Closing Up; References Information; Specifications; Product Registration - Advanced Keys AK-PSB06 Installation Manual

• Connecting the wire harnesses and power ON the controller, check and confirm system operations
(Refer to Ignition Test and Troubleshooting) verify functions of the vehicle are in working order.
• Make sure all wiring connection are insulated properly. Place and secure control units to locations
inside trim panels and bundle all lose wiring. Put back all trim panels
• When mounting the controller unit in the vehicle, consider the location carefully. You should make
sure that you avoid any location where the controller is exposed to moisture, extreme heat or
interfere with moving parts on the vehicle which hampers driving.
• Explain all functions related to the end-user of this system.

REFERENCES INFORMATION

PRODUCT SPECIFICATIONS
Controller operating voltage range: ............................................................. 10 VDC – 16 VDC
Controller Stand by power: ..................................................................... ≤ 20mA @ 12 VDC
Avg. controller operating power: ................................................................ ≤ 80mA@12VDC
Devices operating temperature range: .......................................................... -25°C – +85°C
Push Button Diameter: ...........................................................................................40mm
Push Button Dimensions: ........................................................... 76mmL x 40mmW x 40mmH
Base Controller Dimensions: .......................................................115mmL x 90mmW x 30mmH

PRODUCT REGISTRATION

Installer of this system to is requested to fill out the following information as a proof of installation to
the end-user of this system. For manufacture warranty to take immediate effect please request the
end-user to update the following information at: http:// www.advancedkeys.com/registration.htm
Company / Installer Name:
Installer Address:
Vehicle Manufacture:
Interface/Bypass Module Used:
If YES specify bypass make/model/firmware version:
System Ignition Mode:
Tach
System Enabled by: Smart Key
Reviewed Product Operation with End-User:
Additional Comments:
Model:
YES NO
Steering Column Lock Bypassed:
If YES specify bypass method used:
Remote Start Function Enabled:
Tachless
Third Part Device If YES is Neutral Safety Switch tested and working?
YES NO
© Copyright Advanced Keys Inc. 2013. All Rights Reserved.
Phone Number:
Date of Installation:
Year:
Tested and Working
YES NO
YES NO
Not Tested
15
