Connecting Front Panel Cable

Attach the power LED, keylock, speaker, and reset
switch connectors to the corresponding pins. Locate
the power switch cable from your ATX housing. It is
2-pin female connector from the housing front panel.
Plug this connector to the soft-power switch connector
marked SPWR.
1
2
SPWR
Connecting IDE and Floppy Cable
Be careful of the pin1 orientation. Wrong orientation may cause system damage.
Pin1 of cable is normally marked with red color.
Pin 1
FDC
1
+
Keylock
+
Sleep LED
+
Speaker
GND
1
KEYLOCK
SLEEP LED
GND
+5V
SPEAKER
+5V
GND
NC
SPEAKER
Slave (4th) Master (3rd)
IDE2 (Secondary)
IDE1 (Primary)
Pin 1
Slave (2nd) Master (1st)
The HDD LED connector is designed for different type of housing, actually only two
pins are needed for the LED. If your housing has 4-pin connector, simply plug it in. If
+
you have only 2-pin connector, please connect to pin 1-2 or pin 3-4 according to the
polarity.
Power LED
+
Sleep SW
+
Reset
+5V
GND
POWER LED
GND
GND
NC
GND
SLEEP SWITCH
RESET
GND

Hard Disk LED

1
HDD LED
2
GND
3
GND
4
HDD LED
Connecting ATX Power Cable
The ATX power supply uses 20-pin connector shown
below. Make sure you plug in the right direction.
+5V
+5V
+3.3V
-12V
GND
PSON
PWOK
5VSB
+12V
+5V
-5V
GND
