Intraphex PIN-NI21 User Manual

Prodigy*one.2 prodigy*mini navigation integration module
Hide thumbs

Advertisement

Quick Links

Download this manual
P1N-NI21
PMN-NI21
Prodigy*one.2
Prodigy*mini
na vigation
INTEGRA TION MODULE
See application guide for applicable vehicles

Advertisement

loading
Need help?

Need help?

Do you have a question about the PIN-NI21 and is the answer not in the manual?

Questions and answers

Related Manuals for Intraphex PIN-NI21

Summary of Contents for Intraphex PIN-NI21

  • Page 1 P1N-NI21 PMN-NI21 Prodigy*one.2 Prodigy*mini na vigation INTEGRA TION MODULE See application guide for applicable vehicles...
  • Page 2 Cont acts www.INTRAPHEX.com SUPPORT@INTRAPHEX.COM SUPPORT: 888-228-5560...
  • Page 3 Contents What’s In The Box VIDEO INTERFACE PCB INTRAPHEX MOUSE   PRODIGY*ONE.2 / MINI CONNECTOR TWO   (PRODIGY*ONE.2 ONLY) RGB T-HARNESS  PCB SPACERS  8GB SD CARD WITH  TOUCH LAYER  INTRAPHEX NAV SOFTWARE TOUCH LAYER TRIM ...
  • Page 4 THIS MANUAL EXPLAINS THE INSTALLATION AND WIRING OF PRODIGY*MINI AND PRODIGY*ONE.2. DURING THE PROCESS OF YOUR INSTALLATION PLEASE TAKE NOTE TO REFERENCE THE CORRECT WIRING DIAGRAM THAT CORRESPONDS WITH THE SYSTEM THAT YOU ARE WORKING WITH. OTHER FEATURES SUCH AS THE MICROPHONE, CONNECTOR TWO AND WIFI ARE SPECIFIC TO THE PRODIGY*ONE.2 SYSTEM.
  • Page 6 PRODIGY*MINI CONNECTIONS 4 PIN SPEAKER CVBS VIDEO DATA SD CARD SLOT UART (NOT USED) POWER LED STATUS GREEN POWER ON AMBER BOOT SUCESSFUL FLASHING GREEN/AMBER GPS SIGNAL AQUIRED...
  • Page 7 PRODIGY*ONE.2 CONNECTORS ***NOTE*** MICROPHONE IS THE THINNER OF THE 3.5MM JACKS...

  • Page 8: Monitor Assembly

     REMOVE MONITOR FROM VEHICLE AND PLACE IN A CLEAN WORK AREA. REMOVE MOUNTING BRACKETS FROM MONITOR.  REMOVE FOUR #1 PHILLIPS FROM OUTSIDE OF CASE SECURING BACK OF MONITOR ASSEMBLY.  SEPARATE FRONT AND REAR OF CASE.  REMOVE FOUR #1 PHILLIPS SECURING THE FACTORY PCB IN PLACE.
  • Page 9  FIND PACKAGE OF FOUR PCB SPACERS AND FOUR #1 PHILLIPS.  INSTALL FOUR PCB SPACERS INTO LOCATIONS WHERE PCB MOUNTING SCREWS WERE REMOVED. DO NOT OVER TIGHTEN.  USING A PIC TOOL, RELEASE THE EIGHT SMALL LATCHES HOLDING THE LCD TRIM RING.
  • Page 10  ALL COMPONETS SEPARATED AND INTRAPHEX TRIM RING.  INSERT INTRAPHEX TRIM RING. THE TRIM RING ONLY FITS CORRECTLY ONE WAY. YOU CAN CHECK THE FRONT TO MAKE SURE THAT IT IS INSTALLED THE CORRECT WAY.  TRIM RING INSTALLED. ***NOTE***...
  • Page 11 IF YOU ARE WORKING ON ONE OF THE LARGER NISSAN SCREEN ASSEMBLIES, YOU WILL NEED TO DRILL A SMALL HOLE IN THE FRAME ALLOWING THE RIBBON TO PASS THROUGH TO ENSURE THERE IS ENOUGH LENGTH..  INSTALL INTRAPHEX PCB WITH FOUR PROVIDED #1 PHILLIPS.
  • Page 12 CHECK THIS CONNECTION.  PLUG T-HARNESS INTO THE PCB. TWO CONNECTIONS ARE REQUIRED TO THE INTRAPHEX PCB. 15 PIN AND 5 PIN. PLEASE BE SURE THAT THESE CONNECTIONS ARE TIGHT AND SEATED CORRECTLY. INCORRECT ASSEMBLY WILL CAUSE TOUCH AND COLOR ISSUES.
  • Page 13  ALTHOUGH NOT NECESSARY SOME TRIMMING ON THE CASE WILL ALLOW THE CABLES TO EXIT MUCH EASIER.  HERE THE CASE HAS BEEN MODIFIED AND TESA TAPE ADDED TO PREVENT CHAFING.  RE-INSTALL THE REAR OF THE CASE MAKING SURE THAT NO CONNECTORS COME UNPLUGGED DURING THE PROCESS.
  • Page 14  PLUG IN RGB/DATA CABLE. REINSTALL MONITOR TO CAR AND ROUTE RGB/ DATA CABLE TO LOCATION OF PRODIGY BOX.  PLUG RGB/DATA CABLES INTO PRODIGY BRAIN. ( ). ROUTE PRODIGY MINI SHOWN POWER CONNECTIONS TO REAR OF RADIO.  ROUTE MICROPHONE AND GPS ANTENNA FROM DESIRED LOCATIONS AND CONNECT TO PRODIGY*ONE.2.
  • Page 15  CONNECT POWER, ACC, GROUND TO PRODIGY UNIT. SEE DIAGRAM BELOW  THIS PLUG CAN BE FOUND ON THE BACK OF THE RADIO/CDPLAYER. FOR FACTORY AUDIO INTEGRATION YOU CAN USE THE OPTIONAL PART TD-SPEAKERSWITCH...
  • Page 16  ONCE ALL CONNECTIONS HAVE BEEN MADE YOU CAN TEST THE INTERFACE BEFORE PUTTING THE VEHICLE BACK TOGETHER.  TO TEST TURN ACC ON, WAIT FOR RADIO TO BOOT AND TOUCH THE TOUCH LAYER IN ANY SPOT FOR 1 SEC...
  • Page 17  TO EXIT THE PRODIGY INTERFACE, SIMPLY PRESS IN THE BOTTOM LEFT HAND CORNER FOR THREE SECONDS.  IF YOUR SCREEN DOES NOT SWITCH, YOU HAVE INSTALLED THE TOUCH LAYER INCORRECTLY OR THE RIBBON CABLE IS NOT CONNECTED PROPERLY.  YOU CAN NOW START THE SETUP OF THE PRODIGY BRAIN.

  • Page 18: Touch Screen Calibration

    TOUCH SCREEN CALIBRATION  USING THE MOUSE (PLUGGED INTO THE OPEN USB FROM EARLIER) CLICK ON THE SETTINGS TAB.  ENTER PASSWORD “7777” THEN PRESS OK TO ENTER SETTINGS MENU.  CLICK ON THE “CALIBRATION” ICON.  NOW USING YOUR FINGER (FROM DRIVER TOUCH AND SIDE OF CAR FOR BEST RESULTS)

  • Page 19: Navigation Software

     DO NOT CHANGE ANY OF THE OTHER SETTINGS INSIDE OF THE SETTINGS MENU. THEY ARE ALL SET TO DEFAULT. CHANGING ANY OF THESE SETTINGS WILL CAUSE ERRATIC BEHAVIOR OR CAUSE THE SCREEN TO GO BLACK. IF THIS HAPPENS CALL TECH SUPPORT FOR ASSISTANCE.
  • Page 20  USING THE VOLUME SETTING FOR VOICE, YOU CAN PRESS THE CIRCLE AND IT WILL REPEAT A PROMPT SO THAT YOU CAN SET THIS CORRECTLY. CHOOSE AN OUTPUT THAT COMPLIMENTS THE RADIO VOLUME OUTPUT.  USER WILL HAVE VOLUME CONTROL FROM THE VOLUME SLIDER BAR LOCATED IN THE VOLUME SETTINGS.
  • Page 21 RE-ASSEMBLY  ONCE PROPER FUNCTION HAS BEEN ACHIEVED, YOU CAN RE-ASSEMBLE THE VEHICLE.  BE SURE TO REPLACE ALL REMOVED SCREWS AND TRIM PANELS.  BE SURE TO LEAVE NAVIGATION QUICK START GUIDE AND USER INSTRUCTIONS IN THE VEHICLE FOR THE CUSTOMER.
  • Page 22 SCAN THE IMAGE ABOVE WITH YOUR MOBILE PHONE TO GET MORE INFORMATION ABOUT INTRAPHEX PRODUCTS...
  • Page 23 INTRAPHEX warrants to the original retail purchaser, that the product(s) purchased from an INTRAPHEX authorized dealer, in the original vehicle, are free from defects in materials or workmanship under normal use and conditions for a period of THREE (3) years from date of purchase.

This manual is also suitable for:

Pmn-ni21
