User manual VH Series - Uninterruptible Power Supply 700 - 1000 - 1500 - 2000 - 3000 VA... -
Page 2: Package Contents
3 - Installation 3.1 Package contents The shipping box contains a VH Series UPS, four plastic support parts + mounting set, plastic front panel, two plastic plugs, two mounting brackets and screws, a USB cable, two IEC male-female power cords, 1 mains power cord (VH Series 3000VA only), a CD ROM and this manual. Inspect the UPS for damage after unpacking. -
Page 3: Rackmount Installation - Preparations
3.3.2 Rackmount installation - preparations Place the UPS horizontally on a table or desk. Re-position the operating panel: remove the 2 screws that hold the panel and rotate the panel 90 degrees counterclockwise. Don’t pull out the panel! Tighten the 2 screws again. Install the two mounting brackets that came with the unit using the screws provided. - Page 4 3.3.3 Rear panel The figures on this page show a VH Series 3000 VA. The differences with the rear panel - configuration of other models is clearly indicated in the text below. Input socket AC mains supply to the UPS 700-2000 VA: smaller socket than shown here Input breaker Protects the UPS from damage caused by high...
-
Page 5: Connecting Interface Devices
3.3.5 Connecting interface devices If you do not want to use the communication capabilities of the UPS, please skip this section and proceed with 3.3.6. The UPS is equipped with two interface ports: a USB port and an RJ 11 port, allowing advanced communication between the UPS and a computer (network). -
Page 6: Operation
4 - Operation 4.1 Operating panel fig. 4.1: operating panel switch / LED main function 1 - ‘on’ switch switches on the UPS, starts quick battery test (see 4.6) 2 - ‘off’ switch switches off the UPS 3 - LED ‘operation’ on when the UPS is operating blinks if the UPS is in standby mode 4 - LED ‘on bypass’... -
Page 7: Use: Normal Operation
4.2 Start-up 4.2.1 Start-up, mains available Via front panel: press keypad 'I' (1, fig. 4.1) briefly; LED ‘operation’ (already slowly blinking) will at first blink faster and after a few seconds it will illuminate continuously, indicating that the unit has started up. -
Page 8: Use: Status And Alarm Indications
4.4 Use: status and alarm indications status indications the operating mode low priority alarms abnormal operating situations high priority alarms situations in which the actual output voltage of the UPS is no longer guaranteed; immediate action should be taken Indicators on front panel (fig. 4.1) Situation Standby (4.4.1) Startup pending... -
Page 9: Battery Low (End Of Runtime)
4.4.1 Standby The UPS output is off, but the batteries are charging, see 3.3.6 step 5 4.4.2 Normal operation See 4.3.1. 4.4.3 On bypass The UPS is equipped with an automatic bypass switch. This switch automatically transfers the load to the mains if the UPS is unable to deliver the demanded output power due to overload or overtemperature. - Page 10 4.4.7 Overload The demanded power exceeds the normal capacity of the UPS. The alarm occurs when the load is > 100%. If the load exceeds 150% the UPS will immediately switch to bypass, assuming that the conditions for a transfer to bypass are fulfilled. If an overload condition between 110-150% persists, the UPS will also switch to bypass operation.
-
Page 11: Use: Setup Mode
4.5 Use: setup mode In the setup-mode the following parameters can be changed: output voltage: 220 / 230 / 240 Vac • bypass: enable / disable (see 4.4.6) • P (Phase) - N (Neutral) reversal indication: enable / disable (see 4.4.12) •... -
Page 12: Battery Management
4.6 Battery management Maximum battery life and reliability are obtained by the following features: Quick battery test • • • • The quick battery test checks whether the batteries and their wiring are healthy. If a quick battery test shows that the batteries are close to being worn out, a 'replace battery' alarm will be generated (see 4.4.8). -
Page 13: Usb / Rs232 / Relay Interface Card (Option)
5 - Communication 5.1 USB port The USB port is a plug-in interface port which enables advanced communication between the UPS and the computer (UPS software required). The interface port is operative as soon as the mains power cord is plugged into a live wall outlet, even if the UPS is switched off. For more information please refer to the user manual that comes with the interface software. - Page 14 7.4 Batteries 7.4.1 General The service life of the battery is from 3 to 6 years, depending on the operating temperature and on the number of discharge cycles. As a healthy battery is critical to the performance of the UPS, an automatic quick battery test is performed regularly to ensure failsafe operation (see section 4.6).
-
Page 15: Troubleshooting
8 - Troubleshooting Whenever a malfunction occurs, first check external factors (e.g. connections, temperature, humidity or load) to determine whether the problem is caused by the unit itself or by its environment. Subsequently check the thermal circuit breaker: it may be tripped. If so: reset it (see fig. 3.3.3 a/b) and be sure that the UPS is not overloaded.
