Link electronics VSW-828 Specification Sheet

LINK ELECTRONICS, INC.
RS-232 VERTICAL INTERVAL VIDEO SWITCHER
16 INPUTS, 2 DESTINATIONS
MODEL VSW-828
MADE IN THE USA
FEATURES
16 Inputs
Two Destinations
RS-232 Controlled
Vertical Interval
The VSW-828 is a wide band-width vertical
interval switcher designed for the video
professional. It's sixteen high impedance
looping inputs and TWO distination outputs allow
the user to efficiently and economically route or
delegate multiple video signals.
Packaged in a 19" rack mountable cabinet, the
VSW-828 features 16 inputs and high-quality
push buttons switches. A seven segment LED
readout of the selected source video is shown on
the seven segment LED readout. RS-232 is
provided through a D-Sub connector.
LINK
ELECTRONICS, INC. 2137 Rust Avenue
Phone 573 334 4433
FEATURES
Digital Switching
One Rack Unit Cabinet
7 Seg LED Reads Source #
Wide Bandwidth
Switching is accomplished during the vertical
interval by using the vertical sync derived from
the video at the output stage of the VSW-828
video switcher.
The VSW-828 is a video-only switcher with a
seven segment LED showing the source video.
There is no available audio follow unit for the
VSW-828.
All switchers are manufactured in th USA and
carry a ten-year warranty including parts and
labor.
.
Cape Girardeau, MO 63703-7668
FAX 573 334 9255
800 SERIES
