Summary of Contents for Stabila LA-5P

  • Page 1 Laser LA-5P Operating instructions...
  • Page 3 3 x 1,5 V Mignon LR 6...
  • Page 4 > 5 m > 16‘5“...
  • Page 5 S > 5 m S > 20 ft 90° 90°...

  • Page 7: Main Components

    Operating instructions The STABILA LA-5P is a simple to operate 5 point laser for use horizontal and vertical levelling and also for use in a plumb line function. This laser can measure 90° angles with great precision. It is self-levelling in the range ±...
  • Page 9 Room length or distance The 90° angle between the level beam and square beam is out of calibration if between points A and C the distance between points A and E is: 10 m > 2,0 mm 20 m > 4,0 mm 32‘10“...

  • Page 10: Technical Data

    Measured Value Measured Value 3,0 mm 20 ft 1 / 8“ 10 m 6,0 mm 40 ft 9 / 32“ 15 m 9,0 mm 60 ft 7 / 16“ 20 m 12,0 mm 9 / 16“ 80 ft Technical data Laser type: Red diode laser, wavelength 635 nm Output :...
