SERVICE MANUAL
MODEL TYPE: YS1066
E10P
WEB ACCESS: http://www.yorkville.com
WORLD HEADQUARTERS
CANADA
U.S.A.
Yorkville Sound
Yorkville Sound Inc.
550 Granite Court
4625 Witmer Industrial Estate
Pickering, Ontario
Niagara Falls, New York
L1W-3Y8 CANADA
14305 USA
Voice: (905) 837-8481
Voice: (716) 297-2920
Fax: (905) 837-8746
Fax: (716) 297-3689
Quality and Innovation Since 1963
Printed in Canada
Manual-Service-e10p-00-1v4.pdf

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E10P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YORKVILLE E10P

Summary of Contents for YORKVILLE E10P

  • Page 1 SERVICE MANUAL MODEL TYPE: YS1066 E10P WEB ACCESS: http://www.yorkville.com WORLD HEADQUARTERS CANADA U.S.A. Yorkville Sound Yorkville Sound Inc. 550 Granite Court 4625 Witmer Industrial Estate Pickering, Ontario Niagara Falls, New York L1W-3Y8 CANADA 14305 USA Voice: (905) 837-8481 Voice: (716) 297-2920...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This lightning flash with arrowhead symbol, within The exclamation point within an equilatereal triangle is an equilateral triangle, is intended to alert the user to intended to alert the user to the presence of important the presence of uninsulated “dangerous voltage” operating and maintenance (servicing) instructions in within the product’s enclosure that may be of sufficient the literature accompanying the appliance.

  • Page 3: Specifications

    Specifications E10p Model: powered loudspeaker System Type: Active Active or Passive: Program Power (Watts): Internally biamped Biamp Operation Only: 65 to 20k Frequency Response (Hz +/- 3db): 1500 Crossover Frequency (Hz): 2 way Driver Configuration: 1 inch HF Driver(s): HF Program Power (Watts):...
  • Page 4 2 Ch D/A 10-inch 300W Woofer CLASS D -30dB ±80V Mic / Line Amp / Chassis Ground 3v3,1V8ps 12.288 MHZ CLK 3v3ps HOST PROCESSOR WITH MEMORY 6-PIN BDM Connector LIVE / PLAYBACK (for programming) SUB IN/OUT LIMIT ANTI-FEEDBACK LEVEL TREBLE BASS BLOCK-DIAG-e10p-00-2v0.ai...
  • Page 5 PC8385: Replace L56 #7896 with #8108 Add SCORE lines on the sides. GG 5906 6405 12-JUL-2012 PC8458 - Changed P5 from 4435 to 4459 for PSA1. - ML Product 4599 E10P(M1311) / PSA1(M1496) 4599 M1311 INPUT/DSP PCB# Sheet M1496 Date:...

  • Page 6: Low Voltage Supply

    These parts are not inserted. 96kHz TO WOOFER AMP 2CLR 1CLR 2CLK 1CLK 100N DIG_GND W6:K 26 W250 {Voltage} 100N 0W35 0805 Product E10P(M1311) / PSA1(M1496) 7907 U1:C 2PRE 1PRE PART OF 26 PIN U1:B 7907 U1:A 7907 FEMALE MOLEX M1311 PCB# Sheet M1496...

  • Page 7: Power Supply

    Tie-net Name W6:Y PART OF 26 PIN 5190 Copper Tie Here TO92 100V FEMALE MOLEX W6:V Product IGND LVGND PS_GND E10P(M1311) / PSA1(M1496) W6:U WOOFERGND M1311 LVGND POWER SUPPLY PCB# Sheet WOOFERGND M1496 Date: Thu Jul 12, 2012 Rev: YsType: .
  • Page 8 AXIAL FUSE #2487 T7A MMBTA14LT1 = GROUND MERGE 7903 C106 3522 2337 R T V 4145 C102 M1311 E10P - M1311 R T V 330R0 M1496 R T V PSA1 - M1496 R T V R T V 1300UH 6492 R T V...
  • Page 9 7. B.A. FOR N.A. BOARDS ADD 18AWG JUMPER FROM W26 TO W27 AND FROM W29 TO W31 8. B.A. FOR CE BOARDS ADD 18AWG JUMPER FROM W27 TO W31 9. PCBSA: DO NOT BREAK OUT BOARD BEFORE TESTING X8019 REFERENCE TABLE M1311 E10P M1496 PSA1 REF DES USED ON...
  • Page 10 SEE PRODUCTION NOTES M1311 PCB_DATABASE_HISTORY MODEL(S):- E10P DATE VER# DESCRIPTION OF CHANGE 17-APR-2011 V04 DERIVED FROM M1311V03. PC 8242 16-JUN-2011 PC82xx: XH conn DS pads, add PCB title. GG 31-OCT-2011 PC8322: CHANGED W7 & W8 TO XH CONN. - ML...
  • Page 11 5989 R T V C102 270R R T V R T V R T V 1300UH 6492 R T V E10P C112 YORKVILLE E10P M1311 V3.00 M1311 GROUND W33G/Y R T V CLINCH INSERT ORIGIN Top Assy M1311 LONG AXIS...
  • Page 12 W063 0805 0805 100V U1:A 7833 MC7815BDTG M1495 - PCB DATABASE HISTORY 7846 DPAK3 MODEL(S):- E10P / PSA1 100N 100N DATE VER# DESCRIPTION OF CHANGE OCT 5th 2010 V01 FIRST PRODUCTION. DERIVED FROM M1310 28-JUN-2011 PC8222: Panelize and fiducials 03-MAY-2012 PC8428 - Moved the fids further into the panel.
  • Page 13 100P IRF9530NS CMPD914 7839 W1:F W250 D2PAK 100R 0805 MJD243T4G W1:E W125 7844 0805 DPAK3 W1:D W1:C 0805 0805 W1:B W1:A Product E10P / PSA1 HORN AMP PCB# M1495 Sheet Date: Thu May 03, 2012 Rev: YsType: YsType Filename: M1495V03SCH.sch2006...
  • Page 14 7844 100N HORN USE PLASTIC SHOULDER 560R MJB41C WASHER #8961 ON ALL 4 100N MJD243T4G IRF530NS CORNER MOUNTING NUTS 7847 7846 YORKVILLE SOUND HORN OUTPUT MC79M15 MC7815 SIGNAL HORN PICKERING, ON 470P 470P -15V REGULATOR C10 C11 +15V REGULATOR M1495 8701 + 8877 D&R V03...
  • Page 15 SEE LAYOUT DIAGRAM M1495 PRODUCTION NOTES 1. PLACE GROUNDING SCREW (#8877) AND NUT (#8701) IN SUBSTRATE GND HOLE AFTER REFLOW OVEN.
  • Page 16 SEE LAYOUT DIAGRAM M1495 MODEL(S):- E10P/LMLA DATE VER# DESCRIPTION OF CHANGE OCT 5th 2010 FIRST PRODUCTION. DERIVED FROM M1310 28-JUN-2011 PC8222: Panelize and fiducials 19-DEC-2011 . ADD HAND PLACE PARTS TO LAYOUT 03-MAY-2012 PC8428 - Moved the fids further into the panel. - ML...
  • Page 17 E10P Parts List 7/11/2011 YS # Description Qty. YS # Description Qty. YS # 5906 3MM LED 1V9 20MA.4SPCER T&R 7813 _47P 50V 5%CAP 0805 SMT NPO 7862 5907 3MM LED 1V9 20MA.4SPCER T&R 7927 100P 50V 10%CAP 0805 SMT NPO...
