INSTALLATION GUIDE
Intelligent Unit Series (AK - 101, 102, 103)
1. Package Contents .................................................2
2. Pre-Installation Information and Preparation............3
3. Harness Connection Description.............................4
4. Door Locking System Wiring....................................6
5. Antenna Installation................................................9
6. Main Controller Wiring Diagram.............................10
7. Engine Push-Start Module Installation..................12
8. Windows Auto Closer Installation.............................19
9. Closing Up................................................................23
Attention：
1) Please ensure the target vehicle has proper grounding and no electrical shorts.
2) The manufacturer will not be responsibility for any electrical damage resulting from
improper installation of the product, be that either damage to the vehicle itself or to
the product.
3) This product must be installed by a certified technician using all safety devices
supplied. Please note that this guide has been written for properly trained technicians,
a certain level of skill and knowledge is therefore assumed.
4) Please review the Installation Guide carefully before beginning any work.
Intelligent Keyless Entry System
Advertisement
Related Manuals for Advanced Keys AK-101
Summary of Contents for Advanced Keys AK-101
-
Page 1: Table Of Contents
Intelligent Keyless Entry System INSTALLATION GUIDE Intelligent Unit Series (AK – 101, 102, 103) 1. Package Contents ……...........2 2. Pre-Installation Information and Preparation....3 3. Harness Connection Description…......4 4. Door Locking System Wiring........6 5. Antenna Installation………........9 6. Main Controller Wiring Diagram………....10 7. -
Page 2: Package Contents
Package Contents The following is a list of components included in the kit: Included Contents: Optional Contents: 1 – Control Unit 1 – Push-Start Ignition Module 2 – Access Key 1 – Push-Start Ignition Harness 1 – Main Harness (8-Pin) 1 –... -
Page 3: Pre-Installation Information And Preparation
Should the unit be powered before being grounded, serious damage to internal components might occur. 2.6 Advanced Keys will not accept any damage or injury resulting from the installation of this system. Installation of this product is acceptance of... -
Page 4: Harness Connection Description
Main Controller Harness Connection Description 3.1 Main Harness (8-Pin) – Connect the following wires GREY(2 Wires): (+) Turn Signal Lights • Connect to positive side of the Front/Rear indicator lights. Could optionally connect to hazard light wiring for same effect. RED: (+) 12V Battery •... - Page 5 Main Controller Harness Connection Description 3.2 Accessory Harness (7-Pin) – Connect the following wires WHITE: (-) Starter Control Relay • This output is enabled only if a valid access key is detected. This output can provide Ignition/Starter Control protection or act as an auxiliary output when valid key is in range.
-
Page 6: Door Locking System Wiring
There are various types of central locking systems, please verify and confirm the type of door locking system either by multimeter testing and/or through your vehicle’s dealer technical support department. Advanced keys holds no responsibility for damage to your vehicle by incorrect electrical connections. - Page 7 Door Locking System Wiring 4.2 Positive & Positive/Negative Triggered Door Locking System Use two additional relays and connect the wires according to the following figure: +12V +12V +12V +12V Green (-)LOCK Green (-)LOCK Vehicle LOCK Vehicle LOCK From Controller Unit From Controller Unit Signal Wire Signal Wire...
- Page 8 Door Locking System Wiring About Door Switch These switches are used to check to see if the doors are open or closed. To verify the type of door switches for your vehicle, shut off the interior lights first, then open the driver side’s door, keeping the other doors closed; Then check the voltage, firstly if the voltage is ground and becomes positive voltage when the door is closed, then it should be negative trigger type.
-
Page 9: Antenna Installation
Main Controller Antenna Installation Recommended locations for installing the main antennas are under the front glass or either above or below the instrument panel, depending on customer’s preference. (See diagrams below) Please note the antenna should be as far away as possible from any metallic material to achieve the best reception in all directions. -
Page 10: Main Controller Wiring Diagram
Main Controller Wiring Diagram Grey 18AWG Turn Indicator Light (+) 7.5A Grey 18AWG Turn Indicator Light (+) 7.5A 18AWG Battery +12V Green 18AWG Lock (-) Blue 18AWG Unlock (-) Black 18AWG Ground Purple 20AWG Horn Control Wire (-) (See Jumper) White 22AWG Starter Control Relay Output (-) Purple 22AWG... - Page 11 Main Controller Wiring Diagram 1. Jumper Settings: Note: JP1: Door Switch JP4: Sound Output Type is a dual function jumper setting. The default setting is Positive OEM Horn. Under OEM Horn setting Negative (Default) there will be no sound when Passively Locking/Unlocking.
-
Page 12: Engine Push-Start Module Installation
Closing Up 7.1 Before connecting the wire harness and power on the units, check and confirm all functions of the vehicle are in working order. Make sure taps and wiring connection are insulated properly and pay extra attention to the door panel wiring as it could be exposed to water. Place and secure control units to locations inside trim panels and bundle all lose wiring.
