Technical Manual
Belfort
Wood or coal stove
Model : 134 04 11
Output : 4,5 kW
NF EN 13240
Description of the appliance
Installation instructions
Operating instructions
Spare parts
Warranty certificate
Document n° 1174-3 ~ 15/10/2004
FR EN NL
PL
ÈE EN NL
PL
Technical manual
to be saved
by the user
for future reference
STAUB FONDERIE
Head Office Address
2, rue Saint Gilles
68230 TURCKHEIM
RC Colmar
SIREN 439 330 325
Address - Administration and
manufacturing
BP 73
59660 MERVILLE (FRANCE)
Telephone : 00 333 28 43 43 43
Fax : 00 333 28 43 43 99
Subject to modifications.
IT
IT
Advertisement
Table of Contents
Related Manuals for Belfort 134 04 11
Summary of Contents for Belfort 134 04 11
-
Page 1: Installation Instructions
Belfort Document n° 1174-3 ~ 15/10/2004 FR EN NL Wood or coal stove ÈE EN NL Model : 134 04 11 Output : 4,5 kW NF EN 13240 Technical manual to be saved by the user for future reference STAUB FONDERIE... -
Page 2: Table Of Contents
“BELFORT” - ref. 134 04 11 FRANCO BELGE congratulates you on your choice. FRANCO BELGE, which has been granted the ISO 9001 certification, guarantees the quality of its appliances and is committed to meet its customers’ needs. FRANCO BELGE, which can boast a 75-year experience in the industry of heating devices, uses state-of-the-art technologies to design and manufacture its whole range of products. -
Page 3: Product Information
Ash pan capacity ..litres The “ Belfort ” is designed for operation with the door Net weight ....kg closed. -
Page 4: Installation Instructions
“BELFORT” - ref. 134 04 11 Installation instructions 2. Installation instructions 2.1. Warning to the user thickness 12 mm minimum (C). This may include the thickness of a non-combustible floor. An incorrectly installed heating appliance can The hearth must protrude at least 225 mm in front of the cause serious accidents (chimney fires, burning of stove and 150 mm each side. -
Page 5: Chimney Connector
“BELFORT” - ref. 134 04 11 Installation instructions 2.4. Assembly of flue spigot and blanking plates The stove is supplied with a connection flue spigot with an inner diameter of 125 mm or an outer diameter of 139 mm. 2.4.1. Smoke exit on the top Figure 4 Remove the internal baffle ( # 17, page 13). -
Page 6: Maintenance Of The Stove Body
“BELFORT” - ref. 134 04 11 Installation instructions Figure 6 - Chimney " connections 1 - Chimney 2 - Funnel-shape fireproof material 3 - Non " combustible register plate 4 - Cleaning access door 5 - Liner The connection can be either vertical or horizontal. For horizontal connections, avoid right angle bends. -
Page 7: Assembly Of Flue Spigot And Blanking Plates Pre-Utilisation Check
“BELFORT” - ref. 134 04 11 Installation instructions 2.8. Pre-utilisation check 2.9. Chimney maintenance and sweeping Check the condition of the filler seals, that the door Very important : To avoid accidents (chimney fire, closes correctly. etc.), regular maintenance should be carried out. If the stove is regularly used, the chimney should be swept Check that the glass is not damaged. -
Page 8: Instructions For User
“BELFORT” - ref. 134 04 11 Instructions for user 3. Instructions for user The manufacturer will not be responsible for damages Note : It is recommended to use a fireguard in the presence of children, and also in the presence of old on parts of the appliance due to the use of prohibited and/or infirm people. -
Page 9: Instructions For Use With Wood
“BELFORT” - ref. 134 04 11 Instructions for user Figure 9 - Removing thefuel retainer • “Green wood” and “recovered wood” can eventually cause a chimney fire. • Prohibited fuel : Homefire and any form of bituminous coal or petroleum based coke. -
Page 10: Maintenance Of The Stove
3.6. Recommendations It is essential to keep the grate free from a heavy build up of ashes. The Belfort is equipped with a grate This room heater is a high heat producing appliance riddling device which is used to “shake” ashes off the and may cause severe burns if touched on the glass grate into the ash pan. -
Page 11: Trouble Shooting
“BELFORT” - ref. 134 04 11 Instructions for user 3.8. Trouble Shooting þ : This sign means that you should ask for a qualified engineer to do the work. Problem Probable causes Action Fire difficult to start Wood green, too damp or poor Use the recommended fuel. -
Page 12: Spare Parts
“BELFORT” - ref. 134 04 11 Spare parts 4. Spare parts When ordering spare parts, specify the stove type and Example : serial number, including the colour index (on the Belfort wood stove : “Belfort”, guarantee or identification plate), the name of the part model.: 134 04 11 Y,... - Page 13 “BELFORT” - ref. 134 04 11 Spare parts " $ " ! " " ! " # & " " & & " " ! & ! " & " " % " " " "...
- Page 14 “BELFORT” - ref. 134 04 11 Spare parts Y = 1340411Y ; J = 1340411J ; I = 1340411I ; C = 1340411C ; D = 1340411D ; P = 1340411 P N° Code Description ..Type ..Y . . . J . . . I . . . C . . . D . . . P ..Qty 307432 Fuel retainer .
- Page 16 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ Date of installation : __ __ / __ __ /__ __ __ __ Model of the appliance : q 134 04 11 q Y q J q I q C q D q P Color : Serial number : ___ ___ ___ ___ ___ ___ •...
