Eliminator Lighting Electro Disc LED Operating Instructions

Electro
Disc LED
CAUTION! Please read and under-
stand these instructions before
installing or operating this unit.
Operating Instructions:
The Electro Disc LED has been tested at the factory, there is no assembly required. The unit is ready
to be plugged into a power outlet. This unit is a 4 channel DMX intelligent LED wash. It has 6 oper-
ating modes; Static Color mode, Color Change mode, Color Fade mode, Auto Run mode, Sound
Active mode, or DMX mode. The Electro Disc LED can be used as a stand alone unit or in a master-
slave configuration.
Power Cord Daisy Chaining: With this feature you can connect the fixtures to one another using the
IEC input and output sockets. The quantity that can be connected is 40 fixtures maximum. After 40
fixtures you will need to use a new power outlet. They must be the same fixtures. DO NOT mix fixtures.
1 Year Limited Warranty:
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

SPECIFICATIONS:

Model:
Voltage:
LEDs:
Beam Angle:
Power Consumption:
Weight:
Size:
Fuse:
Power Cord Daisy Chain: 40 Fixtures Max.
Working Position:
Duty Cycle:
DMX Channels:
Colors:
Warranty:
Caution! Never open unit when in use. Always
disconnect main power before replacing fuse.
Remember to always replace with the exact same
type fuse.
Eliminator Lighting warranty is valid from the date of purchase. Our
Electro Disc LED
100V-240V 50/60Hz
107 x 10mm LEDs (36
Red, 36 Green, & 35 Blue)
30 Degrees
14W
3lbs./ 1.2kgs.
10.25"(L) x 9.5"(W) x 4"(H)
1 Amp
Any Safe position
None
4 DMX Channels
Multiple Colors
1 Year
