Lindy 25032 Short Manual

24 + 2Giga N-WAY SNMP Ethernet Switch
Short Guide
LINDY No. 25032
LINDY No. 25033
LINDY No. 25034
LINDY No. 25035
LINDY No. 25036
Please find the complete detailed user manual in PDF format on
the CD-ROM enclosed with the 24+2Giga SNMP N-Way Switch.

Unpacking

The product should contain the following items:
o One module according to the LINDY part number, check from Part No. above.
o This Short Guide

Installation

Before you install the module in the 24+2Giga SNMP Switch, turn off the power to the switch.
Unscrew the face plate of the module slot, this is on the front of the 24+2Giga SNMP Switch.
Then install the module by fixing the two module screws. Switch on the power to 24+2Giga
SNMP switch again.
After the Switch is powered on, it will perform "self-diagnostic" (POSD). This process takes
about 1 min and 40 seconds to complete, during this process, the "DIAG" LED will blink green
and the Switch will not respond to any configuration program. All the connections to the Switch
will not be available at this time. When the process is completed, the "DIAG" LED will stay solid
green.
The following table describes the meaning of each LED indicator.
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (JUNE 2003)
Modules for
2 Port RJ-45 Gigabit 10/100/1000Base-T
1 Port Fibre Optic Gigabit Type SC 1000Base-SX
2 Port Fibre Optic Gigabit Type SC 1000Base-SX
1 Port Fibre Optic Fast Ethernet Type SC 100Base-FX
2 Port Fibre Optic Fast Ethernet Type SC 100Base-FX
English
