- Page 1 MAWB-A26 Item ref: 130.021UK CLAMP ON WIDEBAND MIXER User Manual AERIAL Diplexers F plug coax leads Mounting clips...
- Page 2 INTRODUCTION: Thank you for choosing this Mercury aerial. This aerial is designed for the reception of FM, DAB and UHF digital TV signals. It is designed to clamp onto a satellite dish and does not need a mast. With a built-in low noise signal amplifier and mixer, it boosts the signals and transmits them along the same coax cables as the satellite signals.
- Page 3 Step 2: Position the aerial on top of the dish with dipole box at the back of the satellite dish; ensure the Mercury logo is facing outward. Put the mounting clamps over the edge of the satellite dish one by one and attach the loose end back on the aerial.
- Page 4 Step 6: On existing installations, connect the cables removed from LNB to the mix outputs on the aerial. Otherwise run the cables neatly to the satellite receiver. Step 7: At the end of the cable connect the diplexer as shown in the diagram below. (To split the satellite and terrestrial signals).
