INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
OUTDOOR LINEAR GAS FIREpLACE
GAS-FIRED
OLL60Fp12S(N,p)-1
OLL60Sp12S(N,p)-1
If the information in these instructions are
not followed exactly, a fire or explosion may
result causing property damage, personal
injury or loss of life.
If not installed, operated and maintained in
accordance with the manufacturer's instruc-
tions, this product could expose you to sub-
stances in fuel or from fuel combustion which
can cause death or serious illness.
Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car or home.
MODELS
WARNING
WARNING
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Empire OLL60FP12SN-1
Summary of Contents for Empire OLL60FP12SN-1
- Page 1 INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. OUTDOOR LINEAR GAS FIREpLACE WARNING MODELS For Outdoor Use Only. GAS-FIRED WARNING OLL60Fp12S(N,p)-1 OLL60Sp12S(N,p)-1 If you smell gas: 1. Shut off gas to the appliance. WARNING 2.
-
Page 2: Before You Start
BEFORE YOU START Read the safety information on pages 4 to 5. What to consider before installing. See Page 11. Water drainage is required. See page 12. Optional drain tray available. Where are you going to install the unit? See pages 11 to 13. Frame the opening. -
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION pAGE BEFORE YOU START .....................2 TABLE OF CONTENTS ...................3 IMpORTANT SAFETY INFORMATION ..............4 SAFETY INFORMATION FOR USERS OF Lp-GAS ..........5 INTRODUCTION ......................6 SpECIFICATIONS ....................7 ACCESSORIES .......................7 COMBUSTIBLE MATERIALS .................8 CLEARANCES ....................8 - 9 FIREpLACE DIMENSIONS ...................10 pLANNING INSTALLATION ................11 - 13 FIREpLACE INSTALLATION .................. -
Page 4: Important Safety Information
IMpORTANT SAFETY INFORMATION • Installer: please leave these instructions with the owner for DANGER: Indicates a hazardous situation which, if not future reference avoided, will result in death or serious injury. • This unit complies with ANSI Z21.97/CSA 2.41 for Outdoor WARNING: Indicates a hazardous situation which, if not Gas Fireplaces. -
Page 5: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF Lp-GAS Propane (LP-Gas) is a flammable gas which can cause fires SOME pOINTS TO REMEMBER and explosions. In its natural state, propane is odorless and • Learn to recognize the odor of LP-gas. Your local LP-Gas colorless. -
Page 6: Introduction
pRODUCT SpECIFICATIONS Natural Gas propane Gas Manifold pressure setting 4-1/2" w.c. 11" w.c. Gas inlet pressure Max. 7" w.c. 11" w.c. Air Shutter Setting 1/16" Open Fully Open Model Valve Type Orifice BTUH Max. Rate BTUH Min. Rate OLL60FP12L MANUAL 65,000 39,000 OLL60FP12L... -
Page 7: Specifications
Chase platforms, including hearths should slope away from the structure at 1/4 in. per foot. The fireplace can be shimmed level. When installed on surfaces where water may collect or cause damage: Empire Comfort Systems recommends a slope of 1/8 to 1/4 in. per foot towards the drain port suggested. The fireplace can be shimmed level. 35008-1-0515... -
Page 8: Combustible Materials
Television Considerations Installing a television above a fireplace has become increasingly popular; however, the area above any fireplace gets hot and most TV manufacturers recommend against placing their products near a heat source. If you install a television above this fireplace, Empire Comfort Sys- tems accepts no responsibility for damage or injuries. Follow the television manufacturer’s installation instructions, including any recommendations regarding proximity to heat sources. If you have a TV above your fireplace, turn off the fireplace and let it cool completely before servicing or touching any buttons on the TV. -
Page 9: Clearances
CLEARANCES Framing Header Non-Combustible Panels installed over Appliance Opening 6 1/2” 8” Fireplace Nailing Header Fireplace Fireplace Opening 2 1/4” Opening Non-Combustible Side Panel BOTH SIDES Support Framing NON-COMBUSTIBLE WALL BOARD PROVIDED Figure 4 Front and Side View of Non-Combustible panel to Opening on Fireplace's Face *Note: 8-in. minimum of non-combustible material is required above the fireplace opening. 16-in. of non-combustible material is provided to allow for placement of wall joint in a cooler temperature zone. -
Page 10: Fireplace Dimensions
FIREpLACE DIMENSIONS OLL60Fp OLL60Sp INDEX DIMENSION DESCRIpTION LETTER Dimensions in Inches The maximum height of firebox face 30-7/8 30-7/8 The maximum width of the firebox face (excluding nailing flanges) 63-3/4 63-3/4 The maximum depth of the firebox 19-1/8 22-1/2 The height of the firebox opening 16-3/16 16-3/16 The width of the firebox opening The interior depth of the firebox (not shown) 23-7/8 The rear exterior width of the firebox (not shown) Height from the bottom of the box to the gas line opening 2-9/16 2-9/16 Depth from the front of the box to gas line opening 5-3/16... -
Page 11: Planning Installation
pLANNING INSTALLATION What to Consider Before Installing Installation in partial enclosures must conform with one of the 1. Verify fireplace gas type and gas supply type are the same. following conditions: 2. Look for a location where combustibles will not interfere. • With walls on all sides, but with no overhead cover. 120V GFI power outlet will be needed for LED lights See Figure 5. - Page 12 ATTENTION: Vinyl Soffit, Vinyl Ceiling, Vinyl Overhang Disclaimer Clearances are to heat resistant material (i.e. wood, metal). This does not include vinyl. Empire Comfort Systems Inc. will not be held responsible for heat damage caused from terminating under Figure 8 vinyl overhangs, vinyl ceilings or vinyl ventilated/unventilated soffits.
-
Page 13: Planning Installation
pLANNING INSTALLATION Electrical Considerations CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. Before making the electrical connection, make sure that the main power supply is disconnected. The fireplace, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code ANSI/ NFPA 70 (Latest Edition). A factory installed junction box is located on the lower right side of the fireplace. The junction box and wiring may be relocated to the opposite side of the fireplace if desired. Wiring to the junction... -
Page 14: Framing & Installation
FIREpLACE FRAMING AND INSTALLATION FRAMING & INSTALLATION Unpacking the Fireplace After removal of the plastic wrap, remove the screws holding the corner posts and plywood to the fireplace. Discard the corner posts and plywood. The non-combustible board is under the fireplace on the pallet. Remove any protective film from fireplace and all components (nailing flanges, nailing headers, etc.). Framing Fireplace support framing should be built before the fireplace is set in place. The fireplace framing may be constructed of 2 x 4 lumber. The framing headers must rest on the fireplace nailing headers. Figure 12 - Nailing Flange position Refer to Figure 11 for minimum framing dimensions. -
Page 15: Framing & Installation
FIREpLACE FRAMING AND INSTALLATION FRAMING & INSTALLATION Secure the nailing header to the side framing studs with four Lift front of burner assembly and tilt upwards and toward #8 x 1 drywall screws the back of the fireplace. Retrieve the two supports from To connect the gas line and install the electrical connection, inside the fireplace and place one each side against the the burner assembly must be tilted upward in the fireplace. -
Page 16: Electrical Supply
FIREpLACE FRAMING AND INSTALLATION ELECTRICAL SUPPLY CAUTION All wiring should be done by a qualified electrician and shall be in compliance with all local, city and state building codes. Before making the electrical connection, make sure that the main power supply is disconnected. The fireplace, when installed, must be electrically grounded in accordance with local codes, or in the absence of local codes, with the National Electrical Code ANSI/ CONTROLS NFPA 70 (Latest Edition). -
Page 17: Gas Supply
FIREpLACE FRAMING AND INSTALLATION GAS SUPPLY • Solid fuels shall not be burned in this fireplace. A gas valve and ground joint union should be installed in the gas line upstream of the gas control to aid in servicing. It is required by • The maximum gas inlet supply pressure is 11 in. for LP and the National Fuel Gas Code that a drip line be installed near the 10.5 in. -
Page 18: Lp-Gas Cylinder Information
FIREpLACE FRAMING AND INSTALLATION LP-GAS CYLINDER INFORMATION WARNING WARNING If these instructions are not followed exactly, a fire causing A fire will result if the gas supply hose makes contact with the death or serious injury may occur. underside of the fireplace. Propane Cylinder Specifications Lp (propane) Gas This fireplace can be used with a non-disposable self-contained Attach cylinder retaining bracket supplied to the base of the cyl- LP-gas supply system: inder. Then secure to the surface to which it sits. Cylinder should •... - Page 19 FIREpLACE FRAMING AND INSTALLATION LP-GAS CYLINDER INFORMATION Enclosures For Lp (propane) Gas Supply Systems The enclosure for the LP-gas cylinder shall isolate the cylinder Enclosures for LP-gas supply cylinders shall be ventilated by from the burner compartment to provide: openings at the level of the cylinder valve and at floor level. The Shielding from heat radiation;...
-
Page 20: Finishing
FIREpLACE FRAMING AND INSTALLATION FINISHING 1. After gas and electrical hookup is completed, lower and Framing and Finishing secure the burner assembly (leave two supports in bottom of The fireplace is installed with panels around the opening as a fireplace for future use) with the two screws removed in Step clean face installation. See Figure 23. The top and sides must 7 on page 15. use non-combustible panels (provided) where shown going over 2. Install the glass wind panel (two used on see-through fire- the face of the fireplace. Outside of this area, any weatherproof places). - Page 21 FIREpLACE FRAMING AND INSTALLATION FINISHING To complete installation place non-combustible panel above fire- Notice for Finishing Materials place opening. Center panel on fireplace and secure with screws The wall above the fireplace will become hot. Install the non- into frame. With the non-combustible panels in position, predrill combustible board supplied with the fireplace before adding and counter-sink 1/8-in. diameter holes through the non-combus- paint, tile or stone. Attach tile or other non-combustible products tible panels and top nailing header before running the screws into to the fireplace face and to the non-combustible area (Figures the top mounting nailing header.
- Page 22 FIREpLACE FRAMING AND INSTALLATION FINISHING Crushed Glass Installation Decorative glass droplets may be added as an enhancement, but Ensure the burner cover screens are still properly installed, fully can not be used near or over the burner. See Figure 26. Neither covering the LED openings.
-
Page 23: Lighting Instructions
LIGHTING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING WARNING IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXpLOSION MAY RESULT CAUSING pROpERTY DAMAGE, pERSONAL INJURY, OR LOSS OF LIFE. A. BEFORE LIGHTING, smell around the appliance area for B. -
Page 24: Main Burner Flame Characteristics
MAIN BURNER FLAME CHARACTERISTICS Figure 28 - Correct Flame Lp Figure 27 WARNING NEVER operate fireplace with an optional weather door in place. Figure 29 - Correct Flame NAT In normal operation on high after 10 to 15 minutes, the flame ap- pearance should be several tongues of yellow flames. NOTE: All flames will be random by design, flame height will go up and down. During manufacture, fabricating, and shipping, various components of this fireplace are treated with oils, films, or bonding agents. These are not harmful, but may produce smoke and smells as they are burned off during the initial operation of the fireplace. This is normal. The initial break-in operation should last 2-3 hours with the burner at the highest setting. Any odors remaining after this initial break-in will disappear with continued use. Flames from the main burner should be visually out before the Figure 30 - Incorrect Short Blue Flame weather door is installed. -
Page 25: Operation Instructions/Flame Appearance
OpERATION INSTRUCTIONS/FLAME AppEARANCE LED Brightness Button Press the Brightness Button to activate the LED lights and to cycle LED Intensity from High to Low to Off. 1 – On – High 2 – Medium 3 – Low 4 – Off Use the Brightness Button in conjunction with the Mode Button to create unique looks. -
Page 26: Wiring
WIRING Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing. LED STRIP LED STRIP JUNCTION BOX TRANSFORMER BLACK LEFT BUTTON BLACK BLACK BRIGHTNESS BLACK RIGHT BUTTON BLACK BLACK MODE BLACK... -
Page 27: Maintenance
MAINTENANCE Keep the control compartment and burner area clean. ANNUAL CLEANING/INSpECTION – Refer to parts diagram for location of items discussed below. Always keep the fireplace area clear and free from combustible • Inspect and clean burner air intake hole. Remove lint or particles materials, gasoline, and other flammable vapors and liquids. with vacuum or brush. Failure to keep air intake hole clean will Never obstruct the flow of combustion and ventilation air. Keep the result in sooting and poor combustion. front of the fireplace clear of all obstacles and materials. -
Page 28: Troubleshooting
TROUBLESHOOTING SYMpTOMS - pOSSIBLE CAUSES AND CORRECTIONS Turn fireplace OFF and allow to cool before servicing. Only a qualified service person should service and repair the fireplace. Fireplace produces unwanted odors. If burning at main burner orifice occurs (a loud, roaring a. Fireplace burning vapors from paint, scented candles and blow torch noise). torches, glues, etc. - Ventilate area. Stop using odor causing a. Turn off fireplace and contact a qualified service person. -
Page 29: Master Parts Distributor List
MASTER pARTS DISTRIBUTOR LIST To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort. com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem with the unit. -
Page 30: Oll60Fp Parts List
OLL60Fp pARTS LIST USE ONLY MANUFACTURER'S REpLACEMENT pARTS. USE OF ANY OTHER pARTS COULD CAUSE INJURY OR DEATH. QTY REQ INDEX pART QTY REQ INDEX pART DESCRIpTION DESCRIpTION R12077 FLEX LINE NON-COMBUSTIBLE 35831 R1652 NUT LOCK (VALVE) BOARD, TOP R11982 COVER SCREEN LIGHTS R11981 GLASS... -
Page 31: Oll60Fp Parts View
OLL60Fp pARTS VIEW 35008-1-0515 Page 31... -
Page 32: Oll60Sp Parts List
OLL60Sp pARTS LIST USE ONLY MANUFACTURER'S REpLACEMENT pARTS. USE OF ANY OTHER pARTS COULD CAUSE INJURY OR DEATH. QTY REQ QTY REQ INDEX pART INDEX pART DESCRIpTION DESCRIpTION NONCOMBUSTIBLE REGULATOR 4.5 W.C. 35831 R7160 BOARD, TOP (NAT) R11981 GLASS FITTING BRASS R12078 1/2 FLARE X 3/8 MIP 35007... -
Page 33: Oll60Sp Parts View
OLL60Sp pARTS VIEW 35008-1-0515 Page 33... -
Page 34: Fireplace Service History
FIREpLACE SERVICE HISTORY Date Dealer Name Service Technician Name Service performed/Notes Page 34 35008-1-0515... -
Page 35: Warranty Terms
WARRANTY TERMS Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the periods specified below. Hearth products must be installed by a qualified technician and must be maintained and operated safely, in accordance with the instructions in the owner’s manual. This warranty applies to the original purchaser only and is not transferable. All warranty repairs must be accomplished by a qualified gas appliance technician. Limited Five-Year Parts Warranty – All Components (Except Remote Controls, Thermostats, Accessories and Replacement Parts) Should any part fail because of defective workmanship or material within five years from the date of purchase, Empire will repair or replace at Empire’s option. - Page 36 Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. www.empirecomfort.com Page 36 35008-1-0515...
