- Page 1 SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER MANUAL V.1 FOUR-TAP DELAY / DUAL CROSSFADER SIGNAL INPUTS ECHO / DELAY IN 1 0.15 IN 2 0.05 IN 3 DUAL CROSSFADER IN 1 IN 1 IN 2 IN 2 SPUTNIK MODULAR SPUTNIK-MODULAR.COM...
-
Page 2: Table Of Contents
SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER TABLE OF CONTENTS SPECIFICATIONS INSTALLATION DESCRIPTION DIAGRAM WARRANTY SPUTNIK-MODULAR.COM... -
Page 3: Specifications
SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER SPECIFICATIONS FORMAT: Eurorack DIMENSIONS: 22HP, 40mm deep INTERNAL AND EXTERNAL SIGNALS (3.5mm Jacks): CV: 0-5V, AUDIO: +/-5V MAX CURRENT: +12V: 90mA -12V: 90mA +5V: 100mA SPUTNIK-MODULAR.COM... -
Page 4: Installation
SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER INSTALLATION Remove module from packaging. Power down your modular synthesizer and disconnect the power cable from the wall outlet. Attach the included power cable to the module’s power connector and connect the other end to the power distribution bus in your EuroRack synthesizer case. -
Page 5: Description
SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER DESCRIPTION The SPUTNIK FOUR-TAP DELAY / DUAL CROSSFADER is a modular digital delay with patch points that allow you to create a variety of time-based effects from extreme cross-modulation to subtle, tape-like warble. The delay features a three input mixer summed to the delay section. -
Page 6: Diagram
SPUTNIK MODULAR FOUR-TAP DELAY / DUAL CROSSFADER ECHO / DELAY SIGNAL INPUTS Delay time is variable between approxi- mately 0.05-.2 seconds (X1 mode) or .5 seconds to 2 seconds (X10 mode). Three audio inputs (modular or line-level) with volume attenua-... -
Page 7: Warranty
FOUR-TAP DELAY / DUAL CROSSFADER WARRANTY This product is covered by the Sputnik Modular warranty, for one year following the date of purchase. This warranty covers any defect in the manufacturing of this product. This warranty does not cover any damage or malfunction caused by incorrect use –...
