Liquid Propane Gas (LPG) Heater
Model TH09ALP
FREE HELP
At Grand Hall we're the experts on this
product and trained to help you with:
Ÿ
Assembly questions
Ÿ
Heater operation
Ÿ
Replacement of damaged or missing parts
www.grandhall.com
visit
1- 877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL # __________________
(see silver CSA label on main body of heater)
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this heater was assembled by you or
someone else, you must read this entire manual
before using your heater to ensure the heater is
properly assembled, installed and maintained.
or call:
Ÿ
Use your heater at least 3 feet away from any
wall or surface. Use your heater at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences and
overhangs or sources of ignition including pilot
lights on water heaters and live electrical appli-
ances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR OUT-
DOOR USE ONLY.
Ÿ
Never use your gas heater in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air around
your gas heater housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your heater is lit. A lit heater can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Operator's Manual
WARNING
Manual # P80183001A - Date:2008/11/20
!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Grandhall TH09ALP
Summary of Contents for Grandhall TH09ALP
-
Page 1: Primary Safety Warnings
FREE HELP Ÿ Failure to comply with these instructions could At Grand Hall we're the experts on this result in a fire or explosion that could cause product and trained to help you with: serious bodily injury, death or property damage. -
Page 2: Table Of Contents
Table of Contents WARNING Primary Safety Warnings ......1-3 Pre-Assembly Instructions ......3 • Part Diagrams and Lists ......4-5 LPG models must be used with Liquid Propane Gas and the regulator assembly supplied. LP Gas Tank Installation ......6-8 Use &... -
Page 3: Pre-Assembly Instructions
Pre-Assembly Instructions For Your Safety PRE-ASSEMBLY Read and perform the following pre-assembly instructions: Required Tools • protective work gloves • protective eyewear • phillips head screwdriver You will need assistance from another person to handle the heater and other large, heavy parts. Open Lid of shipping carton and remove parts box and packing materials. -
Page 4: Part Diagrams And Lists
Parts Diagram for Model TH09ALP... - Page 5 4. Quantity of parts needed Important: Use only Grand Hall replacement parts. The use of any part that is not a Grand Hall replacement part can be dangerous and will also void your product warranty. Keep this Operator's Manual for convenient...
-
Page 6: Lp Gas Tank Installation
Replacement regulators and hose ings, (See Below Diagram) or any other sources assemblies must be those specified by Grand Hall. of ignition including pilot lights and live electrical Have your LP Gas dealer check the release valve after appliances. - Page 7 USE AND CARE INSTRUCTIONS NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Heater Ÿ Many retailers that sell heaters offer you the option of re- placing your empty LP Gas tank through an exchange ser- Turn your LP Gas Tank Valve clockwise to the vice.
- Page 8 USE AND CARE INSTRUCTIONS Check all Connections for LP Gas Leaks LP Gas Model only: Never test for leaks with a flame. Prior to first use, at Connect Regulator with Hose to your LP Gas Tank the beginning of each season, or every time your LP Gas tank is changed, you must check for gas leaks.
-
Page 9: Use & Care Instructions
USE AND CARE INSTRUCTIONS Heater Lighting Instructions Manually Lighting Your Heater By Paper Match 1. Before each use, check all hoses for cracks, nicks, To light your gas heater by match, insert a match cuts, burns or abrasions. If a hose is damaged in any into the Lighting Stick and follow steps 1 through 4 way, do not use your heater before replacing the of the Heater Lighting Instructions. -
Page 10: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the heater fails to light : Turn Control Knob to the OFF position. Turn gas off at source and turn Control Knob to OFF. Wait at least 5 minutes for gas to clear, then retry. -
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE To help maintain the finish of stainless steel follow Proper care and maintenance will keep your heater in top these cleaning procedures for the best results: operating condition and prolong its life. Follow these clean- ing procedures on a timely basis and your heater will stay After every use (after your heater has cooled down), wipe clean and operate with minimum effort. -
Page 12: Frequently Asked Questions
Question: Turn all Control Knob to the OFF position. Are the serial and model numbers of my heater listed somewhere for reference? Turn off the LP Gas tank at the tank valve. Answer: Disconnect regulator from LP Gas tank. The serial and model numbers are listed on a silver CSA label placed on the heater. - Page 13 Question: W eathering, extreme heat, machine oils used in the The Regulator and Hose supplied with my gas heater manufacturing process of stainless steel can cause stain- does not fit the older LP Gas tank I’ve used for years. less steel to turn tan in color. Although there are many Why not? factors which can affect the surface appearance of stain- less steel, they do not affect the integrity of the steel or the...
- Page 14 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and...
