HaWeKo
More than only Consoles!
Brunnenstr. 55
70372 Stuttgart
Tel: +49 711 / 794821 03
Fax: +49 711 / 794821 05
Mail: info@HaWeKo24.de
Web: www.HaWeKo24.de
Caution:
Due to safety reasons pay attention to the course of existing, also non-visible cables, wires and other
components which are situated in the installation area!
Note:
The console and the components are to be installed in such a way that for the passengers no dangers
of injury (e.g. by sharp edges) develops.
Installation Instructions for Telephone
Daewoo Kalos, MY 09/02-
Item-
No.:
Console
DAK080 / 085
Illustration 1:
Remove the small hider on the right side of the radio
with a flat object.
Illustration 2:
Put the hider aside.
Illustration 3:
Place the console on the right side of the radio so that
the two left sheet metals of the console grip into the
radio area.
Fasten the upper sheet metal (see arrow) with a self-
tapping screw.
as at March-04
Page 1 of 2
