Service Manual
Service Manual
Service Manual
Service Manual
DJ-V57
Specifications
Circuit Description
Parts List
PC Board View
Adjustment
Schematic Diagram
Block Diagram
Exploded View
ALINCO, INC.
www.ALINCO.ru

Advertisement

loading
Need help?

Need help?

Do you have a question about the DJ-V57 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alinco DJ-V57

  • Page 1 Service Manual Service Manual Service Manual Service Manual DJ-V57 Specifications Circuit Description Parts List PC Board View Adjustment Schematic Diagram Block Diagram Exploded View ALINCO, INC. www.ALINCO.ru...
  • Page 2 SPECIFICATIONS DJ-V57 SPECIFICATIONS DJ-V57 SPECIFICATIONS DJ-V57 SPECIFICATIONS DJ-V57 <GRNERAL> 136.000~173.995MHz *144.000~145.995MHz TX Frequency range 400.000~479.995MHz *430.000~439.995MHz 136.000~173.995MHz RX Frequency range 400.000~511.995MHz Mode F3E(FM) Channel steps 5、10、12.5、15、20、25 & 30kHz 200 channels, 2 CALL channel Memory channels Antenna connector 50Ω(unbalanced) Frequency stability ±2.5ppm...
  • Page 3 DJ-V57 CIRCUIT DESCRIPTION [Reception] 1. RX Method: Double Conversion Super Heterodyne 1st IF: 38.85 MHz 2nd IF: 450 KHz 2. Front End [VHF] The signal input from antenna passes through the low pass filter, and then it is amplified at RF amplifier Q117. The amplified signal is led to band pass filter and band switch D132, then input to the mixer Q120.
  • Page 4 5. Squelch The AF signal from pin 9 of IC105 is input to pin 8 of IC105. The input signal is output from pin 14 of IC105 passing through the noise filter amplifier and rectifier circuits inside of IC105. The rectified signal is input to the A/D port pin 82 of microcomputer IC109.
  • Page 5 result of phase comparison, the pulse signal is output from the charge pump output of pin 21 of IC102, then the signal is converted into the DC voltage at the low pass filter and added to the cathode side of VCO vari-cap to make the phases equal.
  • Page 6 Parts List DJ-V57 MAIN Unit Ref.No. Parts No. Parts Name C101 CU3559 GRM155B30J105KE18D C102 CU3535 GRM155B11H102KA01D C103 CU3523 GRM1552C1H101JZ01D C104 CU3535 GRM155B11H102KA01D C105 CU3554 GRM155B11A104KA01D C106 CU3535 GRM155B11H102KA01D C107 CU3535 GRM155B11H102KA01D C108 CU0124 GRM21BB30J226ME38L C109 CU3504 GRM1553C1H3R0CZ01D C110 CU3513 GRM1552C1H150JZ01D...
  • Page 7 C160 CU3547 GRM155B11C103KA01D C161 CU3535 GRM155B11H102KA01D C162 CU3535 GRM155B11H102KA01D C163 CS0396 TMCP1D104MTRF C164 CU3527 GRM1552C1E221JA01D C165 CU3535 GRM155B11H102KA01D C166 CU3531 GRM155B11H471KA01D C167 CU3508 GRM1552C1H7R0DZ01D C168 CU3523 GRM1552C1H101JZ01D C169 CU3554 GRM155B11A104KA01D C170 CU3554 GRM155B11A104KA01D C171 CU3535 GRM155B11H102KA01D C172 CU3009 C1608CH1H080DT-NS C173 CU3007 C1608CH1H060DT/S C174...
  • Page 8 C222 CU3547 GRM155B11C103KA01D C223 CU3508 GRM1552C1H7R0DZ01D C224 CU3521 GRM1552C1H680JZ01D C225 CU3535 GRM155B11H102KA01D C226 CU3575 GRM1554C1H1R5BZ01D C227 CU3503 GRM1554C1H2R0CZ01D C228 CU3502 GRM1554C1H1R0CZ01D C229 CU3502 GRM1554C1H1R0CZ01D C230 CU3511 GRM1552C1H100JZ01D C231 CU3521 GRM1552C1H680JZ01D C232 C233 CU3521 GRM1552C1H680JZ01D C234 C235 CU3517 GRM1552C1H330JZ01D C236 CU3505 GRM1552C1H4R0CZ01D C237 CU3535...
  • Page 9 C286 CU3535 GRM155B11H102KA01D C287 CU3535 GRM155B11H102KA01D C288 C289 CU3531 GRM155B11H471KA01D C290 CU3554 GRM155B11A104KA01D C291 CU3554 GRM155B11A104KA01D C292 C293 CU3519 GRM1552C1H470JZ01D C294 CS0397 TMCP1C105MTRF C295 CU3531 GRM155B11H471KA01D C296 CU3510 GRM1552C1H9R0DZ01D C297 CU3509 GRM1552C1H8R0DZ01D C298 CU3509 GRM1552C1H8R0DZ01D C299 CU3509 GRM1552C1H8R0DZ01D C300 CE0436 16CE47BSS C301 CU3535...
  • Page 10 C350 CU3535 GRM155B11H102KA01D C351 CU3535 GRM155B11H102KA01D C352 CU3554 GRM155B11A104KA01D C353 CU0119 GRM21BB30J106KE18L C354 CU3535 GRM155B11H102KA01D C355 CU0119 GRM21BB30J106KE18L C356 CU3535 GRM155B11H102KA01D C357 CU3547 GRM155B11C103KA01D C358 C359 CU3553 GRM155B11A473KA01D C360 CU3553 GRM155B11A473KA01D C361 CU3527 GRM1552C1E221JA01D C362 CU3545 GRM155B11E682KA01D C363 CU3554 GRM155B11A104KA01D C364 CU3559 GRM155B30J105KE18D...
  • Page 11 C412 CU3554 GRM155B11A104KA01D C414 CU3523 GRM1552C1H101JZ01D C415 CU3535 GRM155B11H102KA01D C416 CU3554 GRM155B11A104KA01D C417 CU0119 GRM21BB30J106KE18L C418 CU3554 GRM155B11A104KA01D C419 CU3535 GRM155B11H102KA01D C421 C422 CU3507 GRM1552C1H6R0DZ01D C423 CU3508 GRM1552C1H7R0DZ01D C424 CU3507 GRM1552C1H6R0DZ01D C425 CU3535 GRM155B11H102KA01D C426 C427 C428 CU3535 GRM155B11H102KA01D C429 CU3143 GRM188B30J475KE18D CF101...
  • Page 12 D147 XD0419 1SS400 TE61 D148 XD0338 1SS362(TE85L,F) D149 XL0128 SML-D12M8WT86 D150 XL0128 SML-D12M8WT86 D151 XD0418 RB521S-30TE61 D152 XD0499 CMS01(TE12L,Q) D153 XD0418 RB521S-30TE61 D154 XD0499 CMS01(TE12L,Q) D155 XD0338 1SS362(TE85L,F) D156 XD0503 JDP2S04E(TPH3,F) FB101 QB0057 MPZ1608S101AT/A FB102 QB0057 MPZ1608S101AT/A FB103 QB0057 MPZ1608S101AT/A FB104 QB0057 MPZ1608S101AT/A...
  • Page 13 L135 QC0816 MLG1005SR22J-T/A L136 QC0875 C2012H68NH L137 QC0875 C2012H68NH L138 QC0874 C2012H56NH L139 QC0816 MLG1005SR22J-T/A L140 QC0773 C1608CB-R47J L141 QC0955 C1608H-15NG L142 QC0955 C1608H-15NG L143 QC0955 C1608H-15NG L144 QC0782 C1608H-18NJ L145 QC0780 C1608H-12NJ L146 QC0762 C1608CB-56NJ L147 QC0965 LB2012T220K L148 QC0779 C1608H-10NJ LCD101...
  • Page 14 Q147 XU0210 RN1107MFV(TPL3) Q148 XT0241 TPCP8602(TE85L,F) Q149 XT0210 2SC6026MFV-GR(TPL3) Q150 XU0213 RN1111MFV(TPL3) Q151 XU0210 RN1107MFV(TPL3) Q152 XU0213 RN1111MFV(TPL3) Q153 XU0210 RN1107MFV(TPL3) Q154 XU0210 RN1107MFV(TPL3) R101 RK3542 RK73B1ETTP222J R102 RK3534 RK73B1ETTP471J R103 RK3526 RK73B1ETTP101J R104 RK3522 RK73B1ETTP470J R105 RK3550 RK73B1ETTP103J R106 R107 RK3530 RK73B1ETTP221J...
  • Page 15 R157 RK3542 RK73B1ETTP222J R158 RK3550 RK73B1ETTP103J R159 RK3552 RK73B1ETTP153J R160 RK3534 RK73B1ETTP471J R161 RK3546 RK73B1ETTP472J R162 RK3550 RK73B1ETTP103J R163 RK3562 RK73B1ETTP104J R164 RK3562 RK73B1ETTP104J R165 RK3566 RK73B1ETTP224J R166 RK3542 RK73B1ETTP222J R167 RK3538 RK73B1ETTP102J R168 RK3562 RK73B1ETTP104J R169 RK3530 RK73B1ETTP221J R170 RK3566 RK73B1ETTP224J R171...
  • Page 16 R219 RK3562 RK73B1ETTP104J R220 RK3574 RK73B1ETTP105J R221 RK3554 RK73B1ETTP223J R222 RK3553 RK73B1ETTP183J R223 RK3526 RK73B1ETTP101J R224 RK3526 RK73B1ETTP101J R225 RK3564 RK73B1ETTP154J R226 RK3574 RK73B1ETTP105J R227 RK3554 RK73B1ETTP223J R228 RK3550 RK73B1ETTP103J R229 RK3562 RK73B1ETTP104J R230 RK3550 RK73B1ETTP103J R231 RK3558 RK73B1ETTP473J R232 RK3542 RK73B1ETTP222J R233...
  • Page 17 R283 RK3566 RK73B1ETTP224J R284 RK3562 RK73B1ETTP104J R285 RK3562 RK73B1ETTP104J R286 RK3550 RK73B1ETTP103J R287 RK3550 RK73B1ETTP103J R288 RK3550 RK73B1ETTP103J R289 RK3558 RK73B1ETTP473J R290 RK3558 RK73B1ETTP473J R291 RK3558 RK73B1ETTP473J R292 RK3550 RK73B1ETTP103J R293 RK3562 RK73B1ETTP104J R294 RK3562 RK73B1ETTP104J R295 RK3550 RK73B1ETTP103J R296 RK3554 RK73B1ETTP223J R297...
  • Page 18 R347 RK3554 RK73B1ETTP223J R348 RK3550 RK73B1ETTP103J R349 RK3550 RK73B1ETTP103J R350 RK3550 RK73B1ETTP103J R351 RK3546 RK73B1ETTP472J R353 R354 RK3546 RK73B1ETTP472J R355 RK3546 RK73B1ETTP472J R356 RK3546 RK73B1ETTP472J R357 RK3546 RK73B1ETTP472J R358 R359 RK3555 RK73B1ETTP273J R361 RK3532 RK73B1ETTP331J R362 RK3530 RK73B1ETTP221J R363 RK3501 RK73Z1ETTP R364 RK3550...
  • Page 19 KNOB SD0111A BATTERY TERMINAL SP0013 LECTRA #7800 SS0103A CHASSIS UE0502A SMA CONNECTOR UP0535 BATT PANEL BOARD UR0027 RH70N97E20 16.2F YX0039 LCD TAPE DJS45 Packing Unit BB0009Y HAND STRAP BH0017 BELT CLIP EA0114A ANTENNA EG0063 EBP66 EDC160 NI-MH CHARGER SET www.ALINCO.ru...
  • Page 20 DJV57 PC Board View MAIN - Side A ALINCO, INC.
  • Page 21 DJV57 PC Board View MAIN - Side B ALINCO, INC.
  • Page 22 PAGE ADJUSTMENT DJ-V57 In order to adjust the units, mode of them must be changed into “Adjustment mode”. (1) Change the mode of the unit into “Memory mode”. Operation: Press the V/M key. (”M” appears on the display) (2) Change the mode of the unit into “Adjustment mode”.
  • Page 23 PAGE ADJUSTMENT DJ-V57 Required Test Equipment The following items are required to adjust radio parameters 1.Regulated power supply Supply voltage: 5-14 DC Current: 3A or more 2.Digital multimeter Voltage range: FS = Approx. 20V Current: 10A or more Input resistance: High impedance 3.Oscilloscope...
  • Page 24 PAGE ADJUSTMENT DJ-V57 ·13.8V DC shall be supplied to the DC Jack of the unit. ·Antenna connector shall be connected to a measurement equipment with a 50 ohms shield cable. ·The test frequency can be varied within +/- 0.2MHz when receiving interference or interfering with other productions.
  • Page 25 PAGE ADJUSTMENT DJ-V57 ·13.8V DC shall be supplied to the DC Jack of the unit. ·Antenna connector shall be connected to a measurement equipment with a 50 ohms shield cable. ·The test frequency can be varied within +/- 0.2MHz when receiving interference or interfering with other productions.
  • Page 26 PAGE ADJUSTMENT DJ-V57 ·13.8V DC shall be supplied to the DC Jack of the unit. ·Antenna connector shall be connected to a measurement equipment with a 50 ohms shield cable. ·The test frequency can be varied within +/- 0.2MHz when receiving interference or interfering with other productions.
  • Page 27 PAGE ADJUSTMENT DJ-V57 ·13.8V DC shall be supplied to the DC Jack of the unit. ·Antenna connector shall be connected to a measurement equipment with a 50 ohms shield cable. ·The test frequency can be varied within +/- 0.2MHz when receiving interference or interfering with other productions.
  • Page 28 PAGE ADJUSTMENT DJ-V57 ·13.8V DC shall be supplied to the DC Jack of the unit. ·Antenna connector shall be connected to a measurement equipment with a 50 ohms shield cable. ·The test frequency can be varied within +/- 0.2MHz when receiving interference or interfering with other productions.
  • Page 29 FB106 CMS01 FBMH1608HM151 Li-ion BEEP SW109 SW110 SW111 SW112 R348 R349 R350 R351 D153 CN102 RB521S-30 4.7k R330 100k SW113 SW114 SW115 SW116 SSTB DMOD Q149 IC114 2SC6026MVF R1EX24064ATAS0 Q153 DATA RN1107MFV SW117 SW118 SW119 SW120 DAFO Schematic diagram DJ-V57...
  • Page 30 D145 SMLD12M8W Q150 Ni-MH Q149 RN1111MFV D146 SMLD12M8W 2SC6026MFV Q152 D149 SMLD12M8W RN1111MFV V-T5V Q109 D150 SMLD12M8W SSM3J15FV Q135 D154 CMS01 Q112 2SA1955FV U-T5V RN47A4JE BATTERY Li-ion EEP ROM IC114 RECEIVE R1EX24064ATAS0 TRANSMIT Q141 RN2107MFV RECEIVE/TRANSMIT CPU CONTROL Block diagram DJ-V57...
