  • Page 1 NPT-5851 User Manual Version V1.0 AUG 2012...
  • Page 2 Copyright 2012 All Rights Reserved Manual Version 1.0 Model Number: NPT-5851 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS 1. To disconnect the machine from the electrical power supply, turn off the power switch and remove the power cord plug from the wall socket. 2. The wall socket must be easily accessible and in close proximity to the machine. 3.

  • Page 4: Legislation And Weee Symbol

    CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive” This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.

  • Page 5: Revision History

    Revision History Changes to the original user manual are listed below: Version Date Description  AUG. 2012 Initial release...

  • Page 6: Table Of Contents

    Table of Contents 1. Package Checklist……………..............1-1 Standard items…………………………………………………………………….. 1-2 Optional items……………………………………………………………………... 2. System View………………………………………………………………..3. System Assembly & Disassembly………………………………………… 3-1 Replace the HDD…………………………………………………………………..3-2 Replace the Motherboard………………………………………………………….. 3-3 Replace the Inverter Board & Touch Board…………………………………..3-4 Install & Uninstall the Filter…………………………………....... 3-5 Install VFD &...

  • Page 7: Package Checklist

    Package Checklist Standard items a. System b. power adapter Optional items a. Second Display b. Second Display (Pole Type) c. MSR d. VFD e. driver bank/e-User Manual f. power cord...

  • Page 8: System View

    System View Front View Rear View Description Touch Screen MSR/2-in-1 MSR (Option) Power Button & Power LED Model No. Label & OS License Label Stand Cables outlet Heat sink Side View Top View Description VFD (OPTION) System Box (Inside with Motherboard) Vesa Cover Cables outlet...
  • Page 9 Rear I/O View Description DC 19V IN Cash Drawer Port USB (x4) LAN (10/100/1000) COM(x4) 2nd VGA DC 12V OUT 2.5 HDD Parallel port Line OUT...

  • Page 10: System Assembly & Disassembly

    System Assembly & Disassembly 3-1 Replace the HDD a. Unfasten the screws (x2) to remove the HDD cover. b. Disconnect the HDD Cable and take out the HDD with HDD metal handle. c. Unfasten the screws (x4) at both sides of HDD metal bracket. d.

  • Page 11: Replace The Motherboard

    3-2 Replace the Motherboard To replace the motherboard, please follow the below steps: (1) Disconnect the HDD cable from the motherboard (Chapter 3-1, step a,b) (2) Open the system box to access the motherboard (See below) a. Unfasten the screws(x11) on the back of system box. Press the Front bezel then separate top and bottom chassis(L1、L2).

  • Page 12: Replace The Inverter Board & Touch Board

    3-3 Replace the Inverter Board & Touch Board 3-3-1 Replace the Inverter Board a. The location of Inverter board on the LCD sheet metal bracket. b. Unfasten the screws (x2). c. Disconnect the cables (x3). 3-3-2 Replace the Touch Board a.

  • Page 13: Install & Uninstall The Filter

    3-4 Install & Uninstall the Filter The device uses a filter that is washable and reusable. Insert the filter inside the pocket in the rear cover bracket, the handle backward the device and secure the filter with socket hole. Draw out the filter from the pocket in the rear cover bracket (Tip: get the snap out of the socket hole first)

  • Page 14: Install Vfd & Msr (Optional)

    3-5 Install VFD & MSR (Optional) 3-5-1 VFD install a. Unfasten the screws. b. Install VFD Module on the rear cover. c. Tighten the screws. 3-5-2 MSR install a. Unfasten the screws. b. Pull the MSR cover from rear cover. c.

  • Page 15: Specification

    Specification Model Name NPT-5851 Motherboard NP-HM651 Default: Intel® Pentium® Processor B940, 2C/2T, 2.0 GHz, 2MB Cache; Upgrade Optional: B950, 2C/2T, 2.10GHz, 2MB Cache; or 2nd Generation Intel® Core Mobile Processor: Processor i7-2710QE, 4C/8T, BF_2.1GHz/ 1CT_3.0GHz/ 2CT_2.9GHz, 6MB Cache. i5-2510E, 2C/4T, BF_2.5GHz/ 1CT_3.1GHz/ 2CT_3.0GHz, 3MB Cache.
  • Page 16 System Buzzer 1 x System Buzzer Internal Speaker 1 x 3W Speaker System Control/ Indicator Power Switch 1 x Power ON/OFF switch Power LED 1 x Power ON LED (Green) Power Power Supply External AC-DC 19V/ 6.31A 120W Power Brick Peripheral (Optional) ISO 3 Tracks MSR (USB or PS/2) Customer Display...

  • Page 17: Jumper Settings

    Jumper Settings 5-1 HM-651 Motherboard Layout...

  • Page 18: Connectors Description

    5-2 Connectors Description Connector Purpose Connector Purpose COM5 Internal connector SATA 3 Connector COM6 Internal connector SATA 3 Connector MINI PCI-E Sim card holder LVDS Connector 48 Bit LVDS Connector 48 Bit CN10 Line-out & MIC CN11 Print port CN12 COM4 Internal connector CN13 VGA Connector...

  • Page 19: Jumper Settings

    5-3 Jumper Settings Panel Power selection:JP5 Function JP1 (1-2) (2-3) ◎3.3V VCC 5V ◎Default setting 1-2 short. CMOS CLEAR SIGNAL: JP2 Function JP1 (1-2) (2-3) ◎NORMAL CLEAR CMOS ◎Default setting 1-2 short. Note:...

  • Page 20: Install A Cash Drawer

    5-4 Install a Cash Drawer You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal CASEOPEN2# CASH1_P CASEOPEN# CASH2_P Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.

  • Page 21: Bios Settings

    This chapter describes how to use the BIOS setup program for NPT-5850 Series. The BIOS screens in this chapter are for reference only and may change if the BIOS is updated in the future. To check for the latest updates and revisions, visit the NEXCOM Web site at www.nexcom.com.tw.
  • Page 22 system features need to be changed. Default Configuration Most of the configuration settings are either predefined according to the Load Optimal Defaults settings which are stored in the BIOS or are automatically detected and configured without requiring any actions. There are a few settings that you may need to change depending on your system configuration.

  • Page 23: Main

    6-2 Main The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. BIOS Information Displays the detected BIOS information. Memory Information Displays the detected system memory information. ME Firmware Information Displays the detected ME Firmware information. System Date The date format is <day>, <month>, <date>, <year>.
  • Page 24 System Time The time format is <hour>, <minute>, <second>. The time is based on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays seconds from 00 to 59.

  • Page 25: Advanced

    6-3 Advanced The Advanced menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference. Setting incorrect field values may cause the system to malfunction.
  • Page 26 AMT Configuration Configures the AMT function. USB Configuration Configures the USB devices. Second Super IO Configuration The Section is used to configure the I/O function supported by on board Super I/O chip. Super IO Configuration This section is used to configure the I/O functions supported by the onboard Super I/O chip.
  • Page 27 Enables or Disable System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS. Default:[Enabled] ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Default:[S3 (Suspend to RAM) CPU Configuration This section is used to configure the CPU.
  • Page 28 Hyper-Threading Enable this field for Windows XP and Linux which are optimized for Hyper-Threading technology. Select disabled for other OSes not optimized for Hyper-Threading technology. When disabled, only one thread per enabled core is enabled. Default:[Enabled] Hardware Prefetcher Turns on or off the MLC steamer prefetcher Default:[Enabled] Intel Virtualization Technology When this field is set to Enable, the VMM can utilize the additional hardware...
  • Page 29 SATA Configuration This section is used to configure the SATA drives. SATA Mode SATA Controller Enble or disable SATA Device Default: [Enabled] SATA Mode Selection Determines how SATA controller(s) operate. Default: [IDE]...
  • Page 30 AMT Configuration Configures the Active Management Technology function. USB Configuration...
  • Page 31 Configures the USB devices. Legacy USB Support Enabled - Enables legacy USB. Auto - Disables support for legacy when no USB devices are connected. Disabled - Keeps USB devices available only for EFI applications. Default: [Enabled] EHCI Hand-off This is a workaround for OSes that does not support EHCI hand-off. TheEHCI ownership change should be claimed by the EHCI driver.
  • Page 32 Serial Port 3 Configuration to Serial Port 6 Configuration Selects the IO/IRQ setting of the I/O devices.
  • Page 33 Super IO Configuration This section is used to configure the I/O functions supported by the onboard Super I/O chip. Serial Port 1 Configuration to Serial Port 2 Configuration This section is used to configure the I/O functions supported by the onboard Super I/O chip.
  • Page 34 H/W Monitor This section is used to configure the hardware monitoring events such as temperature, fan speed and voltages. System Temperature 1 to System Temperature 2 and CPU core Temperature Detects and displays the internal temperature of the system. Fan1 Speed to Fan2 Speed Detects and displays the current system fan and CPU fan speed in RPM (Revolutions Per Minute).
  • Page 35 Vcore to +5V Detects and displays the output voltages. Sandybridge PPM Configuration This section is used to configure Sandy bridge PPM Configuration Parameters.
  • Page 36 EIST Enable/Disable Intel SpeedStep Default: [Disabled] CPU C3 Report Enable/Disable CPU C3(ACPI C2) report to OS Default: [Disabled] CPU C6 Report Enable/Disable CPU C6 (ACPI C6) report to OS Default: [Disabled] CPU C7 Report Enable/Disable CPU C7 (ACPI C7) report to OS Default: [Disabled]...

  • Page 37: Chipset

    6-4 Chipset System Agent (SA) Configuration System Agent (SA) Parameters PCH-IO Configuration PCH-IO parameters...
  • Page 38 Intel IGFX Configuration Selects the Graphic chip setting of Intel IGFX Configuration. Aperture Size Set Aperture Size Default:[256MB] DVNT Pre-Allocation Internal graphic memory size Default:[256M] DVMT Total GFX Mem Select DVNT5.0 total graphic memory size Default:[256M]...
  • Page 39 Primary IGFX Boot Display Select Video Device which will be activated during POS. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VFA modes will be supported only on primary display. Default:[CRT] Secondary IGFX Boot Display Select Secondary Display Device...
  • Page 40 PCH-IO Configuration PCH-IO parameters PCH LAN Controller Enables or disables onboard NIC. Default: [Enable] Wake on LAN Enable Enables or disables integrated LAN to wake the system. Default: [Disabled] Azalia Control Detection of the Azalia device. Disabled - Azalia will be unconditionally disabled.
  • Page 41 Enabled - Azalia will be unconditionally Enabled. Auto - Azalia will be enabled if present, disabled otherwise. Default: [Auto] SLP_S4 Assertion Width Select a minimum assertion width of the SLP_S4# signal Default: [4-5 Seconds] Restore AC Power Loss Select AC power state when power is re-applied after a power failure. Default: [Power off] 3G/ Wifi Module Type Allows BIOS to Select 3G/Wifi Module with/Without Voice function.

  • Page 42: Boot

    6-5 Boot Quiet Boot Enables or disables the quiet boot function. Default: [Enable] Boot Option #1 and Boot Option #2 Selects the boot sequence of the hard drives. Hard Drive BBS Priorities Sets the order of the legacy devices in this group.

  • Page 43: Security

    6-6 Security Administrator Password Sets the administrator password. User Password Sets the user password...

  • Page 44: Save & Exit

    6-7 Save & Exit Save Changes and Exit To save the changes and exit the Setup utility, select this field then press <Enter>. A dialog box will appear. Confirm by selecting Yes. You can also press <F4> to save and exit Setup. Discard Changes and Exit To exit the Setup utility without saving the changes, select this field then press <Enter>.

  • Page 45: Appendix

    Appendix Drivers Installation: The shipping package includes a Driver CD. You can find every individual driver and utility that enables you to install the drivers in the Driver CD. Please insert the Driver CD into the drive and double click on the “index.htm” to pick up the models.
