Caution!
Due to safety reasons pay attention to the course of existing, also non-visible cables, wires and other
components which are situated in the installation area!
The console and the components are to be installed in such a way that for the passengers no dangers
of injury (i.e. by sharp edges) develop.
Installation Instructions for Telephone
Iveco Stralis active day / time
Item-
No.:
Console
MY 02/02-
IVK000 / 005
Illustration1:
Pull off the bracket (see arrow) and put aside.
Illustration 2:
Unscrew the original screw (see arrow) and put aside.
Illustration 3:
Unscrew the original screw (see arrow) and put
aside.
Perfect
Fit
As at: Nov 05
Page 1 of 7
