1 [Enabled] [Disabled] SATA Port1 HotPlug [Enabled] [Disabled] SATA Port 0 Not Present SATA Port1 Not Present 3.4.10 Miscellaneous Configuration High Precision Timer [Enabled] [Disabled] Boot Timer with HPET Timer [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 32 SCC eMMC 4.5 HS200 Support [Disabled] [Enabled] eMMC Secure Erase [Disabled] [Enabled] SCC SDIO Support [Enabled] [Disabled] SCC SD Card Support [Enabled] [Disabled] SDR25 Support for SDCard [Disabled] DDR50 Support for SDCard [Enabled] MIPI HSI Support [Disabled] [Enabled] AVS-302 Palm-size System User Manual...
  • Page 33 LPSS I2C #4 Support [Disabled] [Enabled] LPSS I2C #5 Support [Disabled] [Enabled] LPSS I2C #6 Support [Disabled] [Enabled] LPSS I2C #7 Support [Disabled] [Enabled] I2C touch Device Address [AUTO] [0x4B] [0x4A] LPSS HSUART #1 Support [Disabled] [Enabled] AVS-302 Palm-size System User Manual...
  • Page 34 PMIC ACPI OBJECT [Disabled] [Enabled] PNP Setting [Disabled] [AUTO] [AX STEPPING] [BX STEPPING] Witt Setting [Disabled] [Enabled] 3.4.13 Network Stack Configuration Network Stack [Disabled] [Enabled] 3.4.14 CSM Configuration Compatibility Support Module Configuration CSM Support [Disabled] [Enabled] AVS-302 Palm-size System User Manual...
  • Page 35 [UEFI only] Option ROM execution Network [Do not launch] [UEFI] [Legacy] Storage [Do not launch] [UEFI] [Legacy] Video [Do not launch] [UEFI] [Legacy] Other PCI devices [UEFI] [Legacy] 3.4.15 SDIO Configuration SDIO Configuration [Auto] [DMA] [PIO] AVS-302 Palm-size System User Manual...
  • Page 36 [Disabled] [Enabled] USB hardware delays and time-outs: USB transfer time-out [1sec] [5sec] [10sec] [20sec] Device reset time-out [10sec] [20sec] [30sec] [40sec] Device power-up delay [Auto] [Manual] 3.4.17 Platform Trust Technology TPM Configuration fTPM [Disabled] [Enabled] AVS-302 Palm-size System User Manual...
  • Page 37 3.4.18 Security Configuration Intel® TXE Configuration Intel® Anti-Theft Technology Configuration Intel® AT [Disabled] [Enabled] Intel® AT Platform PBA [Disabled] [Enabled] Intel® AT Suspend Mode [Disabled] AVS-302 Palm-size System User Manual...

  • Page 38: Chipset Settings

    ESC Exit Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. 3.5.1 North Bridge ►Intel IGD Configuration GOP Configuration GOP Driver [Enabled] [Disabled] Intel IGD Configuration Integrated Graphics Device [Enabled] [Disabled] IGD Turbo Enable [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 39 ISP Enable/Disable [Enabled] [Disabled] ISP PCI Device Selection [Enabled] [Disabled] Vcc,Vnn Configuration for Power state2: Vcc_Vnn Config for Power state2 [Enabled] [Disabled] ►IGD – LCD Control Force Lid Status [ON] [OFF] [AUTO] ALS Support [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 40 This is to view the memory configuration information. 3.5.2 South Bridge ►Azalia HD Audio Audio Configuration LPE Audio Support [Enabled] [Disabled] Audio Controller [Enabled] [Disabled] Azalia VCi Enable [Enabled] [Disabled] Azalia Docking Support Enable [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 41 USB2 Link Power Management [Enabled] [Disabled] USB 2.0(ENCI) Support [Disabled] USB EHCI debug [Enabled] USB Per Port Control [Enabled] [Disabled] USB Port 0 [Enabled] [Disabled] USB Port 1 [Enabled] [Disabled] USB Port 2 [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 42 Reserved I/O PCI Express Port 1 [Enabled] [Disabled] Hot Plug [Enabled] [Disabled] Speed [Auto] Extra Bus Reserved Reserved Memory Reserved Memory Alignment Prefetchable Memory Prefetchable Memory Alignment Reserved I/O PCI Express Port 2 [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 43 Extra Bus Reserved Reserved Memory Reserved Memory Alignment Prefetchable Memory Prefetchable Memory Alignment Reserved I/O ►COM Port Configuration COM Port Configuration COM1 RS485 Resistance [Disabled] [Enabled] COM2 RS485 Resistance [Disabled] [Enabled] COM3 RS485 Resistance [Enabled] [Disabled] AVS-302 Palm-size System User Manual...
  • Page 44 [Disabled] COM10 RS485 Resistance [Enabled] [Disabled] High Precision Timer [Enabled] [Disabled] Restore AC Power Loss [Power off] [power on] [Last State] LCD PWM DC Mode [PWM] [DC] GPIO00-027 Mode [Input] [Output] GPIO00 -027 [High] [Low] AVS-302 Palm-size System User Manual...
  • Page 45 Serial IRQ Mode [Quiet] [Continuous] Global SMI Lock [Enabled] [Disabled] BIOS Read/Write Protection [Enabled] [Disabled] AVS-302 Palm-size System User Manual...

  • Page 46: Security Settings

    F2: Previous Values In the following range: F3:Optimized Defaults Minimum length F4:Save and Exit ESC Exit Maximum length Administrator Password User Password Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. 3.6.1 Administrator Password 3.6.2 User Password AVS-302 Palm-size System User Manual...

  • Page 47: Boot Settings

    Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. Setup Prompt Timeout Bootup Numlock State [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Disabled] [Enabled] Boot Option Priorities Boot Option #1 [UEFI:Built – in EFI … ] AVS-302 Palm-size System User Manual...

  • Page 48: Save & Exit Settings

    UEFI:Built – IN EFI Shell Launch EFI Shell from filesystem device Reset System with ME disable ModeMEUD000 Version 2.17.1246. Copyright (C) 2021 American Megatrends , Inc. Save & Exit Setup save Configuration and exit? [Yes] [No] AVS-302 Palm-size System User Manual...
  • Page 49 Restore the User Defaults to all the setup options? [Yes] [No] Boot Override UEFI: Built – in EFI Shell Launch EFI Shell from filesystem device WARNING Not Found [ok] Reset System with ME disable ModelMEUD000 AVS-302 Palm-size System User Manual...

  • Page 50: Chapter 4 Mounting Suggestions

    Chapter 4 Mounting Suggestions 4.1 Wall Mount 4.1.1 AVS-302 Wall Mount Figure 4.1 Wall Mount of AVS-302 AVS-302 Palm-size System User Manual...
