Portable Unit Heater
Model 84606 240V~60Hz 4000 WATTS
READ AND SAVE THESE INSTRUCTIONS
Please read these instructions carefully and keep for
future reference
appliances, basic precautions should always be followed to reduce the risk of
fire, electric shock, and injury to persons, including the following.
1．
Read all instruction before using this heater.
2．
Connect to property grounded outlets only. Check heater voltage
and amperage on back of heater to make sure it agree with the
electric service supplied.
3．
Do not use outdoors.
4．
This heater is not intended for user in wet or damp locations, never
locate heater where it may fall into a bathtub or other water
container
5．
This heater is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. Always use handles when moving this heater.
Keep combustible materials, such as furniture, pillows, bedding,
84606—Instruction-English
INSTRUCTION MANUAL
IMPORTANT
INSTRUCTIONS
Read Carefully-These instructions contain vital
information for the proper installation, use and
efficient operation of the heater. Carefully read
PLUG
TYPE
these instructions before installation, operation,
20 amp 240V
NEMA # 6 - 20P
or cleaning of the heater. User should always
For Model No: EH - 4606 (4000W)
following this instruction to reduce the risk of fire,
electric shock, and injury to persons.
WARNING!
1 of 5
When
using
Printed in China
SAFETY
electrical
Advertisement
Table of Contents
Related Manuals for Flowpro 84606
Summary of Contents for Flowpro 84606
- Page 1 Portable Unit Heater Model 84606 240V~60Hz 4000 WATTS INSTRUCTION MANUAL READ AND SAVE THESE INSTRUCTIONS Please read these instructions carefully and keep for future reference IMPORTANT SAFETY INSTRUCTIONS Read Carefully-These instructions contain vital information for the proper installation, use and efficient operation of the heater.
- Page 2 Always unplug heater when not in use. ASSEMBLY This Heater has been pre-assembly in factory. FEATURES LIVE POWER SIGNAL LIGHT ( POWER ON LIGHT)—Glows amber when unit is plugged in. Thermostat Control: Off, Low, High 84606—Instruction-English 2 of 5 Printed in China...
- Page 3 3. Turn the “ THERMOSTAT” Control clockwise(right) to the “HIGH” setting until the knob stops. The heater should begin heating and the fan should start to blow warm air. 84606—Instruction-English 3 of 5 Printed in China...
- Page 4 Use a dry cloth to clean the external surfaces of the heater. If heater is used in very dusty location, use a vacuum cleaner dust brush or high pressure air to remove dust and other foreign material from the grilles 84606—Instruction-English 4 of 5 Printed in China...
- Page 5 This heater does not disassemble. • The motor is factory lubricated for life, and will require no further lubrication. SPECIFICATIONS Model NO. 84606 Voltage /Frequency 240V ~ 60 Hz Output Power (W) & Electric Current (A) 4000W / 16.7A NEMA Code Receptacle...
