- Page 1 IS-100 UNIVERSAL IS-100 SMARTPHONE OPTICS ADAPTER Instructions for use Visit www.carson.com/universal to view our IS-100 tutorial video. IS-100...
-
Page 2: Table Of Contents
Table of Contents Circular Camera Front View Diagram Cutout Rear View Diagram Left Spring Right Inserting Phone Loaded Arm Phone Clamp Align & Lock Attaching to Optic 9-12 Troubleshooting Helpful Usage Tips Storage / Cleaning Information Other Uses Specifications Customer Service Front View... -
Page 3: Rear View Diagram
Optics Clamp Circular Camera Cutout Curved Arm Optics Clamp Release Bottom Phone Clamp Rear View... -
Page 4: Inserting Phone
Inserting Phone Fig.2 Fig.3 Fig.1 Place phone into device as Side and bottom of phone should Fig. 3 shows the incorrect shown in Fig. 1, using left side be flush and parallel to side/bottom phone position. of phone to push against left clamps. -
Page 5: Inserting Phone
Inserting Phone (cont.) Fig.5 Fig.4 Fig.5 shows the incorrect Position phone / case as flush as possible to adapter as phone position. shown in Fig. 4. -
Page 6: Align & Lock
Align & Lock Fig.6 Fig.7 Fig.8 Pull side clamp up to unlock Center the camera with the center of the Push clamp down to lock into place. and adjust. circular cutout on the back of the adapter. - Page 7 Align & Lock (cont.) Fig.9 Fig.10 Fig.11 Pull bottom clamp up to unlock Center the camera in the circular cutout Push clamp down to lock into place. and adjust. on the adapter.
-
Page 8: Align & Lock
Align & Lock (cont.) Fig.12 Fig.13 Fig.14 Fig.1 Make slight adjustments until camera is Figure 13 shows a properly To make sure camera is centered centered in the circular cutout on the aligned camera. properly, turn on the camera app. adapter (as shown in Fig. -
Page 9: Attaching To Optic
Attaching to Optic Fig.15 Fig.16 Fig.17 Before attaching to optic, make sure Press curved arms together to open grip Once opened, insert eyepiece eyepiece is twisted down to lowest as shown in Fig. 16. of optic into center of grips flush position. - Page 10 Attaching to Optic (cont.) Fig.18 Fig.19 Fig.20 Make sure adapter is flush to the Fig. 20 shows an adapter that is NOT flush If your hand is around the phone eyepiece of your optic (as shown in to the eyepiece. while pressing the curved arms you Fig.
- Page 11 Attaching to Optic (cont.) Fig.21 Fig.22 Phone can be positioned in either portrait or Once the optic is attached and the camera is turned on, the image may not landscape mode as shown in Fig. 21. take up the entire screen (see Fig. 22). This is normal and can be corrected by enlarging the image on the screen digitally or by inserting the included lens spacer into the adapter.
- Page 12 Attaching to Optic (cont.) Fig.21 Fig.22 To zoom in your image digitally, pinch and If your optic has long eye relief it may be necessary to increase the distance enlarge the phone screen (as shown in Fig. 21) between the camera and the optic to maximize the image size on your screen. until the image fills up your entire screen.
-
Page 13: Troubleshooting
Troubleshooting TROUBLESHOOTING G UIDE PROBLEM POSSIBLE C AUSE POSSIBLE S OLUTIONS • I S-‐100 a dapter i s d epressing s ide • L eft s ide c lamp i s c oming i n t o c ontact • ... -
Page 14: Helpful Usage Tips
Helpful Usage Tips Phone Tips: • When attaching adapter to optic, hold adapter from the back by the curved arms only. If your hand is around the phone while pressing the curved arms you may inadvertently push the camera out of alignment. •... -
Page 15: Storage/Cleaning Information
• Fits all popular iPhone and Samsung smart phones. Does not fit phablet type phones (ex. – Samsung Galaxy Note). Please go to www.carson.com/universal to view the most recent compatibility list. • Designed to work best with most phone cases. You do not need to remove your phone from its case. -
Page 16: Customer Service
Customer Service: We will be happy to help you with any problems you may experience with your Universal Smartphone Optics Adapter. Email us at info@carson.com or call toll-free at 1-800-967-8427. Carson Optical • 2070 5th Avenue • Ronkonkoma, NY 11779 www.carson.com info@carson.com Tel: 631-963-5000 Fax: 631-427-6749 iPhone® and iPod® are registered trademarks of Apple, Inc., registered in the U.S. and other countries. Samsung® is a registered trademark of Samsung, registered in the U.S. and other countries.
