- Page 1 WARRANTY YEARS ERB905D 3mm PLANER SFX-ERB905D-M-050608.indd 1 2005-6-9 9:30:55...
- Page 2 SFX-ERB905D-M-050608.indd 2 2005-6-9 9:30:55...
- Page 3 This guarantee does not affect your statutory rights.This guarantee is only valid in the UK. For further technical advice, spare parts or repair service (outside of guarantee) please contact the customer helpline number on 0845 607 6380 3mm PLANER SFX-ERB905D-M-050608.indd 3 2005-6-9 9:30:55...
-
Page 4: Safety Instructions
Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or SFX-ERB905D-M-050608.indd 4 2005-6-9 9:30:56... - Page 5 2.Ensure your mains supply voltage is the same as indicated on the rating plate. 3.Your tool is double insulated for additional protection against a possible electrical insulation failure within the tool. 4.Always check walls, floors and ceilings to avoid hidden power cables and pipes. 3mm PLANER SFX-ERB905D-M-050608.indd 5 2005-6-9 9:30:56...
- Page 6 Goggles / Safety Spectacles, Ear defenders (essential with tools with a noise rating of over 85 dbA), Gloves and face masks. In all cases ensure that the safety equipment is in good condition . SYMBOLS Read the manual Wear gloves Warning Wear dust mask,eye & ear protection SFX-ERB905D-M-050608.indd 6 2005-6-9 9:30:57...
- Page 7 10. HEIGHT ADJUSTMENT SCREWS (See Fig 6) 11. BELT COVER 12. SMALL PULLEY (See Fig 7) 13. LARGE PULLEY (See Fig 7) 14. BASEPLATE 15. V-GROOVE 16. REBATE DEPTH GAUGE 17. REBATE PARALLEL GUIDE 18. SPANNER 3mm PLANER SFX-ERB905D-M-050608.indd 7 2005-6-9 9:30:58...
-
Page 8: Technical Data
Typical weighted vibration 7.9m/s ACCESSORIES Spanner Dust bag Parallel guide & rebate depth gauge 1set Your planer requires two 82mm blades and two blades are supplied ready fitted. Only use reversible twin cutting blades which cannot be reground. SFX-ERB905D-M-050608.indd 8 2005-6-9 9:30:59... -
Page 9: Operating Instructions
Your blades have two cutting sides and are reversible.To reverse the blades or fit new blades the operation is the same. Remove the plug from the mains socket. Using the spanner provided Fig 4 3mm PLANER SFX-ERB905D-M-050608.indd 9 2005-6-9 9:31:01... - Page 10 To empty, open the zip on the rear of the dust bag. 9.EXTERNAL DUST EXTRACTION The exhaust outlet is best connected to a suitable external dust extraction machine e.g. vacuum cleaner. Fig 7 SFX-ERB905D-M-050608.indd 10 2005-6-9 9:31:03...
-
Page 11: Maintenance
Never use water or chemical cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all Fig D 3mm PLANER SFX-ERB905D-M-050608.indd 11 2005-6-9 9:31:06... -
Page 12: Environment Protection
L. A 13AMP (BS1363 or BS1363/A) plug must be used and a 13 AMP fuse must be fitted. 13 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER SLEEVE CABLE GRIP SFX-ERB905D-M-050608.indd 12 2005-6-9 9:31:08... -
Page 13: Declaration Of Conformity
98/37 EC –Machinery Directive Standards and technical specifications referred to: EN 60745-1:2003/+A1:2003 EN 60745-2-14:2003 EN 55014-1:2000/+A1:2001/+A2:2002 EN 55014-2:1997/+A1:2001 EN 61000-3-2:2000 EN 61000-3-3:1995/+A1:2001 Authorised Signatory Date: 03/15/05 Signature: Name: Peter Harries Screwfix Direct Ltd Quality Manager 2005 3mm PLANER SFX-ERB905D-M-050608.indd 13 2005-6-9 9:31:08... - Page 14 SFX-ERB905D-M-050608.indd 14 2005-6-9 9:31:09...
- Page 15 3mm PLANER SFX-ERB905D-M-050608.indd 15 2005-6-9 9:31:09...
- Page 16 SFX-ERB905D-M-050608.indd 16 2005-6-9 9:31:09...
