6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: (818)994-6498 / FAX: (818)994-6458
techsupport@louroe.com
/ www.louroe.com
DESCRIPTION
The Model A-ML is an omni-directional, low impedance, electret condenser microphone with
housed in a high impact ABS dome designed for ceiling or wall mounting. Normal pick-up pattern is approximately
15' from the microphone location, all directions, or within 30' diameter circle. The unit comes with 20' pre-made cable
with a stereo plug on one end that can be plug directly to the Audio Input of an IP camera.
Connections cable
®
INSTALLATION AND OPERATING INSTRUCTIONS
A-ML
Microphone
SPECIFICATIONS
Sensitivity
Frequency response
Output Impedance
Current drain
Supply voltage
Microphone housing
Dimensions
Weight
Shipping Weight
NOTE
A-ML Microphone is NOT recommended for outdoor use
or in areas with high moisture content.
A-ML
AUDIO MONITORING SYSTEM
-45 dB/pa
50 Hz to 8 kHz
1k
0.8mA
1.8Vdc to 4.5Vdc
High impact ABS
4"
dia x 1 ½ H
"
7.5 oz
1 lb
mic
level audio. It is
Microphone
Element
Housing and
pre-amp
A_ml_inst 12/14
Advertisement
Related Manuals for Louroe Electronics A-ML
Summary of Contents for Louroe Electronics A-ML
- Page 1 / www.louroe.com DESCRIPTION The Model A-ML is an omni-directional, low impedance, electret condenser microphone with level audio. It is housed in a high impact ABS dome designed for ceiling or wall mounting. Normal pick-up pattern is approximately 15' from the microphone location, all directions, or within 30' diameter circle. The unit comes with 20’ pre-made cable with a stereo plug on one end that can be plug directly to the Audio Input of an IP camera.
- Page 2 LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship. Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
