Grandhall THLS09ANG Operator's Manual

Liquid propane gas (lpg) totum heater natural gas (ng ) totum heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Liquid Propane Gas (LPG)
Totum Heater
Model THLS09ALP
Natural Gas (NG ) Totum Heater
Model THLS09ANG
FREE HELP
At Grand Hall we're the experts on this
product and trained to help you with:
Ÿ
Assembly questions
Ÿ
Heater operation
Ÿ
Replacement of damaged or missing parts
visit www.grandhall.com or call:
1- 877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of heater)
Operator's Manual
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this heater was assembled by you or
someone else, you must read this entire manual
before using your heater to ensure the heater is
properly assembled, installed and maintained.
Ÿ
Use your heater at least 3 feet away from any
wall or surface. Use your heater at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences and
overhangs or sources of ignition including pilot
lights on water heaters and live electrical appli-
ances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas heater in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air around
your gas heater housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your heater is lit. A lit heater can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80183003A - Date:2009/09/03
!
