PARTS LIST
REF.NO.
PART NO.
D2153
407 105 1602 VARACTOR DI SVC342M-V
or
407 105 1305 VARACTOR DI SVC342L-V
D2451
407 012 4406 DIODE 1SS133
D2452
407 153 7502 ZENER DIODE GZS3.0B
D2453
407 012 4406 DIODE 1SS133
D2456
407 012 4406 DIODE 1SS133
D2466
407 012 4406 DIODE 1SS133
D4951
407 099 6102 ZENER DIODE MTZJ10B
D4953
407 012 4406 DIODE 1SS133
D4954
407 012 4406 DIODE 1SS133
D4960
407 012 4406 DIODE 1SS133
D4961
407 012 4406 DIODE 1SS133
D4993
407 012 4406 DIODE 1SS133
HS401
614 319 7065 HEAT SINK
IC211
409 016 0200 IC LA1186N-AUDIO
IC231
409 474 3201 IC LA1844ML
IC241
409 439 4502 IC LC72121M-D
IC440
409 451 7406 IC AN7348K
IC441
409 474 6103 IC LC75342M
IC442
409 295 7402 IC TA8229K
IC443
409 189 3404 IC BA7755A
IC446
409 039 9204 IC NJM78L05A
L2102
645 040 2753 INDUCTOR,AIR —
L2103
645 040 2746 COIL,AIR —
L2104
645 002 1534 INDUCTOR,8.2U K
L2151
645 037 2377 TRANS,ANT,796KHZ
L2153
645 040 2739 TRANS,OSC,796KHZ
L2451
645 031 7842 INDUCTOR,100U K
or
645 001 4581 INDUCTOR,100U K
L4600
645 006 1523 INDUCTOR,470U J
L4601
645 006 1523 INDUCTOR,470U J
L4602
645 037 2858 CORE,PIPE
L4603
645 006 1523 INDUCTOR,470U J
L4604
645 037 2858 CORE,PIPE
L4781
645 002 1459 INDUCTOR,22U K
L4782
645 002 1459 INDUCTOR,22U K
L4881
645 002 1459 INDUCTOR,22U K
L4882
645 002 1459 INDUCTOR,22U K
L4981
645 002 1459 INDUCTOR,22U K
PR495
645 042 2621 PROTECTOR,1.5A 125V
PR496
645 042 2621 PROTECTOR,1.5A 125V
Q2201
405 151 4301 TR KTC3195-Y
or
405 151 4806 TR KTC3195-O
Q2451
405 036 3702 TR 2SA1564
or
405 151 5209 TR KRA107M
or
405 000 0904 TR DTA114YS
or
405 078 2404 TR BN1A4P
Q4410
405 141 3406 TR KTA1266-GR
or
405 141 3505 TR KTA1266-Y
or
405 004 4502 TR 2SA608-F-NP
or
405 004 5004 TR 2SA608-G-NP
Q4600
405 155 0002 TR MPSA56
Q4601
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4602
405 019 3804 TR 2SC536-G-NP
or
405 019 2708 TR 2SC536-F-NP
or
405 141 3307 TR KTC3198-GR
or
405 141 3208 TR KTC3198-Y
Q4603
405 019 2708 TR 2SC536-F-NP
or
405 019 3804 TR 2SC536-G-NP
or
405 141 3208 TR KTC3198-Y
or
405 141 3307 TR KTC3198-GR
Q4700
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4701
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4751
405 151 4400 TR KTD1303
or
405 021 0204 TR 2SD1012-F-SPA
or
405 021 0600 TR 2SD1012-G-SPA
or
405 033 6706 TR 2SD1468S-R
or
405 033 6805 TR 2SD1468S-S
Q4800
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
DESCRIPTION
REF.NO.
PART NO.
Q4801
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4851
405 033 6706 TR 2SD1468S-R
or
405 033 6805 TR 2SD1468S-S
or
405 021 0600 TR 2SD1012-G-SPA
or
405 021 0204 TR 2SD1012-F-SPA
or
405 151 4400 TR KTD1303
Q4930
405 141 3307 TR KTC3198-GR
or
405 141 3208 TR KTC3198-Y
or
405 019 2708 TR 2SC536-F-NP
or
405 019 3804 TR 2SC536-G-NP
Q4931
405 000 0508 TR DTA114ES
or
405 110 5400 TR KRA102M-A
Q4951
405 138 6403 TR KTD2058Y
or
405 095 1602 TR 2SD2061-E
or
405 095 1701 TR 2SD2061-F
Q4960
405 155 0002 TR MPSA56
Q4961
405 155 0002 TR MPSA56
Q4962
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4963
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4992
405 141 3703 TR KTA1271-Y
or
405 008 2405 TR 2SB698-F
or
405 008 2504 TR 2SB698-G
Q4993
405 000 3806 TR DTC114YS
or
405 143 0007 TR KRC107M
Q4995
405 141 3703 TR KTA1271-Y
or
405 008 2405 TR 2SB698-F
or
405 008 2504 TR 2SB698-G
R4940
402 081 0205 FUSIBLE RES 27 JA 1/4W
S2001
645 023 5795 SWITCH,LEVER
SA401
411 021 6405 SCR S-TPG BIN 3X8
SA402
411 021 6405 SCR S-TPG BIN 3X8
T2002
645 046 2023 FILTER,450KHZ
or
645 060 4072 FILTER,450KHZ
X2451
645 023 4965 OSC,CRYSTAL 7.2MHZ
XF211
645 059 0047 FILTER,BP
or
645 026 2975 FILTER,BP 108MHZ
or
614 252 1045 FILTER,LC
XF221
645 054 1223 CERAMIC FILTER 10.70MHZ
or
645 010 7665 CERAMIC FILTER 10.70MHZ
or
614 240 2917 FILTER,CERAM
XF222
645 054 1223 CERAMIC FILTER 10.70MHZ
or
645 010 7665 CERAMIC FILTER 10.70MHZ
or
614 240 2917 FILTER,CERAM
XF231
645 059 0054 CERAMIC FILTER 450KHZ
or
645 041 9324 CERAMIC FILTER 450KHZ
XF233
645 040 9981 TRANS,IF 10.7MHZ
or
645 039 9923 TRANS,IF 10.7MHZ
or
645 060 4089 TRANS,IF 10.7MHZ
POWER TRANSFORMER P.W.BOARD ASSY
REF.NO.
PART NO.
74
614 325 7196 ASSY,PWB,DG (Only Initial)
CN215
645 006 4760 HOLDER,FUSE
or
645 031 7903 HOLDER,FUSE
CN216
645 006 4760 HOLDER,FUSE
or
645 031 7903 HOLDER,FUSE
CN420
614 020 1215 SOCKET,2P
CN421
614 322 2262 ASSY,WIRE,PT-AMPWIRE
CN422
614 017 8203 TERMINAL BOARD
CN423
614 017 8203 TERMINAL BOARD
D4280
407 098 3300 DIODE RL153-BF-S2
D4281
407 098 3300 DIODE RL153-BF-S2
D4282
407 098 3300 DIODE RL153-BF-S2
D4283
407 098 3300 DIODE RL153-BF-S2
L4291
645 038 6053 INDUCTOR,181U
or
645 041 3087 INDUCTOR,180U
- 6 -
