  • Page 1 Copyright (c) by Foxit Software Company, 2004 - 2007 For Evaluation Only. For Evaluation Only. For Evaluation Only. For Evaluation Only. For Evaluation Only. PA20-TOY iPod to Toyota / Lexus car stereo Interface to Toyota / Lexus car stereo Interface with song title display with song title display...
  • Page 2 For Evaluation Only. For Evaluation Only. Thank you for purchasing product. This manual describes the functions and operation of PA20-TOY interface for Toyota cars. Please read this manual before installing the product to your vehicle. !!IMPORTANT!! It is strongly recommended that the unit is installed in an accessible location, so that it can later be easily reset or upgraded.
  • Page 3 NOTE 1: To display TEXT information of song on some of the Tundra, Avalon and Solara radio, PA20-TOY should be configured to the SAT port of radio. Please see the DIP switch table in section 2-5 of this manual. NOTE 2:...
  • Page 4 NOT applicable to Hybrid Mode. 2-4 RCA AUX INPUT Besides , PA20-TOY also can connect a second audio source to radio. Connecting the second audio source to the RCA jack labeled AUX INPUT. AUX input is enabled by setting the DIP switch at the side of this adaptor should be at ON position.

  • Page 5: Wire Connection

    WIRE CONNECTION Step 1- Remove radio from the dash. Step 2- Plug the round din plug of the CAS-TYi to PA20-TOY interface adapter box where it is labeled "RADIO" Step 3- Plug the other end of CAS-TYi cable to the receptor at back of radio. (For some of recent year models, plug CAS-TA to the back of radio and connect CAS-TYi to the other end of CAS-TA.)
  • Page 6 WARNING!! Use only the connection cable which comes with PA20-TOY interface adaptor. Connection cables from other sources may look similar, but they may damage your 4-POSITION DIP SWITCH ON: when switch is at bottom position CONNECT TO RADIO FRONT VIEW...
  • Page 7 DISC 6: TOYOTA6... DISC 7: ALL SONGS on The naming of designated Toyota Playlists in iTune for PA20-TOY interface must be exactly as shown. Toyota must be in capital letters and there can be no spaces between Toyota text and number.
  • Page 8 For Evaluation Only. For Evaluation Only. For Evaluation Only. If no designated Toyota Playlists are created, PA20-TOY adapter automatically relates to the first five Playlists on to DISC number 1 to 6 regardless Playlist naming. If less than six designated Toyota Playlists are created, PA20-TOY adapter automatically fills...
  • Page 9 1, and the continue by increments of 10 (i, e, 19, 29, 1, 11..) When PA20-TOY is configured to SAT port. press on Fast Forward button starts the 10 track jump and requires a second on the FF button to stop the track jump, To stop the fast retreal, a second press on Fast Rewind button is required.
