Linear DXS-80 Specifications

†
The DXS-80 is a UL listed
station, carbon monoxide alarm with
a built-in supervised transmitter. It is
compatible with Linear's wireless
DXS Format Security Systems, Personal
Emergency Reporting Systems (PERS),
and other stand-alone receivers. The
DXS-80 provides a warning to alert
against both the acute and chronic
effects of carbon monoxide (CO)
poisoning.
When carbon monoxide is detected,
the alarm sounds a loud local alarm.
The built-in transmitter sends a digitally
coded wireless signal to its companion
receiver every 20 seconds until the air
has cleared and the detector is restored.
The local alarm can be silenced once by pressing the test/
reset button. The transmitter will continue to send an alarm
signal every 20 seconds. After 7 minutes, the alarm will sound
again if there is still an unsafe carbon monoxide concentration
level. The reset function can be used only once for each alarm
occurrence.
No field coding is required because the DXS-80 is factory set to
a unique code; one of over a million possible codes.
Model DXS-80
(SST00116)
Carbon Monoxide Alarm
Also available as a kit:
DX-COKIT
(SSA00020)
Kit contains one DXR-702 receiver
with a DXS-80 already learned into
the receiver
NOTE: The DX-COKIT is not for use
in UL Listed applications
DXS-80
Wireless Carbon Monoxide
Alarm
, single
,
,
Model DXR-702
(SNR00149)
2-Channel Receiver
The DXS-80 is powered by one 3-volt
lithium battery. The battery is supplied
and can power the unit for up to the
six year life of the detector. If the
battery voltage drops below a preset
level the alarm will sound a low
battery chirp every 45 seconds and a
low battery signal will be sent to the
receiver.
A At about 6 years, the carbon monoxide
detector element will reach the end of
its serviceable life. The self-supervising
detector will signal a permanent
trouble condition, indicating time for
replacement.
SPECIFICATIONS
REGULATORY LISTINGS:
UL2034
DETECTION METHODS:
Electrochemical
TIME TO ALARM PER UL 2034:
Carbon Monoxide Minimum Time
Concentration Level
50 ppm +/-5 ppm
70 ppm +/-5 ppm
150 ppm +/-5 ppm
400 ppm +/-5 ppm
AUDIBLE OUTPUT: 85 dBA/10'
OPERATING TEMP. RANGE: 32º-100º F
POWER:
3-Volt battery (Lithium Type 123A)
(UL tested for greater than 1 year service life)
CURRENT: 7 mA alarm average, 15 µA standby
FREQUENCY: 315 MHz
NUMBER OF CODES:
One of 1,048,576 possible codes
DIMENSIONS: 5.3" diameter, 2.0"h
†
COMPATIBLE RECEIVERS : PERS-3600
DXSR-1504
DVS-1200
DUAL-824
† The DXS-80 is currently UL Listed for use with the Linear PERS Consoles only. It has not
been tested by UL with other compatible Linear receivers.
Maximum Time
to Alarm to Alarm
30 days Indefinite
60 min 240 min
10 min 50 min
4 min 15 min
PERS-2400A
DXSR-1508
DXR-702
DVS-2400
