- Page 1 2-898-277-11 (1) Trinitron Color TV Operating Instructions • Before operating the unit, please read this manual thoroughly and retain it for future reference. KV-FA29 © 2006 Sony Corporation...
- Page 2 WARNING • Dangerously high voltages are present inside the TV. • TV operating voltage: 110 – 240 V AC. • Do not plug in the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground.
-
Page 3: Table Of Contents
Table of Contents Menu Adjustment Installation Securing the TV ........4 Introducing the WEGA GATE navigator ..........12 Getting Started ........5 “Settings” Adjustment ...... 13 Setting up your TV (“Initial Setup”) ........6 Changing the “Picture” setting ..14 Changing the “Sound”... -
Page 4: Installation
Installation x Securing the TV To prevent the TV from falling, use the supplied screws, clamps and band to secure the TV. 20 mm 3.8 mm screws clamps band Screw the band to the TV stand and to the provided hole at the rear of your TV. (1) Put a cord or chain through the clamps. -
Page 5: Getting Started
x Getting Started Step 1 Insert the batteries (supplied) into the remote. Note • Do not use old or different types of batteries together. Step 2 Connect the antenna cable (not supplied) to 8 (antenna input) at the rear of the TV. •... -
Page 6: Setting Up Your Tv ("Initial Setup")
x Setting up your TV (“Initial Setup”) When you turn on your TV for the first time, the “Initial Setup” menu will appear. You may change the menu language, preset the TV channels automatically, sort or edit the channels and adjust the picture position using the buttons on the remote control or TV front panel. - Page 7 d) If you wish to edit the channels, press to change to edit mode. Press b until the mode that you wish to edit is highlighted: Label, Skip, (block symbol). Then press 1) To label, press V or v to select the alphanumeric characters for the label.
-
Page 8: Overview Of Controls
Overview of Controls TV front and rear panels TV rear panel (MONO) (MONO) qa qd qs qa TV front panel L(MONO) SOUND PROG MODE WEGA GATE Button/Terminal Function Page Turn off or turn on the TV. Wake Up indicator. Standby indicator. Remote control sensor. -
Page 9: Using The Remote Control And Basic Functions
Using the remote control and basic functions Button Description Page 1 ?/1 Turn off temporarily or turn on – the TV. Display the TV program. – Jump to last program number – that has been watched for at least five seconds. PROG +/–... - Page 10 continued Button Description Page Timer operations Set TV to turn on automatically according to the desired – period of time (max. of 12 hours). (Wake up timer) indicator on TV lights up amber once you set the wake up timer. If no buttons or controls are pressed for more than one hour after the TV is turned on using the wake up timer, the TV automatically goes into standby mode.
-
Page 11: Advanced Operations
Advanced Operations Selecting the picture and sound modes You can select picture and sound modes and adjust the setting to your preference in the “Custom” option. Selecting the picture mode Press to select the desired picture mode. Select To view “Vivid”... -
Page 12: Menu Adjustment
Menu Adjustment x Introducing the WEGA GATE navigator WEGA GATE is a gateway that allows you access to preset TV channels, connected external inputs and “Settings” menu. WEGA GATE External Inputs “TV” watch the preset TV Settings channels (see page 6) Select Confirm Select... -
Page 13: Settings" Adjustment
x “Settings” Adjustment You are able to change the settings of your TV from “Settings” in WEGA GATE menu. Press WEGA GATE button to display WEGA GATE menu. Press V or v to select “Settings” and press The following is an overview of the items that can be adjusted. ”Picture”... -
Page 14: Changing The "Picture" Setting
x Changing the “Picture” setting The “Picture” menu allows you to adjust settings below. Press WEGA GATE and select “Settings”. Make sure the “Picture” icon ( ) is Picture Picture Mode: Vivid selected, then press Picture Adjustment Color Temperature: Cool High Intelligent Picture: Signal Level Indicator:... -
Page 15: Adjusting The "Picture Adjustment" Items Under "Custom" Mode
Adjusting the “Picture Adjustment” items under “Custom” mode Press V or v to select either “Picture” (contrast), “Brightness”, “Color”, “Hue” (color tones) or “Sharpness”, then press Selecting “Reset” will set your TV to the factory settings. Press V,v,B or b to adjust the setting of your selected item, then press Repeat the above steps to adjust other items. -
Page 16: Changing The "Sound" Setting
x Changing the “Sound” setting The “Sound” menu allows you to adjust settings below. Press WEGA GATE and select “Settings”. Press V or v to select the “Sound” Sound Sound Mode: Dynamic icon ( ), then press Sound Adjustment Balance Intelligent Volume: Surround: Select... -
Page 17: Changing The "Channel Setup" Setting
x Changing the “Channel Setup” setting The “Channel Setup” menu allows you to adjust settings below. Press WEGA GATE and select “Settings”. Press V or v to select the “Channel Setup” Channel Setup Auto Program icon ( ), then press Manual Program Program Sorting/Edit Select... -
Page 18: Presetting Channels Manually
continued Presetting channels manually After selecting “M anual Program”, select the program number to which you want to preset a channel. Manual Program Program: (1) Make sure “Program” is selected, then press TV System: VHF Low Fine: Auto (2) Press V or v until the program number you want Signal Booster: Auto to preset appears on the menu, then press... -
Page 19: Changing The "Setup" Setting
x Changing the “Setup” setting The “Setup” menu allows you to adjust settings below. Press WEGA GATE and select “Settings”. Press V or v to select the “Setup” icon ( Setup Language: English then press Picture Position Video Label Color System: Auto Factory Settings Select... -
Page 20: Additional Information
Additional Information x Connecting the 3D WOOFER, TWEETER and CENTER SPEAKER You can enjoy high quality sound by connecting the 3D WOOFER, TWEETER and CENTER SPEAKER as follows: Step 1 Front view of 3D WOOFER, TWEETER and CENTER SPEAKER 3D WOOFER CENTER TWEETER SPEAKER... -
Page 21: Connecting Optional Components
x Connecting optional components Connecting to the video input terminal ( t ) TV front panel Audio/Video cable (not supplied) Camcorder L(MONO) TV rear panel Antenna cable (not supplied) (MONO) (MONO) DVD player Audio/Video cable (not supplied) Note • If you connect a VCR to 8 (antenna input), preset the signal output from the VCR to the program number 0 on the TV (see page 18). -
Page 22: Connecting To The Component Video Input Terminal
continued Connecting to the component video input terminal ( TV rear panel Component video cable (not supplied) (MONO) (MONO) DVD player Audio cable (not supplied) Notes • If your DVD player can output interlace and progressive mode signals, select the interlace output when connecting to (component video input) on your TV. -
Page 23: Troubleshooting
• Check the antenna cable and connection on the TV, VCR and at the wall noisy sound (see page 21). • Check the antenna setup. Contact a Sony dealer for advice. • Display the “Channel Setup” menu and select “Manual Program” to preset the channel again (see page 18). - Page 24 TV. • Count the number of times the 1 (standby) indicator flashes. The 1 (standby) indicator on your Press ! (main power) to turn off your TV. Contact your nearest Sony TV flashes red service center. several times after every three seconds.
-
Page 25: Specifications
Specifications KV-FA29M83 Note KV-FA29M53 Power requirements 110-240 V AC, 50/60 Hz Power consumption (W) Indicated on the rear of the TV Television system B/G, I, D/K, M Color system PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43 Channel coverage VHF : E2 to E12 /UHF : E21 to E69 / CATV : S01 to S03, S1 to S41 UHF : B21 to B68 /CATV : S01 to S03, S1 to S41 VHF : C1 to C12, R1 to R12 /...
