Table of contents Important notice ........4 Wi-Fi .............29 Bluetooth ..........30 Getting to know your phone .....7 Wi-Fi Direct ...........31 Phone layout ..........7 Transferring data between a PC and the Installing the SIM or USIM card and device............32 battery .............9 Calls ............33 Charging the battery ......11 Making a call .........33 Inserting a memory card ......12...
Important notice Please read this before you start using your phone! Please check to see whether any problems you encountered with your phone are described in this section before taking the phone in for service or calling a service representative. 1.
Some applications you download may consume battery power. • While using downloaded applications, check the battery charge level. • 3. Before installing an open source application and OS WARNING If you install and use an OS other than the one provided by the manufacturer it may cause your phone to malfunction.
Press the Volume Keys to highlight Yes once more, then press the Power/Lock Key to confirm. WARNING If you perform a Hard Reset, all user applications, user data and DRM licenses will be deleted. Please remember to backup any important data before performing a Hard Reset.
Getting to know your phone Phone layout Microphone Earpiece Headset Jack Proximity Sensor Front Camera Lens NOTE: Proximity sensor When receiving and making calls, the proximity sensor automatically turns the backlight off and locks the touch screen by sensing when the phone is near your ear.
Page 10
Rear Camera Lens Flash Power/Lock Key Volume Keys Speaker Microphone Charger/USB Port Power/Lock Key Turn your phone on/off by pressing and holding this key. • Press once quickly to lock/unlock the screen. • Volume Keys While the screen is off: Press Volume Up Key twice to launch QuickMemo+.
Installing the SIM or USIM card and battery Before you can start exploring your new phone, you need to set it up. To remove the back cover, hold the phone firmly in one hand. With your other hand, lift off the back cover with your thumbnail as shown in the figure below. Slide the SIM card into the lower slot for the SIM card as shown in the figure.
Page 12
WARNING Do not insert a memory card into the SIM card slot. If a memory card happens to be lodged in the SIM card slot, take the device to a LG Service Center to remove the memory card. NOTE: Only microSIM cards work with this device.
USB cable. WARNING Use only LG-approved chargers, batteries and cables. If you use unapproved chargers, batteries or cables, it may cause a battery charging delay. This can also cause the battery to explode or damage the device, which is not covered by the warranty.
Inserting a memory card Your device supports up to a 32 GB microSD card. Depending on the memory card manufacturer and type, some memory cards may not be compatible with your device. WARNING Some memory cards may not be fully compatible with the device. Using an incompatible card may damage the device or the memory card, or corrupt the data stored in it.
Do not remove the memory card while the device is transferring or accessing information. Doing so can cause data to be lost or corrupted or damage to the memory card or device. LG is not responsible for losses that result from the misuse of damaged memory cards, including the loss of data.
Page 16
NOTE: Create or sign in to a Google account before setting an screen lock and remember the backup PIN you created when creating your screen lock. Caution! If you haven't created or signed in to a Google account on the phone and you forgot your PIN, Password, and the backup PIN, you need to perform a hard reset.
Your Home screen Touch screen tips Here are some tips on how to navigate on your phone. Tap or touch – A single finger tap selects items, links, shortcuts and letters on the • on-screen keyboard. Touch and hold – Touch and hold an item on the screen by tapping it and not •...
Home screen The Home screen is the starting point for many applications and functions. It allows you to add items like app shortcuts and Google widgets to give you instant access to information and applications. This is the default canvas and accessible from any menu by tapping Status Bar Widget Application Icons...
Returns to the previous screen. Also closes pop-up items, Back Button such as menus, dialog boxes and the on-screen keyboard. Home Button Return to the Home screen from any screen. Touch and hold to access the Google Now shortcut. Displays recently used applications. If you touch and hold Recent Apps this button, it opens a menu of available options.
Adding an app to the Quick Button area From the Apps screen or on the Home screen, touch and hold an application icon • and drag it to the Quick Button area. Then release it in the desired location. Removing an app from the Quick Button area Touch and hold the desired Quick Button, drag it to , and release it.
Page 21
NOTE: The available options may vary depending on the region or service provider. Pending System notifications notifications Opening the Notifications panel Swipe down from the Status bar to open the Notifications panel. To close the Notifications panel, swipe the screen upwards or tap Quick Settings Area Notifications Clear...
Page 22
Current notifications are listed, each with a brief description. Tap a notification to view it. Tap to clear all of the notifications. Indicator icons on the Status Bar Indicator icons appear on the status bar at the top of the screen to report missed calls, new messages, calendar events, device status and more.
An alarm is set GPS is on New voicemail available Data is synchronizing New text or multimedia Choose input method message Media server content sharing is on NOTE: The icon's location in the Status bar may differ according to the function or service.
Page 24
Entering special characters The on-screen keyboard allows you to enter special characters. For example, to input "á", touch and hold the "a" button until the zoom-in key expands and displays special characters. Without lifting your finger, drag your finger to the desired special character.
Special Features Gesture shot The Gesture shot feature allows you to take a picture with a hand gesture using the front camera. To take photo There are two methods for using the Gesture shot feature. Raise your hand, with an open palm, until the front camera detects it and a box •...
KnockON The KnockON feature allows you to double-tap the screen to easily turn it on or off. To turn the screen on Double-tap the center of the Lock screen to turn the screen on. Unlock the screen or access any of the available shortcuts or widgets. To turn the screen off Double-tap an empty area of the Home screen or the Status Bar.
Knock Code The Knock Code feature allows you to create your own unlock code using a combination of knocks on the screen. You can access the Home screen directly when the screen is off by tapping the same sequence on the screen. NOTE: If you enter the wrong Knock Code 6 times, it will compulsorily take you to •...
QuickMemo+ The QuickMemo+ feature allows you to create memos and capture screen shots. You can use QuickMemo+ to easily and efficiently create memos during a call, with a saved picture or on the current phone screen. Drag the Status bar down and tap Create a memo using the following options: Tap to undo the most recent action.
Google account setup The first time you open a Google application on your phone, you will be required to sign in with your existing Google account. If you do not have a Google account, you will be prompted to create one. Creating your Google account >...
Page 30
After signing in, your phone will sync with your Google services, such as Gmail, Contacts, and Google Calendar. You can also use Maps, download applications from Play Store, back up your settings to Google servers, and take advantage of other Google services on your phone.
Connecting to Networks and Devices Wi-Fi You can use high-speed Internet access while within the coverage of the wireless access point (AP). Connecting to Wi-Fi networks > > > Networks tab > Wi-Fi. to turn Wi-Fi on and start scanning for available Wi-Fi networks. Tap a network to connect to it.
Bluetooth devices, such as headsets and hands-free car kits, and Bluetooth-enabled handhelds, computers, printers, and wireless devices. NOTE: LG is not responsible for the loss, interception or misuse of data sent or • received via the Bluetooth feature.
Sending data via Bluetooth Select a file or item, such as a contact or media file. Select the option for sending data via Bluetooth. Search for and pair with a Bluetooth-enabled device. Due to different specifications and features of other Bluetooth-compatible devices, •...
(MTP). A window will pop up on your PC, allowing you to transfer the desired data. NOTE: The LG United Mobile Driver is required to be installed on your PC to be • able to detect the phone. Check the requirements for using Media sync (MTP).
Calls Making a call to open the dialer. Enter the number using the dialer. To delete a digit, tap After entering the desired number, tap to place the call. To end the call, tap TIP! To enter "+" to make international calls, touch and hold Calling your contacts to open your contacts.
Making a second call During your first call, tap > Add call and enter the number. to place the call. Both calls are displayed on the call screen. Your initial call is locked and put on hold. Tap the displayed number to toggle between calls. Or tap to start a conference call.
Contacts You can add contacts on your phone and synchronize them with the contacts in your Google Account or other accounts that support syncing contacts. Searching for a contact to open your contacts. Tap Search contacts and enter the contact name using the keyboard. Adding a new contact and enter the new contact's number.
Removing a contact from your favorites list to open your contacts. Tap the Favorites tab, and choose a contact to view its details. Tap the gold star at the top right of the screen to remove the contact from your favorites.
Messaging Your phone combines text and multimedia messaging into one intuitive, easyto-use menu. Sending a message From the Home screen, tap and tap to create a new message. Enter a contact name or contact number into the To field. As you enter the contact name, matching contacts appear.
Conversation view Messages exchanged with another party are displayed in chronological order so that you can conveniently see and find your conversations. Changing your messaging settings Your phone's messaging settings are predefined to allow you to send messages immediately. You can change the settings based on your preferences. on the Home screen, tap >...
E-mail You can use the Email application to read email from providers other than Gmail. The Email application supports the following account types: POP3, IMAP and Microsoft Exchange (for Enterprise users). Managing email accounts To open the Email application The first time you open the Email application, a setup wizard opens to help you add an email account.
Composing and sending email In the application, tap to create a new email. Enter an address for the message's intended recipient. As you enter text, matching addresses will be offered from your contacts. Separate multiple addresses with semicolons. Tap the Cc/Bcc field to copy or blind copy to other contacts/email addresses. Tap the text field and enter your message.
Camera and Video Camera options on the viewfinder To open the Camera application, tap > > You can use the camera or camcorder to take and share pictures and videos. NOTE: Be sure to clean the protective lens cover with a microfiber cloth before taking pictures.
Set the size of your picture and video. 16 : 9 Allows you to say a voice command to take pictures. You can say LG, Cheese, Smile, or any other supported command. Set your camera's timer. This is ideal if you want to be a part of the picture or video.
Taking a photo Open the Camera application and point the lens toward the subject you want to photograph. Focus indicators will appear in the center of the viewfinder screen. You can also tap anywhere on the screen to focus on that spot. When the focus indicators turn green, the camera has focused on your subject.
Recording a video Open the Camera application and point the lens toward the subject you want to capture in your video. once to start recording. NOTE: The timer will be displayed on the screen. to stop recording. TIP! – Tap to pause the recording. After recording a video Tap the video thumbnail on the screen to view the last video you recorded.
Live Zoom Live Zoom allows you to zoom in or out on a portion of a video that is being played to make the desired section appear larger or smaller. When viewing a video, use your index finger and thumb in a pinching or spreading motion to zoom in or out.
Viewing pictures The Gallery displays your pictures in folders. When some apps save a picture, a folder is automatically created to contain the picture. Pictures are displayed by the date they were created. Select a picture to view it full screen.
Page 49
Tap to access additional options. NOTE: While a video is playing, the following options are available: • Slide the right side of the screen up or down to adjust the sound. • Slide the left side of the screen up or down to adjust the brightness. •...
Multimedia Music Your phone has a music player that lets you play all your favorite tracks. Playing a song > > Tap the Songs tab. Select the song you want to play. The following options are available. Tap to add the song to your favorites. Tap to open the current playlist.
Page 51
Tap to toggle through repeat all songs, repeat current song and repeat off. Tap to adjust the volume. Tap to restart the current track or skip to the previous track in the album, playlist or shuffle list. Touch and hold to rewind. Tap to pause playback.
Utilities Clock The Clock app gives you access to the Alarms, Timer, World clock and Stopwatch functions. Access these functions by tapping the tabs across the top of the screen or swiping horizontally across the screen. > > Alarms The Alarms tab allows you to set alarms. Open the app, then select the Alarms tab.
World clock The World clock tab allows you to easily check the current time in other cities around the world. Open the app, then select the World clock tab. and select the desired city. Stopwatch The Stopwatch tab allows you to use your phone as a stopwatch. Open the app, then select the Stopwatch tab.
Calendar The Calendar app allows you to track your schedule of events. > > Tap the date you want to add an event to. Then tap Enter the event details and tap SAVE. Voice Recorder The Voice Recorder app records audible files for you to use in a variety of ways. Recording a sound or voice >...
NOTE: You may incur data fee charges when using your mobile network to access • LG SmartWorld. LG SmartWorld may not be available for all carriers or in all countries. • What if there is no LG SmartWorld icon? Using a mobile Web browser on your device, access LG SmartWorld (www.lgworld.com) and select your country.
Page 56
Special benefits available for LG SmartWorld Personalize your device with home themes, keyboard themes, and fonts. • Enjoy special promotions only offered on LG SmartWorld. • Note that LG SmartWorld is only available for certain devices. Please check • the www.lgworld.com for more information. Utilities...
Browsing the Web Chrome Use Chrome to search for information and browse webpages. > > NOTE: This application may not be available depending on your region and service provider. Viewing webpages Tap the address field, and then enter a web address or search criteria. Opening a page To open a new page, tab >...
Settings The Settings application contains most of the tools for customizing and configuring your phone. All of the settings in the Settings application are described in this section. To open the Settings application > touch and hold > System settings. •...
Page 59
Only numbers in the fixed dial list can be called from your phone. Caller ID – Use default operator settings to display your number in outgoing calls. • Incoming voice call pop-up – Displays incoming voice call pop-up when an app •...
Mobile Hotspot – Allows you to create a hotspot and share your connection. • Help – Displays Help information about USB tethering, Mobile hotspot, and • Bluetooth tethering. More Mobile networks – Allows you to configure various mobile network settings. •...
< NOTIFICATIONS > Interruptions Allows you to set a schedule when to prevent interruptions from notifications. You can set to allow certain features to interrupt when Priority only is set. Lock screen Allows you to choose if you want to show or hide notifications on the lock screen. Apps Allows you to prevent apps from displaying notifications or set apps to show notifications with priority when Do not disturb is set to Priority only.
Page 62
LG SmartWorld. Wallpaper – Allows you to set the desired wallpaper for your Home screen. • Screen swipe effect – Choose the desired type of effect to display when you • swipe from one Home screen canvas to the next.
Current keyboard – Allows you to set the current keyboard to use when entering • text. LG Keyboard – Tap to change the LG Keyboard settings. • Google voice typing – Tap to change the Google voice typing settings. •...
Page 64
text-to-speech output. Pointer speed – Adjust the pointer speed. • Location Turn on location service, your phone determines your approximate location using Wi-Fi and mobile networks. When you select this option, you're asked whether you consent to allowing Google to use your location when providing these services. Mode –...
Page 65
- Touch zoom – Allows you to zoom in and out by triple-tapping the screen. - Screen color inversion – Enable to invert the colors of the screen and content. - Screen color adjustment – Allows you to invert the colors of screen and content.
Shortcut key Get quick access to apps by pressing the Volume Keys twice when the screen is off or locked. < PRIVACY > Security Use the Security menu to configure how to help secure your phone and its data. Lock screen – Allows you to set your lock screen settings. •...
Page 67
erases the secure storage's own password. Trust agents – Select apps to use without unlocking screen. • Screen pin – This feature allows you to lock your device so that the current user • can only access the pinned app. This is useful for users with children. App usage access –...
Page 68
data. Factory data reset – Reset your settings to the factory default values and delete • all your data. If you reset the phone this way, you are prompted to re-enter the same information as when you first started Android. About phone View legal information, check phone status and software versions, and perform a software update.
Internet without needing to visit a service center. This feature will only be available if and when LG makes a newer firmware version available for your device. Because the mobile phone firmware update requires the user's full attention for the duration of the update process, please make sure you check all instructions and notes that appear at each step before proceeding.
Page 70
Google account and any other accounts, your system/application data and settings, any downloaded applications and your DRM licence—might be lost in the process of updating your phone's software. Therefore, LG recommends that you backup your personal data before updating your phone's software.
• providers or carriers. This content is subject to change without prior notice. For the latest version of this guide, please visit the LG website at www.lg.com. Your phone's applications and their functions may vary by country, region or •...
Page 72
• Battery • NOTE Always use genuine LG accessories. The supplied items are designed only • for this device and may not be compatible with other devices. The items supplied with the device and any available accessories may vary •...
Page 73
Category Question Answer What functions You can connect a Bluetooth audio Bluetooth are available via device, such as a Stereo/Mono Devices Bluetooth? headset or car kit. Contacts data can be synchronized Contacts How can I back up between your phone and your Google Backup Contacts? account.
Page 74
Category Question Answer My phone does not display the time of Open the conversation and touch and Message receipt for messages hold the desired message. Then tap Time older than 24 hrs. Details. How can I change this? Is it possible to install Any application that is available at Play another navigation Navigation...
Page 75
Category Question Answer 1. From the Home screen, touch and hold 2. Tap System settings > Display tab > Lock screen. 3. Tap Select screen lock > Pattern. The first time you do this, a short tutorial about creating an Unlock Pattern appears.
Page 76
Category Question Answer If you forgot your pattern: If you logged into your Google account on the phone but failed to enter the correct pattern 5 times, tap the Forgot pattern button. You are then required What should I do if to log in with your Google account I forget the unlock to unlock your phone.
Page 77
Category Question Answer 1. From the Home screen, touch and My screen turns off hold after only 15 seconds. 2. Tap System settings > Display tab. Screen time How can I change the 3. Tap Screen timeout. amount of time for the 4.
Page 78
Category Question Answer Yes. After saving a music file as a ringtone, you can use it as an alarm. 1. Touch and hold a song in a library Can I use music files list. In the menu that opens, tap Set Alarm for my alarm? as ringtone >...
Page 79
For Your Safety Safety Information Please read and observe the following information for safe and proper use of your phone and to prevent damage. WARNING! This product contains chemicals known to the State of California to cause cancer and birth defects or reproductive harm. Wash hands after handling. Caution Violation of the instructions may cause minor or serious damage to the product.
Page 80
Improper battery use may result in a fire, explosion or other hazard. • Repairs under warranty, at LG’s option, may include replacement parts or boards • that are either new or reconditioned, provided that they have functionality equal to that of the parts being replaced.
Page 81
Recharge the battery after long periods of non-use to maximize battery life. Battery • life will vary due to usage pattern and environmental conditions. Never store your phone in temperature less than -4 °F or greater than 122 °F. • Charging temperature range is between 32 °F and 113 °F.
to clean your phone. This could cause a fire. Always unplug the charger from the wall socket after the phone is fully charged to • save unnecessary power consumption of the charger. Care and Maintenance Your mobile device is a product of superior design and craftsmanship and should be treated with care.
Page 83
Do not use the phone if the antenna is damaged. If a damaged antenna contacts • skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna. The data saved in your phone might be deleted due to careless use, repair of the •...
Page 84
disturb others. Do not turn your phone on or off when putting it to your ear. • Your phone is an electronic device that generates heat during normal operation. • Extremely prolonged, direct skin contact in the absence of adequate ventilation may result in discomfort or minor burns.
Page 85
Consult the dealer or an experienced radio/TV technician for help. • FCC RF Exposure Information WARNING! Read this information before operating the phone. In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters.
Page 86
Consumer Information About Radio Frequency Emissions Your wireless phone, which contains a radio transmitter and receiver, emits radio frequency energy during use. The following consumer information addresses commonly asked questions about the health effects of wireless phones. Are wireless phones safe? Scientific research on the subject of wireless phones and radio frequency (“RF”) energy has been conducted worldwide for many years, and continues.
Page 87
limits established by the FCC. One of these limits is expressed as a Specific Absorption Rate, or “SAR.” SAR is a measure of the rate of absorption of RF energy in the body. Tests for SAR are conducted with the phone transmitting at its highest power level in all tested frequency bands.
Page 88
users of wireless communication devices, including children.” The FDA/FCC website further states that “some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all”. For example, the Stewart Report from the United Kingdom [“UK”] made such a recommendation in December 2000.
Page 89
Royal Society of Canada Expert Panels on Potential Health Risks of Radio Frequency Fields from Wireless Telecommunication Devices 283 Sparks Street Ottawa, Ontario K1R 7X9 Canada Telephone: (613) 991-6990 World Health Organization Avenue Appia 20 1211 Geneva 27 Switzerland Telephone: 011 41 22 791 21 11 http://www.who.int/mediacentre/factsheets/fs193/en/ International Commission on Non-Ionizing Radiation Protection c/o Bundesamt fur Strahlenschutz...
Engineering in Medicine and Biology Society, Committee on Man and Radiation (COMAR) of the Institute of Electrical and Electronics Engineers http://ewh.ieee.org/soc/embs/comar/ TIA Safety Information The following is the complete TIA Safety Information for wireless handheld phones. Consumer Information on SAR (Specific Absorption Rate) This model phone meets the government’s requirements for exposure to radio waves.
Page 91
The highest SAR values are: * Head: 1.21 W/kg * Body (Body-worn): 1.25 W/kg (body measurements differ among phone models, depending upon available accessories and FCC requirements). While there may be differences between SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.
Page 92
scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1). The design of your phone complies with the FCC guidelines (and those standards). Antenna Care Use only the supplied or an approved replacement antenna.
Page 93
Should use the ear opposite the pacemaker to minimize the potential for • interference; Should turn the phone OFF immediately if there is any reason to suspect that • interference is taking place. Hearing Aids Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).
Potentially Explosive Atmosphere Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations);...
Page 95
reasons for inconsistent results. 2. What is the FDA’s role concerning the safety of wireless phones? Under the law, the FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices.
Page 96
While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.
Page 97
acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.
Page 98
formal Cooperative Research And Development Agreement (CRADA) to do research on wireless phone safety. The FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts with independent investigators. The initial research will include both laboratory studies and studies of wireless phone users.
Page 99
phone users. The test method uses a tissue-simulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body.
Page 100
2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.
Page 101
(http://www.hpa.org.uk/radiation/) Driving Check the laws and regulations on the use of wireless phones in the areas where you drive and always obey them. Also, if using your phone while driving, please observe the following: Give full attention to driving -- driving safely is your first responsibility; •...
Page 102
box or a label located on the box. The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully.
Page 103
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of LG. LG shall bear the cost of shipping the product back to the consumer after the completion of service under this limited warranty.
Page 105
(11) Consumables (such as fuses). 3. WHAT LG WILL DO: LG will, at its sole option, either repair, replace or refund the purchase price of any unit that is covered under this limited warranty. LG may choose at its option to use functionally equivalent re-conditioned, refurbished or new units or parts or any units.
Page 106
Send a copy of your written demand for arbitration, as well as a copy of this provision, to the AAA in the manner described in the AAA Rules. You must also send a copy of your written demand to LG at LG Electronics, USA, Inc.Attn: Legal Department-Arbitration1000 Sylvan AvenueEnglewood Cliffs, NJ...
Page 107
Opt Out. You may opt out of this dispute resolution procedure. If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the fi...
