  • Page 1 POWER POWER EV10i...
  • Page 2 USR EV10i OWNER'S MANUAL The"e-SPEC"mark symbolizes environmentally responsible technologies applied to USR power equipment, which contains our wish to" preserve nature for generations to come."...
  • Page 3 Thank you for purchasing a our generator. This manual covers operation and maintenance of the EV10i generator. All information in this publication is based on the latest product information available at the time of approval for printing. We reserves the right to make changes at any time without notice and and without incurring any obligation.

  • Page 4: Table Of Contents

    CONTENTS SAFETY INSTRUCTIONS ..............SAFETY LABEL LOCATIONS ............Ce mark and noise label locations ........... COMPONENT IDENTIFICATION ............PRE-OPERATION CHECK ..............13 STARTING THE ENGINE ..............18 Carburetor Modification for High Altitude Operation GENERATOR USE ................22 STOPPING THE ENGINE ..............

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS To ensure safe operation ʵ The generator is designed to give safe and dependable service if operated according to instructions. Read and understand the Owner's Manual before operating the generator. Failure to do so could result in personal injury or equipment damage.
  • Page 6 To ensure safe operation ʵ Gasoline is extremely flammable and explosive under certain conditions. Refuel in a well ventilated area with the engine stopped. Keep away from cigarette, smoke and sparks when refueling the generator. Always refuel in a well-ventilated location. Wipe up spilled gasoline at once.
  • Page 7 To ensure safe operation Always make a pre-operation inspection (page ) before you start the engine. You may prevent an accident or equipment damage. Place the generator at least 1 m (3 ft) away from buildings or other equipment during operation. Operate the generator on a level surface.

  • Page 8: Safety Label Locations

    If a label comes off or becomes hard to read, contact your dealer for a replacement. [For European model: G, GW, B, F, W types] HOT CAUTION CONNECT CAUTION FUEL CAUTION/PARALLEL OPERATION CAUTION EV10i Inverter Generator EXHAUST CAUTION READ OWNER扴 MANUAL...
  • Page 9 SOCKET CAUTION [For Australian model: U type]...

  • Page 10: Ce Mark And Noise Label Locations

    CE mark and noise label locations [For European model: G, GW, B, F, W types] NOISE LABEL CE MARK EV10i Inverter Generator Model Maximum ambient temperature EV10i Inverter Generator Performance class IP code Maximum altitude Dry weight...

  • Page 11: Component Identification

    COMPONENT IDENTIFICATION FUEL CAP VENT LEVER CHOKE LEVER FUEL FILLER CAP CONTROL PANEL LEFT SIDE MAINTENANCE COVER STARTER GRIP ENGINE SWITCH FRAME SERIAL NUMBER SPARK PLUG MAINTENANCE COVER MUFFLER Record the frame serial number in the space below. You will need this serial number when ordering parts.

  • Page 12: Control Panel

    CONTROL PANEL G, GW, F, W types AC RECEPTACLE PARALLEL OPERATION SOCKETS ECO THROTTLE SWITCH GROUND TERMINAL OIL ALERT INDICATOR LIGHT OVERLOAD INDICATOR LIGHT OUTPUT INDICATOR LIGHT DC RECEPTACLE DC CIRCUIT PROTECTOR...
  • Page 13 B type AC RECEPTACLE U type AC RECEPTACLE...
  • Page 14 Eco Throttle ECO: Engine speed is kept at idle automatically when the electrical appliance is disconnected and it returns to the proper speed by the electrical load when electrical appliance is connected. This position is recommended to minimize the fuel consumption while in operation. Eco Throttle system does not operate sufficiently if the electrical appliance requires the momentary electric power.

  • Page 15: Pre-Operation Check

    PRE-OPERATION CHECK Be sure to check the generator on a level surface with the engine stopped. Check the engine oil level. Using nondetergent oil or 2-stroke engine oil could shorten the engine抯 service life. Use high-detergent, premium quality 4-stroke engine oil, certified to meet or exceed U.S.
  • Page 16 Loosen the cover screw and remove the left side maintenance cover. (see page Remove the oil filler cap, and wipe the dipstick with a clean rag. Check the oil level by inserting the dipstick in the filler hole without screwing it in.
  • Page 17 Check the fuel level. If the fuel level is low, refuel the fuel tank until the level as specified. After refueling, tighten the fuel filler cap securely. Use automotive unleaded gasoline with a Research Octane Number of 91 or higher (a Pump Octane Number of 86 or higher). Never use stale or contaminated gasoline or an oil/gasoline mixture.
  • Page 18 Gasolines containing alcohol If you decide to use a gasoline containing alcohol (gasohol), be sure it's octane rating is at least as high as that recommended by USR . There " are two types of "gasohol : one containing ethanol, and the other containing methanol.
  • Page 19 Check the air cleaner. Check the air cleaner element to be sure it is clean and in good condition. Loosen the cover screw and remove the left side maintenance cover. Press the latch tab on the top of the air cleaner body, remove the air cleaner cover, check the element.

  • Page 20: Starting The Engine

    STARTING THE ENGINE Before starting the engine disconnect any load from the AC receptacle. Turn the fuel cap lever fully clockwise to the ON position. Turn the fuel cap vent lever to the OFF position when transporting the generator. FUEL CAP VENT LEVER Turn the engine switch to the ON position.
  • Page 21 Move the choke lever to the CLOSED position. Do not use the choke when the engine is warm or the air temperature is high. CHOKE LEVER CLOSED CLOSED Pull the starter grip lightly until you feel resistance, then pull the starter grip briskly toward the arrow as shown below.
  • Page 22 Move the choke lever to the OPEN position as the engine warms up. CHOKE LEVER OPEN If the engine stops and will not restart, check the engine oil level (see page ) before troubleshooting in other areas.

  • Page 23: Carburetor Modification For High Altitude Operation

    Carburetor Modification for High Altitude Operation At high altitude, the standard carburetor air-fuel mixture will be too rich. Performance will decrease, and fuel consumption will increase. A very rich mixture will also foul the spark plug and cause hard starting. Operation at an altitude that differs from that at which this engine was certified, for extended periods of time, may increase emissions.

  • Page 24: Generator Use

    GENERATOR USE Be sure to ground the generator when the connected equipment is grounded. Connections for standby power to a building抯 electrical system must be made by a qualified electrician and must comply with all applicable laws and electrical codes. Improper connections can allow electrical current from the generator to backfeed into the utility lines.
  • Page 25 The DC receptacle can be used while the AC power is in use. If you use both at the same time, be sure not to exceed the total power for AC and DC. (See page Most appliance motors require more than their rated wattage for startup.
  • Page 26 AC applications Start the engine and make sure the Output indicator (green) comes Confirm that the appliance to be used is switched off, and plug in the appliance. PLUG OUTPUT INDICATOR OVERLOAD INDICATOR LIGHT (GREEN) LIGHT (RED) Substantial overloading that continuously lights the overload indicator light (red) may damage the generator.
  • Page 27 Output and Overload Indicators The Output indicator (green) will remain ON during normal operating conditions. If the generator is overloaded (in excess of 1.0 kVA), or if there is a short in the connected appliance, the output indicator light (green) will go OFF, the overload indicator light (red) will go ON and current to the connected appliance will be shut off.
  • Page 28 Please read the item "GENERATOR USE" before connecting any equipment to be used. A max output of 2.0 kVA can be obtained by using two units (EV10i) in parallel operation (connection in parallel). There are the terminals into which the special cable is inserted for parallel operation.
  • Page 29 Never connect the different generator models and types. Never connect a cable other than the special cable for parallel operation. Connect and remove the special cable for parallel operation with the engine stopped. For single operation, the special cable for parallel operation must be removed.
  • Page 30 Be sure to ground the generator when the connected equipment is grounded. GROUND TERMINAL GROUND TERMINAL Start each engine according to" STARTING THE ENGINE". When the output indicator light (green) does not light and the overload indicator light (red) lights instead, set the engine switch to STOP, stop the engine once, and then start the engine again.
  • Page 31 Switch on the equipment to be used. The output indicator light (green) will light. In case of normal operation In case of overload operation or short-circuit OVERLOAD INDICATOR LIGHT OUTPUT INDICATOR LIGHT (RED) (GREEN) In case of overload operation (refer to page ) or when trouble occurs for the equipment being used, the output indicator light (green) will go out, the overload indicator light (red) will light...
  • Page 32 When equipment requiring a large starting power, like a motor etc., is used, the overload indicator light (red) and the output indicator light (green) may light together for a short time (about 4 sec), but this is no abnormality. After start of the equipment, the overload indicator light (red) will go out and the output indicator light (green) will stay lit.
  • Page 33 DC Application The DC receptacle may be used for charging 12 volt automotive-type batteries only. In DC operation, turn the eco throttle switch to the OFF position. Connect the charging cable to the DC receptacle of the generator and then to the battery terminals. CHARGING CABLE (SOLD SEPARATELY: G, B, F, W types) To prevent the possibility of creating a spark near the battery,...
  • Page 34 Batteries produce explosive gases: If ignited, and explosion can cause serious injury or blindness. Provide adequate ventilation when charging. CHEMICAL HAZARD: Battery electrolyte contains sulfuric acid. Contact with eyes or skin, even through clothing, may cause severe burns. Wear a faceshield and protective clothing. Keep flames and sparks away, and do not smoke in the area.
  • Page 35 Oil alert system The Oil Alert system is designed to prevent engine damage caused by an insufficient amount of oil in the crankcase. Before the oil level in the crankcase falls below a safe limit, the Oil Alert system will automatically shut down the engine (the engine switch will remain in the ON position).

  • Page 36: Stopping The Engine

    STOPPING THE ENGINE To stop the engine in an emergency, turn the engine switch to the OFF position. IN NORMAL USE: Switch off the connected equipment and pull the inserted plug. PLUG Turn the engine switch to the OFF position. ENGINE SWITCH...
  • Page 37 Turn the fuel cap vent lever fully counterclockwise to the "OFF" position. FUEL CAP VENT LEVER Be sure the fuel cap vent lever and the engine switch are "OFF" when stopping, transporting and/or storing the generator. When parallel operation has been executed, pull the special cable for parallel operation.

  • Page 38: Maintenance

    The exhaust contains poisonous carbon monoxide gas. Use genuine USR parts or their equivalent. The use of replacement parts which are not of equivalent quality may damage the generator. Maintenance Schedule...
  • Page 39 CHANGING OIL Drain the oil while the engine is still warm to assure rapid and complete draining. Make sure to turn the engine switch and the fuel cap vent lever OFF before draining. Loosen the cover screw and remove the left side maintenance cover. Remove the oil filler cap.
  • Page 40 AIR CLEANER SERVICE A dirty air cleaner will restrict air flow to the carburetor. To prevent carburetor malfunction, service the air cleaner regularly. Service more frequently when operating the generator in extremely dusty areas. Do not use gasoline or low flash point solvents for cleaning. They are flammable and explosive under certain conditions.
  • Page 41 SPARK PLUG SERVICE RECOMMENDED SPARK PLUG: CR4HSB (NGK) U14FSR-UB (DENSO) To ensure proper engine operation, the spark plug must be properly gapped and free of deposits. Remove the spark plug maintenance cover. SPARK PLUG MAINTENANCE COVER Remove the spark plug cap. Clean any dirt from around the spark plug base.
  • Page 42 Visually inspect the spark plug. Discard it if the insulator is cracked or chipped. Clean the spark plug with a wire brush if it is to be reused. Measure the plug gap with a feeler gauge. Correct as necessary by carefully bending the side electrode. The gap should be: 0.60 0.70 mm (0.024 0.028 in) ʵ...
  • Page 43 SPARK ARRESTER MAINTENANCE (Equipped type) If the generator has been running, the muffler will be very hot. Allow it to cool before proceeding. The spark arrester must be serviced every 100 hours to maintain its efficiency. Remove the four 5 mm screws, and remove the muffler protector. MUFFLER PROTECTOR 5 mm SCREW Remove the three 6 mm bolts, and remove the muffler, the spark...
  • Page 44 Use a brush to remove carbon deposits from the spark arrester screen. Inspect the spark arrester screen for holes or tears. Replace if necessary. Check the muffler gasket; replace if damaged. Reinstall the muffler gasket, the spark arrester, the muffler and the muffler protector in the reverse order of removal.

  • Page 45: Transporting/Storage

    TRANSPORTING/STORAGE To prevent fuel spillage when transporting or during temporary storage, the generator should be secured upright in its normal operating position, with the engine switch OFF. The fuel cap vent lever is turned fully counterclockwise to the" OFF" position. When transporting the generator: Do not overfill the tank (there should be no fuel in the filler neck).
  • Page 46 Turn the engine switch ON, and loosen the carburetor drain screw and drain the gasoline from the carburetor into a suitable container. With the drain screw loosened remove the spark plug cap, and pull the starter grip 3 to 4 times to drain the gasoline from the fuel pump. Turn the engine switch to the OFF position, and tighten the drain screw securely.

  • Page 47: Troubleshooting

    TROUBLESHOOTING When the engine will not start: Is there fuel in Refill the fuel the tank? tank. Is the engine Turn the engine switch on? switch on. Is the enough oil Add the in the engine? recommended oil. Is the spark plug Clean, readjust in good gap and dry the...
  • Page 48 Appliance does not operate: Is the Output indicator ON? Take the Is the Overload generator to an indicator ON? authorized dealer. Check the Take the electrical NO DEFECTS generator to an appliance or authorized equipment for dealer. any defects. Replace the electrical appliance or equipment.

  • Page 49: Specifications

    SPECIFICATIONS Dimensions and Weight Model EV10i Description code EZGA Length 450 mm (17.7 in) Width 240 mm (9.4 in) Height 380 mm (15.0 in) Dry weight 13 kg (29 lbs) Engine Model GXH50 Engine type 4-stroke, overhead valve, single cylinder Displacement 50 cm (3.1 cu-in)
  • Page 50 Generator Model EV10i Type G, GW, B, F, W Rated voltage (V) Rated frequency (Hz) output Rated Ampere (A) Rated Output (VA) Max Output (VA) 1,000 Only for charging 12 V DC rated output automotive batteries. 12 V, 8 A...

  • Page 51: Wiring Diagram

    WIRING DIAGRAM AC, NF AC Noise Filter ACOR AC Output Receptacle Capacitor Composite Socket Control Panel Block DC, D DC Diode DC, NF DC Noise Filter DCOR DC Output Receptacle DC, W DC Winding EcoSw Eco throttle switch Engine Block Engine Ground Engine Switch Exciter Winding...
  • Page 52 BLACK YELLOW BLUE GREEN WHITE BROWN LIGHT GREEN GRAY LIGHT BLUE ORANGE PINK ENGINE SWITCH ECOTHROTTLE SWITCH...
  • Page 53 G, GW, B, F, W type...
  • Page 54 U type...
  • Page 55 RECEPTACLE Shape Type G, GW...
