E N G L I S H
Large screws and hard workpiece materials require a
higher torque setting than small screws and soft
workpiece materials. The collar has a wide range of
settings to suit your application.
For drilling in wood, metal and plastics, set the
N
collar (3) to the drilling position by aligning the
symbol
with the marking (24).
HP148F2/HP188F2:
N
For drilling in masonry, set the collar (3) to the
hammer drilling position by aligning the
symbol
with the marking (24).
For screwdriving, set the collar to the desired
N
setting. If you do not yet know the appropriate
setting, proceed as follows:
Set the collar (3) to the lowest torque setting.
N
Tighten the first screw.
N
If the clutch ratchets before the desired
N
result is achieved, increase the collar setting
and continue tightening the screw.
Repeat until you reach the correct setting.
Use this setting for the remaining screws.
Two-gear selector (fig. I)
For drilling in steel and for screwdriving
N
applications, slide the two-gear selector (5)
towards the front of the tool (1st gear).
For drilling in materials other than steel, slide
N
the two-gear selector (5) towards the rear of
the tool (2nd gear).
Drilling/screwdriving (fig. A)
Select forward or reverse rotation using the
N
forward/reverse slider (2).
To switch the tool on, press the switch (1).
N
The tool speed depends on how far you press
the switch.
To switch the tool off, release the switch.
N
Hints for optimum use
Drilling
Always apply a light pressure in a straight line
N
with the drill bit.
Just before the drill tip breaks through the
N
other side of the workpiece, decrease pressure
on the tool.
Use a block of wood to back up workpieces
N
that may splinter.
12
Use spade bits when drilling large diameter
N
holes in wood.
Use HSS drill bits when drilling in metal.
N
Use masonry bits when drilling in soft masonry.
N
Use a lubricant when drilling metals other than
N
cast iron and brass.
Make an indentation using a centre punch at
N
the centre of the hole to be drilled in order to
improve accuracy.
Screwdriving
Always use the correct type and size of
N
screwdriver bit.
If screws are difficult to tighten, try applying a
N
small amount of washing liquid or soap as a
lubricant.
Always hold the tool and screwdriver bit in a
N
straight line with the screw.

MAINTENANCE

Your Black & Decker tool has been designed to
operate over a long period of time with a
minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and
regular cleaning.
Your charger does not require any maintenance
apart from regular cleaning.
Before performing any maintenance on
the tool, remove the battery from the tool.
Unplug the charger before cleaning it.
N
Regularly clean the ventilation slots in your tool
N
and charger using a soft brush or dry cloth.
Regularly clean the motor housing using a
N
damp cloth. Do not use any abrasive or
solvent-based cleaner.
Regularly open the chuck and tap it to remove
N
any dust from the interior.
