Automatic Commercial Ice Cube Machine
User's Manual / Manual del Usuario / Manuel de l'utilisateur
Be sure the ice machine has been standing upright for at least 24 hours prior to plug-in.
The Legacy Companies
Model
3355 Enterprise Ave, Suite 160
Ft Lauderdale, FL
MIM2 0
Tel.: 1-877-368-2797
E-mail: sales@thelegacycompanies.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIM20 and is the answer not in the manual?

Questions and answers

Related Manuals for The Legacy Companies MIM20

Summary of Contents for The Legacy Companies MIM20

  • Page 1 Automatic Commercial Ice Cube Machine User’s Manual / Manual del Usuario / Manuel de l’utilisateur Be sure the ice machine has been standing upright for at least 24 hours prior to plug-in. The Legacy Companies Model 3355 Enterprise Ave, Suite 160...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page ICE MAKER SAFETY........................2 IMPORTANT SAFEGUARDS ....................2 – 4 TECHNICAL INFORMATION ....................5 INTRODUCTION .........................5 COMPONENT LOCATIONS ........................ICE MAKER INSTALLATION 7 - 11 ......................Unpacking ..........................7 Installing the Adjustable Feet ....................7 Installing the Stability Brackets ......................Location Requirements ....................8 - 9 Electrical Requirements 9 - 10 ........................

  • Page 3: Ice Maker Safety

    ICE MAKER SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. This symbol alerts you to potential hazards that can injure or kill you and others.
  • Page 4 Plug into a grounded 3-prong outlet. Do not remove grounding prong, do not use an adapter, • and do not use an extension cord. It is recommended that a separate circuit, serving only your ice maker, be provided. Use • receptacles that cannot be turned off by a switch or pull chain.

  • Page 5: Save These Instructions

    Although the unit has been tested at the factory, due to long-term transit and storage, the first • batch of cubes must be discarded. If the ice maker will not be used for a long time, before the next use it must be thoroughly •...

  • Page 6: Technical Information

    It meets or exceeds the safety standard of UL563 and sanitation standard NSF12. The Legacy Companies, assumes no liability or responsibility of any kind for products manufactured by MaxxIce, that have been altered in any way, including the use of any parts and/or other components not specifically approved by The Legacy Companies.

  • Page 7: Component Locations

    Component Locations Top panel Door Evaporator (ice mold) Bin full probe Water tank Water tank screw nut Ice storage bin Front bottom louver Control panel cover Adjustable foot Back view Top view Water inlet 3/8” FPT (Female Pipe Thread) Power supply line Ice maker drain 1/2”...

  • Page 8: Ice Maker Installation

    Ice Maker Installation Unpacking Remove packaging materials IMPORTANT: Do not remove any permanent instruction labels or the data label on your ice maker. Remove tape and glue from your ice maker before using, To remove any remaining tape or glue, rub the area briskly with your thumb. Tape or glue •...

  • Page 9: Installing The Stability Brackets

    Installing the stability brackets This operation requires at least two persons. If you wish to install the ice maker in a free-standing mode rather than enclosed, it is necessary to attach the two metallic stability brackets that can be found packed inside the ice storage bin. Keeping the machine tilted to the right, but not more than 45˚, attach one bracket to the center of the underside of the ice maker with two screws (supplied).

  • Page 10: Electrical Requirements

    To ensure proper ventilation for your ice maker, the front of the unit must be completely • unobstructed. When installing the ice maker under a counter, follow the recommended spacing dimensions • shown. Allow at least 6” (150 mm) clearance at rear, and 1” (25 mm) at the sides and at the top for proper air circulation.

  • Page 11: Leveling The Ice Maker

    Before you move your ice maker into its final location, it is important to make sure you have the proper electrical connection. A standard electrical supply (120VAC only, 60Hz, 15A), properly grounded in accordance with the National Electrical Code and local codes and ordinances, is required.

  • Page 12: Installation Types

    IMPORTANT: 1. All installations must be in accordance with local plumbing code requirements. Professional installation is recommended. 2. Water inlet fitting: 3/8” FPT (Female Pipe Thread); drain line connection: 1/2” FPT. 3. Make certain you have a suitable water supply hose and two suitable drain hoses, and that the hoses are not pinched, kinked or damaged during installation.

  • Page 13: Operation

    Operation Final Check List before Operation 1. Have all packing materials and tape been removed from the interior and exterior of the ice maker? 2. Did you clean the ice storage bin? (See pages 15 - 17.) 3. Have the installation instructions been followed, including connecting the machine to water and electricity? 4.

  • Page 14: How The Machine Makes Ice

    • Never turn the water supply tap off when the ice maker is working. • Never touch the evaporator when the machine is running. • Except to take ice from the unit, keep the door closed to reduce melting and insure proper ice formation.

  • Page 15: Preparing The Ice Maker For Long Storage

    You may hear air being forced over the condenser by the condenser fan. • During the Harvest cycle, you may hear the sound of ice cubes falling into the ice storage • bin. Preparing the Ice Cube Machine for Long Storage If the ice cube machine will not be used for a long time, or it is to be moved to another place, it will be necessary to drain the system of water.

  • Page 16: Exterior Cleaning

    Exterior Cleaning The door and cabinet may be cleaned with a mild detergent and warm water solution such as 1 oz of dishwashing liquid mixed with 2 gallons of warm water. Do not use solvent-based or abrasive cleaners. Use a soft sponge and rinse with clean water. Wipe with a soft clean towel to prevent water spotting.

  • Page 17: Water Distribution Tube Cleaning

    Water Distribution Tube Cleaning When you find that the ice cubes are incompletely formed or the output of ice cubes is low, the water distribution tube may be blocked. Set the power switch to OFF. Unscrew the six screws holding the top panel and remove the panel. You will see the water distribution tube. Rotate the water distribution tube so that the holes in it are facing up.

  • Page 18: Sanitizing The Ice-Making System

    Sanitizing the Ice-Making System 1. Set the power switch to OFF. 2. Remove all ice cubes from the storage bin. 3. Prepare a sanitizing solution by mixing 1 oz. household bleach with 1 gallon of warm water. 4. Keep the ice maker connected to the water supply. Fill the water tank with the sanitizing solution.

  • Page 19: Control Panel

    Control Panel White LED Ice-full Clean Green LED Ice-making Mode Yellow LED Red LED Ice - harvest Descriptions of LEDs and buttons: Red LED: Power indicator   Ice Full indicator light. White LED: When this LED is lit, the ice storage bin is full of ice or something is holding the water curtain open.
  • Page 20 Thinner ice bridge setting: By pressing the “Clean” button, you can decrease the size of the ice bridge. The “ICE FULL” LED (white) will flash as you lower the ice bridge thickness and will finally be blinking at the setting of thinnest ice bridge.

  • Page 21: Troubleshooting

    Troubleshooting Before Calling for Service If the unit appears to be malfunctioning, read through the OPERATION section of this manual first. If the problem persists, check the Troubleshooting Guide below and on the following page. The problem may be something very simple that can be solved without a service call. Clean the condenser air screen.
  • Page 22 The ice cubes are The sprinkler is blocked. Clean the sprinkler. See Interior not completely Cleaning. formed when being dumped.
