- Page 1 pro+ Vac & Steam 2 in 1 Hard floor Cleaner User Guide Model No: ASVC4001 For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com IMPORTANT: RETAIN FOR FUTURE REFERENCE...
-
Page 2: Table Of Contents
……………………………………… Connection to the mains supply ……………………………………… Thank you for purchasing your Abode Vac & Steam. Convert from Vac to Steam Mop in just seconds. With a swivel head for flexible cleaning and an ergonomic handle for comfort, cleaning your hard floors has never been so easy. -
Page 3: Safety Instructions
Safety instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to electrical parts. - Page 4 Safety instructions • Unplug from power outlet when not in use. Do not leave steam mop unattended while plugged in. • Do not use with damaged cord or plug. • Do not immerse in water or other liquids for cleaning. •...
- Page 5 Safety instructions • Do not use cleaner in an enclosed space filled with vapour given off by oil-based paint, paint thinner, some moth proofing substances, flammable dust, or other explosive or toxic vapors. • Do not use on leather, wax polished furniture or floors, synthetic fabrics, velvet or other delicate, steam-sensitive materials.
- Page 6 Safety instructions • Never place your fingers or other objects into any part of the cleaner. Be aware that loose clothing or hair may become trapped in the cleaner if improperly used. • Before use ensure that all of the air vents of the cleaner are clear and there is no restriction of air flow.
-
Page 7: Steam Cleaner Feature Diagram
Steam cleaner feature diagram Handle Dust cup filter Mop pad Cord holder Dust cup Water cup Water tank Power cord Screw Exhaust filter On/off dial Steam base... -
Page 8: Steam Cleaner Assembly
Steam cleaner assembly Before using your steam mop: Remove all packaging and lay out the separate components. Check the steam mop after unpacking for any visual damage such as: • Misaligned or damaged parts • Damage to the main body and separate components •... -
Page 9: Mode Controls
Mode controls The Abode Vac & Steam has 2 operating modes: Vacuum Mode Steam Mode Avoid vacuuming with the steam base attached. Avoid vacuuming with the steam base attached. Move the black marker from the central ‘off’ position, twisting the... -
Page 10: Vacuum Mode
Vacuum mode Once the handle is assembled, pull and twist the cord holder to unwrap the cord. Plug the unit into a mains socket and turn the power on. Move the black marker from the central ‘off’ position, twisting the dial clockwise for vacuum function. - Page 11 Vacuum mode Storage 1. Lightly place your foot on the top of the unit base. Tilt the unit forward to the upright position. 2. Move the black marker from the vacuum position to the central ‘off’ position, twisting the dial anticlockwise. 3.
- Page 12 Vacuum mode Emptying the dust cup Press the clip at the bottom of the canister upwards. Pull the dust cup out and down. Twist dust cup cover anticlockwise to open and lift upwards to remove. Tip canister over bin and tap the side to empty.
-
Page 13: Steam Mode
Steam mode Place the microfibre pad on to the base of the unit, lining up the velcro to secure. Note: You must attach the steam frame and pad to the cleaner when using the steam function. Place the cleaner in an upright position in to the steam frame and secure. - Page 14 Steam mode Once the handle is inserted, steam pad attached and water filled, pull and twist the cord holder to unwrap the cord. Plug the unit into a mains socket and turn the power on. Move the black marker from the central ‘off’...
- Page 15 Steam mode Storage 1. Lightly place your foot on the top of the unit base. Tilt the unit to the upright position. 2. Move the black marker from the steam position to the central ‘off’ position, twisting the dial clockwise. 3.
-
Page 16: Cleaning And Care
Cleaning and care Before you clean the appliance, disconnect the mains plug from the wall socket. To clean the exterior of the device, use a damp, soft cloth and mild detergent. NEVER IMMERSE THE STEAM MOP IN WATER. When wiping off the main body, do not allow moisture in the area around the on/off dial. -
Page 17: Dust Cup Filter
Care of dust cup filters Ensure the unit is unplugged and the on/off dial is centred. Once the dust cup is removed, lift the filter frame out of the top and remove the two filter layers from the frame filter. Rinse the two filters thoroughly in lukewarm water. -
Page 18: Problem Solving
Problem Solving PROBLEM POTENTIAL REASON POSSIBLE SOLUTION 1. The screw is missing 1. Contact customer services for spare parts. Cannot assemble handle 2. The hanlde is loose 2. Have you tightened the screw with a (unplug before screwdriver? Ensure it is fully tightened. assembling) 3. - Page 19 Problem Solving PROBLEM POTENTIAL REASON POSSIBLE SOLUTION 1. Difficult to remove dust 1. Press and hold in clip at the bottom of the dust cup and filter. cup and pull outwards. Remove dust cup cover by twisting anticlockwise and lifting. To remove filter, Difficulty removing parts lift filter frame from the top of the dust cup cover and remove the 2 filter layers.
- Page 20 Problem Solving PROBLEM POTENTIAL REASON POSSIBLE SOLUTION 1. The flap on the main 1. Close the flap of the water tank on the main body has not been closed body, fully securing until it 'clicks'. properly. The unit is leaking 2.
-
Page 21: Guarantee
Guarantee This product is guaranteed for 12 months from the date of the original purchase. If any defect arises due to faulty materials or workmanship the faulty product must be returned to the place of purchase. Refund or replacement is at the discretion of the retailer. The following conditions apply: •... -
Page 22: Customer Services
Customer services Attach your receipt to this page for proof of purchase. We’re here should you need us For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com Produced for: G2S Limited... -
Page 23: Spare Parts
Spare parts Steam base Microfibre mop pads Dust cup Water cup Dust cup filter Screw We’re here should you need us. For Customer Services & Spare Parts please call 0845 209 7461 Opening times: Monday - Friday 8am – 6pm & Saturday 9am – 1pm Or visit us at www.productcareuk.com... -
Page 24: Connection To The Mains Supply
Connection to the mains supply WARNING- THIS APPLIANCE MUST BE EARTHED This appliance is designed to operate from a mains supply of AC230V - 240V ~ 50/60HZ. Check that the voltage marked on the product corresponds with your supply voltage. This product is fitted with a 13A plug complying with BS1363. - Page 25 Connection to the mains supply For UK use only – Plug fitting details (where applicable): As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The GREEN/YELLOW wire is the EARTH and must be connected to the terminal which is marked with the letter E or by the earth symbol or...
- Page 26 ASVC4001...
