- Page 1 Installation Guide VoiceLift VoiceLift Microphone System 68-1629-01 Rev. D 06 14...
-
Page 2: Safety Instructions
Safety Instructions Safety Instructions • English Инструкция по технике безопасности • Русский WARNING: This symbol, , when used on the product, is intended to ПРЕДУПРЕЖДЕНИЕ: Данный символ, , если указан alert the user of the presence of uninsulated dangerous voltage within the на... - Page 3 AVTrac, Cable Cubby, CrossPoint, eBUS, EDID Manager, EDID Minder, Extron, Flat Field, GlobalViewer, Hideaway, Inline, IP Intercom, IP Link, Key Minder, LockIt, MediaLink, PlenumVault, PoleVault, PowerCage, PURE3, Quantum, SoundField, SpeedMount, SpeedSwitch, System INTEGRATOR, TeamWork, TouchLink, V-Lock, VersaTools, VN-Matrix, VoiceLift, WallVault, WindoWall, XTP, and XTP Systems Registered Service Mark...
- Page 4 Conventions Used in this Guide Notifications The following notifications are used in this guide: Potential risk of severe injury or death. WARNING: AVERTISSEMENT : Risque potentiel de blessure grave ou de mort. CAUTION: Risk of minor personal injury. ATTENTION : Risque de blessure mineure. ATTENTION: •...
-
Page 5: Table Of Contents
Stage 2: Mounting the FF 20 Speakers ............1 ... 24 About this Guide ..........1 FF 120 Flat Field Ceiling Speakers ....24 About the VoiceLift System ......1 Speaker Cable ..........24 Application Diagram ........2 Procedure............25 Before You Begin — Planning the Installation ............ - Page 6 VoiceLift System Installation Guide • Contents...
-
Page 7: Introduction
This guide leads the installer through the steps to install and connect each component of the Extron VoiceLift System. The VoiceLift VLR 102 receiver can be installed in a drop ceiling, a standard junction box, an octagonal ceiling box, or a wall. It is assumed that the installer has some knowledge of and experience with audio/video, electrical, or electronic device installation. -
Page 8: Application Diagram
Each VoiceLift system contains a feedback suppressor (FBS) that eliminates feedback caused by high microphone levels, room resonance, or proximity of the microphone to the speakers. If feedback occurs, up to 15 dynamic filters engage, automatically detecting and attenuating unwanted feedback frequencies up to 30 dB. -
Page 9: Before You Begin - Planning The Installation
Before you begin the installation, consider the major factors discussed in the following sections to ensure that the installation of the VoiceLift System is as smooth and trouble free as possible and that the result meets the needs of the users. Placement of the receiver (sensor location) is very important for optimal performance of the VoiceLift System. -
Page 10: Room Considerations
VoiceLift system: Interference and noise sources Infrared and radio frequency noise can reduce the performance of the microphone system. To minimize noise in the system, avoid mounting the VoiceLift receiver near the following items: • Lighting, fluorescent or incandescent — Keep the receiver at least 2 feet (61 cm) away from a light source. - Page 11 Support pillars • I-beams • Projectors VLR 102 Ceiling Receiver Beams B lu e Ja ra du at io Cl ass of 20 ’s Sta Not Good Extron Extr Figure 5. Potential Line-of-Sight Obstructions VoiceLift System Installation Guide • Introduction...
- Page 12 Curtains and blinds • Furniture (such as bookcases or easels) VLR 102 Receiver B lu e Ja ra du at io Cl ass of 20 ’s Sta Good Not Good Extron Extr Figure 6. Reflective Surfaces VoiceLift System Installation Guide • Introduction...
-
Page 13: Receiver Location
Potential TV / VCR / DVD VLR 102 IR Inputs Receiver Locations MLC Controller Location Ceiling Mount Wall Mount Projector and Switcher Location Speaker Locations Student Desks Figure 7. Diagram of a Classroom Installation VoiceLift System Installation Guide • Introduction... -
Page 14: Polevault Switcher Location
Possible switcher mounting locations include: • On a desk • Mounted to a wall • Under a desk • Mounted to a ceiling pole • In a cabinet • Above a drop ceiling (The PVS is plenum rated.) VoiceLift System Installation Guide • Introduction... -
Page 15: Inventory
Inventory VoiceLift VLM System Kits Devices and Hardware The VoiceLift VLM System kit is shipped in one box and is available in three package configurations: • VLM 1000: Contains one VLP 202 Pendant Microphone, a VLR 102 Receiver, and a wall charger. - Page 16 (1) 3-pole Captive Screw Connector VoiceLift User Wall Charger/ Installation Card Power Supply NOTE: If any items in the VoiceLift VLM System are damaged or missing, contact the Extron S Sales and Technical Support Hotline (see the rear cover for contact numbers).
-
Page 17: Voicelift Vls System Kits Devices And Hardware
VoiceLift VLS System Kits Devices and Hardware The VoiceLift VLS System kit is available in three packaged configurations: • VLS 1000: Contains one VLP 202 Pendant Microphone, a VLR 102 Receiver, a wall charger, and two FF 120 Flat Field speakers. - Page 18 100 Feet (30.4 m) Speaker Cable Microphone Label Set VoiceLift User Installation Card NOTE: If any items in the VoiceLift System or FF 120 boxes are damaged or missing, rear cover contact the Extron S Sales and Technical Support Hotline (see contact numbers).
-
Page 19: Installation Tools
Installation Tools Extron recommends the following equipment (not provided) to ensure that the VoiceLift System is properly installed. Marker Pen, Pencil Handsaw for Safety Goggles Cutting Drywall Utility Knives Tools for Terminating Cable RJ-45 Crimpers and Connectors Flashlight Tape Measure... -
Page 20: Items Not Included
The optional items listed below can be added to or substituted for items in the standard VoiceLift System kits. • VLP 202 Pendant Microphone (additional) or VLH 102 Handheld Microphone • PVS 305SA mounting options WMK 150 WallVault wall mounting kit • PMK 550 pole mounting kit • VoiceLift System Installation Guide • Introduction... -
Page 21: Installation Overview
Installation Overview This section provides an overview of the five stages of installation for the VoiceLift system and the steps required for each stage. Stage 1 — Install the VLR 102 Receiver Choose one of these installation types: 1a. Drop ceiling Cut a hole in the ceiling tile (page 19). -
Page 22: Stage 4 - Connect The Vlr 102 Receiver To The Polevault System
(page 38). Installation Procedures The following sections contain instructions for installing the VoiceLift System. Where possible, line drawings and photos from an actual installation are used to clarify some of the steps discussed in the text. Each image has a circled number corresponding to the step that is being described. -
Page 23: Stage 1: Mounting The Receiver
The bracket is attached to the screw on the back of the ceiling tile. What it does: Fastens the receiver to a tile in a drop ceiling. VoiceLift System Installation Guide • Installation — Stage 1... - Page 24 VoiceLift Receiver on a Pole (page Figure 11. Diagrams of Stage 1 Mounting Options NOTE: Observe all local and national building and safety codes to ensure that the installation meets all regulatory standards. VoiceLift System Installation Guide • Installation — Stage 1...
-
Page 25: Stage 1A - Installing The Receiver In A Drop Ceiling
3. (Optional) Attach a conduit to the back plate if needed (see figure NOTE: Observe all local and national building and safety codes. 4. Replace the ceiling tile. Attach a conduit to the back plate if desired. VoiceLift System Installation Guide • Installation — Stage 1... -
Page 26: Stage 1B - Installing The Receiver To A Junction Box
(not included). 3. Attach a conduit to the junction box if needed. NOTE: Observe all local and national building and safety codes. Attach a conduit to the junction box if needed. VoiceLift System Installation Guide • Installation — Stage 1... -
Page 27: Stage 1C - Installing The Receiver On A Wall Or Other Hard Surface
Use a knife to score around the edge of the selected raceway knockout to create a clean edge. Press on the scored section to remove it. Remove a raceway knockout from the housing, if needed. VoiceLift System Installation Guide • Installation — Stage 1... - Page 28 (Screws and wall anchors are not included.) Mounting without a raceway If using a raceway: Position the receiver housing with the raceway inserted through the knockout. Mounting with a raceway VoiceLift System Installation Guide • Installation — Stage 1...
-
Page 29: Stage 1D - Installing The Receiver On A Pole
Attach a ¾-inch connector to the pole. Replace the lock nut onto the connector and tighten it to secure the connector to the housing. – Attach the pole to the receiver back × Ø plate. VoiceLift System Installation Guide • Installation — Stage 1... -
Page 30: Stage 2: Mounting The Ff 20 Speakers
Receive and output the audio signal from the PVS 305SA IP switcher. Speaker Cable SPK 18, 35 feet (10.6 m) Figure 13. SPK 18 Speaker Cable What it does: For speaker installation, connects the ceiling speakers to the switcher. VoiceLift System Installation Guide • Installation — Stage 2... -
Page 31: Speaker Mounting Procedure
T-rails. Remove the terminal cover and attach the Ö Replace the ceiling tile. clamp and ring to it. Repeat steps 2a through 2f for each speaker that needs to be installed. VoiceLift System Installation Guide • Installation — Stage 2... - Page 32 4-pole Captive Screw Connector AMPLIFIED OUTPUTS Speaker To PVS 305SA IP Ohms Wire Color Terminal (Left and Right) PVS Switcher Rear Panel Positive (+) Black Negative (-) Wire the captive screw connector. VoiceLift System Installation Guide • Installation — Stage 2...
- Page 33 Switcher Control software or the Extron Special Instruction Set (SIS ) commands to change ™ the setting to stereo if desired. For full details, see the PVS 305SA IP PoleVault Switcher User www.extron.com. Guide, available at VoiceLift System Installation Guide • Installation — Stage 2...
-
Page 34: Stage 3: Installing The Polevault Switcher
® What it does: Receives input video and audio signals from A/V source input wall plates and audio signals from the VoiceLift VLR 102 Receiver. Outputs and switches the signals to a projector and ceiling speakers. VoiceLift System Installation Guide • Installation — Stage 3... -
Page 35: Polevault Switcher Installation
Make sure that the PVS 305SA IP front and rear panels are accessible until installation and testing of the VoiceLift System is complete. WMK 150 WallVault Wall Mount Kit Remove the large knockout (outer ring). VoiceLift System Installation Guide • Installation — Stage 3... -
Page 36: Stage 4: Connecting The Cables
Use a CAT 5, 5E, 6, 7 screened shielded twisted pair cable with T568A or T568B straight-through wiring. Where it goes: Attaches to the receiver RJ-45 Out port and to the VoiceLift Receiver RJ-45 port on the PVS 305SA IP switcher. What it does: Provides power to the receiver and enables communication and audio between the receiver and the PoleVault switcher. -
Page 37: Procedure
Connect the STP cable to the Receiver Out port (the RJ-45 connector closest to the DIP switches on the receiver base). Connect the STP cable to the Receiver Out Õ RJ-45 port. VoiceLift System Installation Guide • Installation — Stage 4... - Page 38 Arrow slots in the base. Arrow on Housing Align Arrows Twist to Arrow Lock Arrow on Tab Receiver Dome Align the arrows on the housing rim and the Ü dome tab. VoiceLift System Installation Guide • Installation — Stage 4...
- Page 39 VLS systems to the PoleVault switcher location. Run the cables down through the projector pole and the PMK mounting bracket. Run the cables through the projector pole å and the PMK 550. VoiceLift System Installation Guide • Installation — Stage 4...
- Page 40 Reconnect the power cable to the switcher. VoiceLift Receiver Port – Connect the STP cable and the ë ì speaker cables to the switcher. Figure 18. Connecting the Receiver to a PVS 305SA IP Switcher VoiceLift System Installation Guide • Installation — Stage 4...
-
Page 41: Stage 5: Testing The System
Stage 5: Testing the System This stage consists of configuring, setting up, and testing the VoiceLift System. 1. Set up the microphones. Set up each microphone in your VoiceLift system as follows: Set the channels using the rotary switch. A and C are at 2.3 MHz, and B and D are at... - Page 42 LEDs on the microphone and receiver should light green. If the microphone has been in operation, cycle power on the receiver to clear any existing Power Switch filters. Power Switch Power on the microphone. Õ VoiceLift System Installation Guide • Installation — Stage 5...
- Page 43 Volume Up Volume Up VOLUME Volume Down Volume Down – Volume Up and Down buttons on the Ù Ú VoiceLift microphone. VoiceLift System Installation Guide • Installation — Stage 5...
- Page 44 Complete the mounting and installation of the PoleVault switcher if necessary. Slide cover inward to pole. PoleVault Switcher Cable Access Slot Projector Pole Cable Slot Cover Reattach the bottom of the PMK 550. Ý VoiceLift System Installation Guide • Installation — Stage 5...
-
Page 45: Installation Example - Setting Up An Instant Alert
Contact input (CTC), the Aux Input (Aux In), or the RS-232 port (see the illustration at right). Connect a communication cable to the Ï VLR 102 Rly port. VoiceLift System Installation Guide • Installation Example... - Page 46 Check for the arrival of the e-mail notification. Press and hold both Press and hold halves of the Volume both Volume button simultaneously. VOLUME buttons simultaneously. Press and hold both Volume buttons for Ý 3 seconds. VoiceLift System Installation Guide • Installation Example...
- Page 47 Extron Electronics makes no further warranties either expressed or implied with respect to the product and its quality, performance, merchantability, or fitness for any particular use. In no event will Extron Electronics be liable for direct, indirect, or consequential damages resulting from any defect in this product even if Extron Electronics has been advised of such damage.
