Snap-On 870017 Instruction Manual
  1. Manuals
  2. Brands
  3. Snap-On Manuals
  4. Nail Gun
  5. 870017
  6. Instruction manual

Snap-On 870017 Instruction Manual

18 gauge 1-5/8" narrow crown staple
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
FOR CUSTOMER SERVICE
PARA EL SERVICIO
PARA EL CONSUMIDOR
1-888-278-8092
Printed in Taiwan
®
®
SNAP-ON
IS A TRADEMARK LICENSED BY SNAP-ON
CORP.,
U.S.A., WHICH DOES NOT MANUFACTURE OR
DISTRIBUTE THIS PRODUCT. CONSUMER INQUIRES SHOULD BE
DIRECTED TO:
©COPYRIGHT 2007 ALLTRADE TOOLS, LLC.
1431 VIA PLATA
LONG BEACH, CA 90810-1462 USA
870017 – 18 Gauge 1-5/8" Stapler_Rev 9/6/07
18 GAUGE 1-5/8" NARROW CROWN STAPLER

INSTRUCTION MANUAL

THIS
MANUAL
CONTAINS
IMPORTANT
MAINTENANCE AND STORAGE OF THIS PRODUCT. BEFORE USE, READ CAREFULLY AND
UNDERSTAND ALL CAUTIONS, WARNINGS, INSTRUCTIONS AND PRODUCT LABELS. FAILURE TO DO SO
COULD RESULT IN SERIOUS PERSONAL INJURY AND/OR PROPERTY DAMAGE.
IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR SNAP-ON PRODUCT, DO
NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SERVICE DEPARTMENT AT
1-888-278-8092. BEFORE YOU CALL, HAVE THE FOLLOWING INFORMATION AVAILABLE: MODEL No.,
DATE PURCHASED AND STORE LOCATION.
MODEL #870017
INFORMATION
REGARDING
SAFETY, OPERATION,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 870017 and is the answer not in the manual?

Questions and answers

Related Manuals for Snap-On 870017

Summary of Contents for Snap-On 870017

  • Page 1: Instruction Manual

    PARA EL SERVICIO DISTRIBUTE THIS PRODUCT. CONSUMER INQUIRES SHOULD BE PARA EL CONSUMIDOR IF YOU SHOULD HAVE ANY QUESTIONS OR EXPERIENCE A PROBLEM WITH YOUR SNAP-ON PRODUCT, DO DIRECTED TO: ©COPYRIGHT 2007 ALLTRADE TOOLS, LLC. NOT RETURN THIS PRODUCT TO THE STORE. PLEASE CALL OUR CUSTOMER SERVICE DEPARTMENT AT...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONGRATULATIONS! Thanks for choosing this product. Our aim is to provide you with the highest quality prod- CONGRATULATIONS! ......... 2 ucts, and we want you to be totally satisfied with your product and our Customer Service.

  • Page 3: Important Information About This Manual

    IMPORTANT INFORMATION ABOUT THIS MANUAL CAUTION used without the safety alert symbol indicates a potentially hazardous situation which, Improper maintenance and operation are responsible for the majority of accidents if not avoided, may result in property damage. involving air staplers. The largest portion of these could be prevented by recogniz- ing the basic safety rules and precautions.
  • Page 4 Always use hearing protection to protect your ears against Do not connect air stapler to an air source capable of generating hearing loss due to exhaust noise. Always wear proper safe- more than 200 psi (14.06 kg/cm G). Over-pressurizing the air sta- ty glasses to prevent injuries to the eyes from fragments of pler will result in bursting, abnormal operation or breakage of the the work piece, defective staples or other debris caused by using the air sta-...

  • Page 5: Functional Description

    COMPONENT INSTALLATION Thoroughly clean and maintain the air stapler after every use. Lubricate mov- Never use a non-relieving air coupler with the air stapler. ing parts to prevent rust and minimize friction related wear. Wipe down the Always use couplers that release any built-up charge in the air stapler’s firing entire tool and remove all dust from the moving parts.

  • Page 6: Operating The Air Stapler

    To improve the connection between the quick disconnect and air stapler, and to help OPERATION IN SINGLE SEQUENTIAL ACTUATION MODE prevent oxidation, apply PTFE tape or joint compound to the connector threads To select the Single Sequential Actuation Mode (see before insertion.

  • Page 7: Adjusting Depth Of Stapling

    To select Contact Sequential Actuation Mode (see Figure 2): 1. Press and hold Actuation Selector embedded in the Always disconnect the air stapler before making any trigger. adjustments to the staple depth knob. 2. Rotate Actuation Selector up to the Contact USING THE HOOK Sequential Actuation (TTT).

  • Page 8: Using The No-Mar Nosepiece

    6. Select Single Sequential Actuation Operation. Check for leaks. Without pulling USING THE NO-MAR NOSEPIECE the trigger, press the work piece contact against the work piece. The tool MUST NOT operate. Holding the tool away from the work piece, pull trigger Always disconnect the air hose before attaching the and hold for 5 seconds.

  • Page 9: Changing Direction Of Exhaust Air

    OVERALL MAINTENANCE OF AIR STAPLER CHANGING DIRECTION OF EXHAUST AIR The direction of exhaust air on the air stapler can Always disconnect the air hose from air stapler before be directed 360˚ degrees by placing hand on attempting any type of maintenance or visual inspection of tool. exhaust cover and turning.

  • Page 10: Mandatory Maintenance

    PROBLEM POSSIBLE CAUSE SOLUTION MANDATORY MAINTENANCE Increase air pressure, Ensure proper air pres- All maintenance and repairs should be performed by an sure is being used. Do not exceed 120 psig authorized repair facility. Call 1-888-278-8092 to obtain a list of repair facil- (8.3 bars, 8.5 kgf/cm2) Weak drive.

  • Page 11: Parts Diagram

    PARTS DIAGRAM PARTS LIST ITEM NO. PART NO. DESCRIPTION A0000-1211 Nylon Screw M4*8 A0005-0691 Washer 12*1 A0304-0651 Exhaust Cover A0200-2471 O-Ring 7.59*2.62 B0000-0051 Screw Set M5*20 A0000-0091 Screw M5*20 A0005-0031 Washer #5*1.21 A0301-1551 Cap, Top A0311-0451 Seal, Air A0200-0221 O-Ring 15*2.5 A0205-0651 Gasket A0100-0631...
  • Page 12 A0711-1051 Release Catch (A) A0005-0311 Pin Retainer 5.5*2 A0000-0861 Screw M4*30 A0011-0161 Spring Pin 3*24 A07100411 Spacer A0313-0631 Main Body Bumper L(Snap-on) A0000-0041 Screw M4*20 A0313-0641 Main Body Bumper R(Snap-on) A0710-0401 Spacer A0006-0411 A0712-0491 Release Catch Cover A0005-0291 Pin Retainer 6*2.9...

  • Page 13: Specifications

    Alltrade in writing. Under no circumstances shall purchaser of the accompanying SNAP-ON™ portable air tool and no one else all Alltrade bear any responsibility for loss of the unit, loss of time or rental, inconven- parts of the product (except those parts referred to below which are specifically ience, commercial loss, or consequential damages.
  • Page 14 TIVE(S) HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH DAMAGES. IN NO EVENT, WHETHER BECAUSE OF A BREACH OF CONTRACT, WARRANTY, TORT The use of other than genuine Snap-On™ Repair Parts will VOID the warranty. (INCLUDING NEGLIGENCE) OR OTHERWISE, SHALL ALLTRADE'S AND/OR ITS WARRANTY DISCLAIMERS REPRESENTATIVE (S) LIABILITY EXCEED THE PRICE OF THE PRODUCT.

Table of Contents
