S/M No. : FR33000010
Refrigerator
Service Manual
MODEL :
FR-370S (FRM-272LNE9C)
(For Malaysia DWE SAL-MALAYS)
FR-331 (FRM-273NLE8C)
(For Singapore AIMS)
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr
Oct. 2001
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo FR-370S
Summary of Contents for Daewoo FR-370S
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr Oct. 2001...
-
Page 2: Specification
1. SPECIFICATION 1) MALAYSIA DWE SAL-MALAYS (FR-370S) 115g Refirgerant R134a Fan Cooling Convection Type COOLING System Air Forced Convection Refrigeration System Forced Fin-Evaporator Type Defrost System Automatic Start & Stop Defrost Operation Adjustable Dial Cold Control Freezer Capacity 207L Refrigerator... - Page 3 Specification 2) SINGAPORE AIMS (FR-331) 115g Refirgerant R134a Fan Cooling Convection Type COOLING System Air Forced Convection Refrigeration System Forced Fin-Evaporator Type Defrost System Automatic Start & Stop Defrost Operation Adjustable Dial Cold Control Freezer Capacity 207L Refrigerator 268L Total 1636mm Height Externel...
-
Page 4: Name Of Parts
2. NAME OF PARTS 1) MALAYSIA DWE SAL-MALAYS(FR-370S) - Page 5 Name of parts 2) SINGAPORE AIMS (FR-331)
-
Page 6: Refrigerant Cycle Diagram
3. REFRIGERANT CYCLE DIAGRAM... -
Page 7: Machine Room View And Part List
4. MACHINE ROOM VIEW AND PART LIST 1) SIDE PLATE PIPE TYPE PART NAME PART NAME PART NAME 1 BASE CAB AS 7 PIPE HOT 13 BASE COMP AS 2 COMPRESSOR 8 DRYER AS 14 BRACKET EARTH 3 P-RELAY AS 9 PIPE SUC AS 15 POWER CORD AS 4 PIPE VAPORI AS... -
Page 9: Methods Of Exchanging Main Parts
5. METHODS OF EXCHANGING MAIN PARTS (1) Freezing room louver 1) Unscrew, remove the F-louver by pulling forward with inserting screwdriver into the hole of F louver. 2) Assemble it by pressing triangle shape (▲) by hand. (2) R control box 1) After pressing both bottom surfaces of shade and pull forward. - Page 10 Methode of exchanging main parts 4) Pull slightly forward with instant force. 5) Remove the housing 6) After romoving the control switch knob and two screws for fixing control switch, change the control switch to new one.
- Page 11 Methode of exchanging main parts (3) Bimetal 1) Cut off the wire bind. 2) Take out the bimetal. (4) Glass tube heater Evaporator fastening screw 1) Remove 2 screws that fasten the evaporator. 2) Slightly pull the evaporator to the arrow's direction.
- Page 12 Methode of exchanging main parts 4) Cut the both ends of glass tube heater tube heater lead wires and insulate and seal lead tip remaining in refrigerator with tape etc. Raise Heater Glass tube Heater 5) Pull out the glass tube heater from the heater Cover heater supporter with heater covers remaining.
- Page 13 6-1. EXPLODE VIEW AND PARTS LIST 1) Expoloded views MALAYSIA DWE SAL-MALAYS (FR-370S)
-
Page 14: Parts List
2) PARTS LIST MALAYSIA DWE SAL-MALAYS(FR-370S) NO PART CODE PART NAME DESCRIPTION Q'TY REMARK ASS'Y CAB URT HCFC-141B 4019R54111 GUIDE DRN 3012800501 HEATER GLAS AS 150W 4019R73571 COVER DEFR HTR *TGALVANIED 4019R73581 COVER DEFR HTR *UGALVANIED 4019R03208 EVAPPORATOR AS NO ACCUM... - Page 15 NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3012624000 HANDLE F 3011610810 DECO F HNDL AS 3019015700 POCKET F *T GPPS 3019015800 POCKET F *U GPPS ASSY R DOOR URT HCFC-141B 3012310010 GASKET R DR AS PVC-S 3012624200 HANDLE R 3011611110 DECO R HNDL AS 3011165700 CASE EGG GPPS...
- Page 16 6-2. EXPLODE VIEW AND PARTS LIST 1) Expoloded views SINGAPORE AIMS (FR-331)
- Page 17 Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr) 2) PARTS LIST SINGAPORE AIMS(FR-331)
- Page 18 NO PART CODE PART NAME DESCRIPTION Q'TY REMARK 3012624100 HANDLE F/R C TYPE 3012611000 DECO F/R HNDL C TYPE 3019015700 POCKET F *T GPPS 3019015800 POCKET F *U GPPS ASSY R DOOR URT HCFC-141B 3012310010 GASKET R DR AS PVC-S 3019016200 POCKET SM GPPS 7002501611 SCREW MACHINE...
