Linear DXS-80 Installation Instructions

DXS-80
WIRELESS
CARBON
MONOXIDE
ALARM
Installation
Instructions
USA & Canada (800) 421-1587 & (800) 392-0123
(760) 438-7000 - Toll Free FAX (800) 468-1340
www.linearcorp.com
SELECT PROPER LOCATION
REFER TO SECTION
Kitchen
NUMBER 5 ON THE
Family Room
REAR OF THESE
Living Room
INSTRUCTIONS FOR
IMPORTANT MOUNTING
DETAILS
= Carbon Monoxide
Bedroom
FIGURE 1. RECOMMENDED
CO ALARM PLACEMENT FOR
SINGLE FLOOR RESIDENCE
Bedroom
Bedroom Bedroom
FIGURE 2. RECOMMENDED
CO ALARM PLACEMENT FOR
Kitchen
Living
Garage
MULTI-LEVEL RESIDENCE
Room
= Carbon Monoxide alarm
Basement
location for multi-level
residence
Inside wall location
FIGURE 3. RECOMMENDED
CO ALARM MOUNTING
LOCATION IS 5 TO 6 FEET
FROM FLOOR
INSTALL MOUNTING PLATE
SCREW
ANCHORS
FOR WALLBOARD
OR
PLASTIC
SINGLE-GANG
ELECTRICAL BOX
The DXS-80 is a carbon monoxide (CO) alarm with a built-in transmitter
designed for use with Linear's DXS and DX Format receivers. The
detector gives warning to alert against both the acute and chronic
effects of CO poisoning. When carbon monoxide is detected, the alarm
BY
sounds a loud local alarm. When the local alarm sounds, the built-in
transmitter sends a digitally coded wireless signal to its companion
receiver every 20 seconds until the air has cleared and the detector
is restored.
The local alarm can be silenced once by pressing the TEST/RESET
button. The transmitter will continue to send an alarm signal every 20
seconds. After 7 minutes, the alarm will sound again if there is still an
unsafe CO concentration level. The reset function can be used only
once for each alarm occurrence.
The DXS transmitters are precoded at the factory to one of over a
million possible unique system codes, so no field coding is required.
Receivers must be programmed to the transmitter's code before
system testing and operation. Refer to the receiver's instructions for
details on programming.
SIGNALING
The unit is powered by one 3-volt lithium battery. The battery is supplied
with the transmitter and can power the unit for more than one year. If the
battery voltage drops below a preset level the alarm will sound a low
®
battery chirp every 45 seconds and a low battery signal will be sent to
LISTED
the receiver (some receivers can report low battery, others cannot).
When the detector reaches the end of its serviceable life (after about 6
years) a permanent trouble condition will occur and cannot be reset.
Maintenance: Occasionally clean the outside casing with a cloth.
Ensure that the holes on the front of the alarm are not blocked with dirt
and dust. Do not paint, and do not use cleaning agents, bleach, or
polish on the detector.
Dining
Bedroom
Room
TWIST MOUNTING
PLATE TO UNLOCK
Bedroom
alarm location
Height 5' - 6' from floor
= Carbon Monoxide alarm
mounting location
REFER TO RECEIVER'S INSTRUCTIONS TO
PREPARE RECEIVER TO ACCEPT THE
TRANSMITTER'S CODE
PRESS UNTIL ALARM
BEEPS THEN RELEASE
TEST BUTTON TO
SEND SIGNAL
PRODUCT DESCRIPTION
REMOVE MOUNTING PLATE
REMOVE
MOUNTING
PLATE
PROGRAM RECEIVER
A TEST SIGNAL WILL BE SENT A
FEW SECONDS AFTER THE
SWITCH IS RELEASED
DXS-80 FEATURES
CARBON MOUNTING
ALARM
MONOXIDE PLATE
SOUNDER
ALARM
MOUNTING
TEST/RESET
SCREWS &
BUTTON
ANCHORS
ALARM SIGNALS
NORMAL
GREEN LED FLASHES EVERY 10 SECONDS.
OPERATION
A REPEATING PATTERN OF FOUR SHORT BEEPS AND
ALARM
5 SECOND SILENCE. THE RED LED WILL FLASH ONCE
SIGNAL
PER SECOND.
DETECTOR SELF-TESTS EVERY 5 SECONDS. IF A FAULT
TROUBLE IS DETECTED, RED LED WILL BLINK ONCE EVERY
SIGNAL
5 SECONDS AND DETECTOR WILL BEEP EVERY 45
SECONDS.
LOW BATTERY
RED LED BLINKS EVERY 45 SECONDS.
SIGNAL REPLACE THE BATTERY WHEN THIS SIGNAL OCCURS.
RED LED WILL BLINK ONCE EVERY 10 SECONDS AND
END-OF-LIFE DETECTOR WILL BEEP EVERY 45 SECONDS. IN THIS
SIGNAL CONDITION, THE DETECTOR REQUIRES IMMEDIATE
REPLACEMENT.
REMOVE BATTERY TAB
NOTE: ON POWER-UP THE RED AND
GREEN LEDS WILL BLINK 4 TIMES,
15 SECONDS APART WHILE
REMOVE
THE ALARM INITIALIZES.
BATTERY TAB
TO APPLY
POWER
3-VOLT LITHIUM BATTERY - TYPES: DURACELL DL123A,
PANASONIC CR123A, SANYO CR123A, ADEMCO 466.
AVAILABLE AT LOCAL RETAILERS AND INTERNET
SUPPLIERS. NOTE: USE ONLY THESE SPECIFIC
BATTERY MODELS.
MOUNT ALARM ON PLATE
TWIST CO ALARM CLOCKWISE TO
LOCK ONTO MOUNTING PLATE
ALIGN TAB IN PLATE WITH
NOTCH IN COVER
