INTREPID TRDV
BECKETT BURNER DATA — BURNER MODEL NX

Beckett

Boiler Model
Model
TRDV-30-0.85 NX
TRDV-30-1.00 NX
TRDV-30-1.10 NX
HEAD SETTING
1. Loosen screw and move the index marker until it is aligned
with the correct index number. See Figure 15.
2. Retighten the retaining screw.
Note:
The air setting depends on the setting of the head setting.
80 mm
(3-5/32")
75 mm (2-15/16")
Figure 11
6 mm (1/4")
MINIMUM
89 mm
(3-1/2")
Figure 13
IMPORTANT
The air/oil ratio depends on accurate setting of the head and air band settings. Be careful when making these adjustments as an
incorrect setting will result in an unsatisfactory operation.
Firing Rate
No. 2 Oil
L/Hr GPH
L/Hr
3.21 0.85
3.78 1.00
4.16 1.10
80 mm
(3-5/32")
75 mm
(2-15/16")
170 mm (6-11/16")
329 mm (12-15/16")
179 mm (7-1/16")
Nozzles
Size
Type
GPH
2.46 0.65 60°B
2.94 0.75 60°B
3.22 0.85 60°B
38 mm
(1-1/2")
± .8mm
(± 1/32)
12 mm (15/32")
± .8mm(± 1/32)
4 mm (5/32") ± .8mm(± 1/32)
Figure 12
Use Riello
Universal
mounting
flange
#3005855
(S/F Part
#430161)
and
Slant/Fin
burner
collar Part
#430010
Figure 14
Figure 15
Oil Pump
Pressure
Setting
Mfg.
Delavan 175
Delavan 175
Delavan 175
24 mm (3/32")
± .8mm(± 1/32)
HEAD SETTING
ADJUSTMENT
THUMB NUT
11
Head
Setting
2.5
2.5
3.0
3 mm (1/8")
± .8mm
(± 1/32)
6 mm (1/4")
± .8mm
(± 1/32)
Flush with
insulation
to a
maximum
recess of
no more
than 6mm
(1/4")
HEAD
ADJUSTMENT
SCREW
