Summary of Contents for schwa-medico VASOTRAIN

  • Page 1 VASOTRAIN PORTABLE BIOFEEDBACK EQUIPMENT Instruction Manual 507131...
  • Page 2 Start the first phase (calibration) with calm and easy breathing, until the preset CAL Setting Mode is changed to MEA in the display. The VasoTrain now runs in Training Mode MEA. Start the training now. On the left bottom display side you see the running time visible for your orientation.
  • Page 3: Table Of Contents

    Connection plugs at the upper case side ................ 6  Display details ........................ 7  5  Operation of VasoTrain ....................8  First steps before training / CAL Mode ................8  Start of training mode: MEA Mode .................. 9  Running training phase (MEA Mode) ................9 ...
  • Page 4: Introduction

    From this blood volume pulse BVP the relative vessel width is reckoned and shown to the patient as circle symbols and with acoustic tone pitches with the help of the VasoTrain. Hereby, the circles display the width of the vessel, more circles = wide vessel (dilatation), few circles (constriction).
  • Page 5: Safety Instructions

    Attention! The VasoTrain must only be used with the original BVP sensor! Never put a plug of another device into the sensor plug connection. The BVP sensor emits low infrared light, which cannot be recognized by the human eye and also is of low intensity and not harmful to the human eye.
  • Page 6: Switching Off

    Switching OFF Switch OFF the VasoTrain with . All display details shall disappear. Auto-OFF The VasoTrain switches OFF automatically with a signal tone, if not used for more than 5 minutes. Battery Replacement In case the battery status is too low, the device switches OFF automatically with a signal tone.
  • Page 7: Display Details

    Insert the plug properly into the regarding connection slot. Display details Automatic Setting Mode/Calibration Mode (CAL) Battery level Mode Lock symbol Signal intensity Amplifying factor Heart rate Training Mode/Measurement (MEA) Response via circle display Signal intensity Therapy duration VasoTrain | Instruction Manual...
  • Page 8: Operation Of Vasotrain

    8-10 seconds, possibly the signal is too low. In this case try to place the sensor at a position more suitable, or change the pressure of the headband. (If this also does not help, see trouble shooting). VasoTrain | Instruction Manual...
  • Page 9: Start Of Training Mode: Mea Mode

    All information, excluding battery status and ring display, can be faded out with the E key, if they irritate. Press E once more to fade in the information again. Switch OFF the device The device VasoTrain can be switched OFF at any time with the key. VasoTrain | Instruction Manual...
  • Page 10: Modes

    Setting Mode/Calibration Mode (CAL) By switching ON the device with the key, the VasoTrain is put into Setting Mode. This mode can also be reached with the P key. The amplifying factor shown on the display’s left bottom side is chosen by the device and cannot be changed manually.
  • Page 11: Report Mode

    Reach the Test Mode by switching ON the device and simultaneously press the , the E and left ▼ key. Battery level Ring display Display field 1 Acoustic signal OFF Bar display Locking symbol in CAL mode Display field 2 Display field 3 VasoTrain | Instruction Manual...
  • Page 12: General Advice

    EU directive 2002/96/EG. This means that the product at the end of its working life must be disposed freely at a communal recycling location. Do not dispose it in the household waste. It is an active deed for the benefit of the environment. VasoTrain | Instruction Manual...
  • Page 13: Interaction With Other Devices

    If, however, liquid shall enter the device, take out the batteries and let the device dry completely before reuse. Batteries Use with 3 AA (Mignon) batteries with the VasoTrain. The lowest agreeable voltage is 1.2 V. Battery type Volt...
  • Page 14: Storing

    Temperature: 10-30 °C Humidity: 20-90 % Avoid direct light, direct sunshine, and infrared light. Product Classification The VasoTrain is classified as medical product of class I due to the European Directive 93/42/EWG. Trouble Shooting Problem Possible Reason Suggestion for solution...
  • Page 15: Delivery Content

    140 g BVP Sensor Temperature Drift BVP Sensor 0.5 % per C° Infrared radiation wavelength 880 nm Axial Radiation intensity of pulse max 10 mW/sr Average Axial Radiation intensity max 0.3 mW/sr Sensor Frequency 1 kHz VasoTrain | Instruction Manual...
  • Page 16 Manufacturer Pierenkemper GmbH Hoernsheimer Eck 19 35578 Wetzlar Germany Distributor schwa-medico GmbH Wetzlarer Str. 41-43 35630 Ehringshausen Germany Tel. +49 64438333113 www.schwa-medico.com export@schwa-medico.de SPORÉCUP XTR2 | Instruction Manual...
