- Page 1 INSTALLATION & OPERATING INSTRUCTIONS ® REDCO WEDGEMASTER II™ P/N: 2810320-1 REV: C...
- Page 2 WARNING AND SAFETY INFORMATION WARNING THIS MACHINE CONTAINS SHARP BLADES AND CAN CAUSE SERIOUS INJURY OR DEATH IF NOT HANDLED PROPERLY. ALL OPERATORS OF THIS EQUIPMENT SHOULD READ THIS OPERATION MANUAL BEFORE OPERATING EQUIPMENT. IN ORDER TO AVOID DAMAGE TO PEOPLE AND THE APPLIANCE, READ AND FOLLOW THE MANUFACTURER’S INSTRUCTIONS FOR THE CLEANING OF THIS EQUIPMENT.
-
Page 3: Operation Instructions
CAUTION Blades are sharp and can cause injury. Check machine before using. Be sure machine is clean. Check for broken, nicked or dull blades and if found, replace blade assembly. Check to be sure Pusher Head Assembly can move freely. Lubricate if necessary using a light coating of mineral oil, Petrol Gel or food grade lubricant. DO NOT LUBRICATE WITH COOKING OIL AS IT WILL BECOME STICKY. - Page 4 BLADE SERVICING AND REPLACEMENT If the machine no longer slices cleanly or without damage, the blades could be dull and need to be replaced. Broken, bent, nicked, or dull blades must be replaced immediately. Change the complete assembly. HANDLE WITH EXTREME CARE AS BLADES ARE SHARP AND CAN CAUSE INJURY OR DEATH IF NOT HANDLED PROPERLY.
- Page 5 This page intentionally left blank. Wedgemaster II Ops Manual...
-
Page 6: Spare Parts
SPARE PARTS PART LETTER DESCRIPTION NUMBER 379107 Pusher Assembly, 6 / 12 Section 379108 Pusher Assembly, 4 / 8 Section 379109 Base Assembly Blade Assembly, 4 Section Blade Assembly, 6 Section Blade Assembly, 8 Section Blade Assembly, 12 Section ‘O’ Ring 379103 Foot Cover Wedgemaster II Ops Manual... - Page 7 EXPLODED VIEW – WEDGEMASTER II A, B D, E, F, G Wedgemaster II Ops Manual...
- Page 8 Lincoln Foodservice Product, LLC 1111 North Hadley Road Fort Wayne, Indiana 46804 United States of America Telephone: (260) 459-8200 U.S. Fax: (888) 790-8193 Int’l Fax: (260) 436-0735 Technical Support Hotline: (800) 678-9511 www.lincolnsmallwares.com Wedgemaster II Ops Manual...
